Frigidaire Microwave / Wall Oven Combination Manual de usuario

p/n 316495004 rev B (0706)

Microwave Oven

Over-the-Range

READ AND SAVE THESE INSTRUCTIONS

Welcome..........................................2

Important Safety Instructions .....3-6

Features and Specifications ..........7

Before Operating ............................8

Manual Operation ..................... 9-14

Convenience Operation ......... 15-16

Cooking Charts ...................... 17-18

Care & Cleaning ..................... 19-20

Before You Call

Solutions to Common Problems........................ 21

Warranty ......................... Back Page

Visit the Frigidaire Web Site at: http://www.frigidaire.com

Questions or for Service Call:

1-888-312-2117

with Convenience Pad

Welcome & Congratulations

This Use & Care Manual contains

generaloperatinginstructionsforyour

applianceand feature informationfor

several models. Your microwave may

not have all the described features. The

graphicsshown are representative.The

graphics on your microwave may not

look exactly like those shown.

Be sure to register your product. The

self-addressedPRODUCT

REGISTRATIONCARD should be filled

in completely, signed and returned to

Electrolux Home Products.

Product Registration

Congratulations on your purchase of a new microwave! At Electrolux Home

Products, we are very proud of our product and are completely committed to

providing you with the best service possible. Your satisfaction is our number

one priority.

We know you’ll enjoy your new microwave and Thank You for choosing our product.

We hope you consider us for future purchases.

PLEASE CAREFULLY READ AND SAVE THESE INSTRUCTIONS

This Use & Care Manual provides specific operating instructions for your model.

Use your microwave only as instructed in this manual. These instructions are

not meant to cover every possible condition and situation that may occur.

Common sense and caution must be practiced when installing, operating and

maintaining any appliance.

Be sure to record your model and serial number. The serial plate is located on

the back of the microwave oven.

Please record your model and serial number and date of purchase in

the spaces provided below for future reference in case your microwave

should ever require servicing:

Model Number:

Serial Number:

Purchase Date:

Important Safety Instructions

What You Need to

Know About Safety

Instructions

Warning and Important Safety Instructions appearing in the

Use & Care Guide are not meant to cover all possible

conditions and situations that may occur. Common sense,

caution, and care must be exercised when installing,

maintainingor operating a microwave.

Always contact your dealer, distributor, service agent or

manufacturer about problems or conditions you do not

understand.

Recognize Safety

Symbols, Words, Labels

SAVE THESE INSTRUCTIONS

Important Safety Instructions

Grounding Instructions

SAVE THESE INSTRUCTIONS

Federal

Communications

Commission Radio

Frequency Interference

Statement (U.S.A. Only)

Important Safety Instructions

SAVE THESE INSTRUCTIONS

Adhere to the following precautions:

• DO NOT attempt to operate this oven with the door open

since open door operation can result in harmful exposure

to microwave energy. It is important not to defeat or

tampler with the safety interlock switches.

• DO NOT place any object between the oven front face

and the door or allow soil or cleaner residue to

accumulate on sealing surfaces.

• DO NOT use any cleaning materials on the oven door

gasket. Doing so could cause damage.

• DO NOT operate the oven if it is damaged. It is

particularly important that the oven door close properly

and that there is no damage to:

1. door (bent),

2. hinges and latches (broken or loosended),

3. door seals and sealing surfaces.

•Oven should not be be adjusted or repaired by anyone

exceptproperaly qualified service personnel.

Precautions to Avoid

Possible Exposure to

Excessive Microwave

Energy

Important Safety Instructions

When using electrical appliances, basic safety

precautions should be followed to reduce the risk of

burns, electric shocks, fire or injury to persons or

exposureto excessive microvave energy.

• READ ALL instructions before using oven.

• READ AND FOLLOW the specific “PRECAUTIONS

TOAVOID POSSIBLE EXPOSURE TO EXCESSIVE

MICROWAVE ENERGY” on page 5.

•Install or locate this oven ONLY in accordance with

the installation instructions in this Use & Care

Manual.

•Some products such as whole eggs and sealed

containers - for example, closed jars - are able to

explode and SHOULD NOT be HEATED in this oven.

•Use this oven ONLY for its intended use as described

in this Use & Care Manual. Do not use corrosive

chemicals or vapors in this oven. This type of oven is

specifically designed to heat, cook, or dry food. It is

not designed for industrial or laboratory use.

•As with any appliance, CLOSE SUPERVISION is

necessary when used by CHILDREN or INFIRM

PERSONS.

•Review the door cleaning instructions in the Care &

Cleaningsection.

• DO NOT heat baby bottles in oven.

•Baby food jars shall be open when heated and

contents stirred or shaken before consumption, in

orderto avoid burns.

• DO NOT use this oven for commercial purposes. It is

made for household use only.

To avoid the risk of fir in the oven cavity: injury to persons

or exposure to excessive microvave energy.

• DONOT overcook food. Carefully attend ovenwhen

paper, plastic or other combustible materials are

placed inside the oven to facilitate cooking.

•Remove wire twist-ties from paper or plastic bags

before placing bag in oven.

• DO NOT operate this oven if it has a damaged cord or

power plug, if it is not working properly, or if it has

beendamaged ordropped.

•This oven, including power cord, must be serviced

ONLY by qualified service personnel. Special tools are

requiredto service oven. Contact nearest authorized

service facility for examination, repair, or adjustment.

• DO NOT cover or block any vents, openings or filters

on the oven.

• DO NOT store this oven outdoors. DO NOT use this

appliance near water - for example, near a kitchen

sink, in a wet basement, near a swimming pool or

similar locations.

• DO NOT immerse cord or plug in water.

•Keep cord AWAY from HEATED surfaces.

• DO NOT let cord hang over edge of table or counter.

•Review the door cleaning instructions in the Care &

Cleaningsection.

•Cleanthe ventillating hood frequently.

• DO NOT allow grease to accumulate on the hood or

filters.

•Use care when cleaning the ventilating hood filters.

Corrosive cleaning agents such as lye-based oven

cleaners may damage the filters.

•When flaming foods under the hood, turn the fan on.

•Suitable for use above both gas and electric cooking

equipment 36 inches or less wide.

•If materials inside the oven ignite, keep oven door

CLOSED, turn oven off and disconnect the power cord,

or shut off power at the fuse or circuit breaker panel.

• DO NOT use this oven cavity for storage. DO NOT

leave paper products, cooking utensils or food in the

caity when not in use.

SAVE THESE INSTRUCTIONS

Features & Specifications

Microwave features

Turntable

Shaft

Turntable

ring

assembly

Turntable

glass

tray

Control

panel

Door

assembly

Window

Interlock

system

Oven specifications

Control panel

(1) Popcorn

(2) Beverage

(3) Potato(1-3 potatoes)

(4) Reheat (3 different settings)

(5) Defrost (by time or weight)

(6) EasySet (3 instant key settings)

(7) numeric pads (0 thru 9)

(8) Clock

(9) Timer

(10) Cook Time

(11) Power Level (10 power levels available)

(12) +30 sec ~ Press this pad to add 30

seconds to cook time. Each press will add

additional 30 seconds to the cook time.

(13) START/Pause

(14) Stop/Cancel

(15) Exhaust (High/Low/Off ~ Use to turn the

exhaust fan on, off or to adjust fan speed.

(16) Surface Light ~ Press this pad to turn the

surface lights on or off.

PowerSupply

InputPower

CookingPower

Frequency

OuterDimensions

(WxHxD)

CavityVolume

Net Weight

120VAC, 60 Hz

1,550W

1,000W

2,450 MHz

29.88”x15.75”x15.04”

1.5 cubic ft.

65.04 lbs.

Front View

Front Vent Grill

Bottom View

Front

Rear

Surface lights

Ventilation

filters

Before Operating

Learn more about your

microwave oven

•To avoid risk of personal injury or property damage, do

not operate the microwave oven empty.

•To avoid risk of personal injury or property damage, do

not use stoneware, aluminum foil, metal utensils, or

metal trimmed utensils in the microwave oven.

Setting the clock

Example: setting clock display for 9:00:

1. Touch Clock

2.Enter time using number pads.

3.Touch Clock pad again.

Microwave utensil guide

•Oven proof glass (specifically treated

for high intensity heat):

Utility dishes, loaf dishes, pie plates,

cake plates, liquid measuring cups,

casseroles and bowls without metallic

trim.

•China:

Bowls, cups, serving plates and platters

without metallic trim.

•Plastic:

Plastic wrap (as a cover) - lay the plastic

wrap loosely over the dish and press it to

the sides. Vent plastic wrap by turning

back one edge slightly to allow excess

steam to escape. The dish should be

deep enough so that the plastic wrap will

not touch the food. Use plastic dishes,

cups, semi-rigid freezer containers and

plastic bags for short cooking times. Use

these with care because the plastic may

soften from the heat of the food.

•Paper:

Paper towls, waxed paper, paper napkins

and paper plates with no metallic trim or

design. Look for the manufacturer’s label

for any special instructions for use in the

microwaveoven.

•Metal utensils:

Metal shields the food from microwave energy and produces uneven

cooking. Also, avoid metal skewers, thermometers or foil trays. Metal

utensils can cause arcing, which can damage your microwave oven.

•Metal decoration:

Bowls, cups, serving plates and platters without metallic trim.

•Aluminum foil:

Avoid large sheets of aluminum foil because they hinder cooking and

may cause harmful arcing. Use small pieces of foil to shield poultry

legs and wings. Keep ALL aluminum foil at least 1 inch from the side

walls of the oven cavity and door of the microwave.

•Wood:

Wooden bowls and boards will dry out and may split or crack when

you use them in the microwave oven. Baskets made of wood will react

in the same way.

•Tightly covered utensils:

Be sure to leave openings for steam to escape from covered

cookware. Pierce plastic pouches of vegetables or other food items

before cooking. Tightly closed pouches may explode.

•Brown paper:

Avoid using brown paper bags. They absorb heat and can burn.

•Flawed or chipped cooking utensils:

Any utensil that is cracked, flawed or chipped may break in the oven.

•Metal twist ties:

Remove metal twist ties from plastic or paper bags. They become hot

and could cause a fire.

Use Do not use

pad once for AM,

touch twice for PM.

Manual Operation

Setting the timer

Example: setting timer for 5 minutes:

1. Touch Timer pad once.

2. Enter desired time using number pads.

3. Touch Timer pad.

When the timer has reached the end of set time, you will

hear beep alerts indicating the timer has run out.

Exhaust High / Low / Off

The exhaust ventilation moves steam and other cooking

vapors from the cooking surface of the range below the

microwaveoven.

To operate the exhaust vent, Touch the

Exhaust High/Low/Off pad once for the

highest speed setting. Touch the pad again to

choose the Low speed setting and a 3rd time

to turn the exhaust ventilation off.

Note: If the temperature gets too hot around the microwave

oven, the fan in the exhaust vent hood will automatically turn

on at the LOW setting to cool the oven. The will

automatically turn off when the internal parts are cool. When

this occurs, the vent cannot be turned off.

Surface Light / On / Off

Touch the Surface Light/On/Off pad

once for a cooking surface light. Press the

pad again to turn the light off.

Control Lock

You may lock the control panel to prevent the microwave

from being accidentally started or used by children.

The control lock feature is very useful when cleaning the

control panel. The lock will prevent accidental programming

when wiping the control panel clean.

Example: to set the control lock ON:

Touch and hold the Stop/Cancel pad for more

than 3 seconds. The Lock icon will appear in

the display window along with 2 beeps. hold for 3

seconds

UsingEasySet

Example: to quickly heat for 2 minutes at 100% power:

Touch number pads 1, 2 or 3 for desired

minutes of cook time.

Microwave heating or cooking may be quickly set at 100%

power level for 1, 2 or 3 minutes. Use the number keys 1, 2

or 3 to choose the desired minutes of cook time (this option

will only work using the 1, 2 or 3 numeric pads):

Note: the EasySet function cannot be set when using the

Defrost (by weight) feature.

Example: to change the control lock from ON to OFF:

Touch and hold the Stop/Cancel pad for

more than 3 seconds. The Lock icon will

disappear in the display window. hold for 3

seconds

Heating with multiple cooking stages

Example: to cook food for 3 minutes at 80% power and

then 50% power for 6 minutes 30 seconds:

For best results, some microwave recipes call for different

power levels or different lengths of time for cooking. Your

microwave may be set to change from one stage to another

automatically (2 stages maximum).

1. Press Cook Time.

2. Use the number pads to enter

heating time for the 1st stage (cook

time may be set up to 99 minutes

and 99 seconds).

3. Press Power Level pad once.

4. Use the number keys to enter power

level for the 1st stage. PL8 appears

in the display (80 % power).

5. Press Cook Time pad for 2nd

stage.

6. Use the number pads to enter

heating time for the 2nd stage (cook

time may be set up to 99 minutes

and 99 seconds).

7. Press Power Level pad for 2nd

stage.

8. Use the number key to enter power

level for the 2nd stage. PL5 appears

in the display (50 % power).

9. Press START pad.

Manual Operation

Heating with high power level

Example: to heat for 5 minutes at 100% power:

1. Press Cook Time pad.

2. Use the number pads to enter

desired heating time (cook time may

be set up to 99 minutes and 99

seconds).

3. Touch START

pad.

Heating with lower power levels

Example: to heat for 4 minutes at 70% power:

1. Press Cook Time.

2. Use the number pads to enter desired

heating time (cook time may be set

up to 99 minutes and 99 seconds).

3. Press Power Level pad once for

powerlevel 10 (100% power).

4. Use the number key to change the

power level to 7. PL7 appears in the

display (70 % power).

5. Press START pad.

Using the highest power level to heat foods with does not

always give the best results when some types of food need

slower cooking, such as roasts, baked goods or custards.

Your oven has nine other power levels you may choose.

When heating has finished you will hear 5 beeps and

"Good" will display.

When heating has finished you will hear 5 beeps and

"Good" will display.

When heating has finished you will hear 5 beeps and

"Good" will display.

Note:

Power level must always be programmed for first

stage - 100% =10.

Otros manuales para Microwave / Wall Oven Combination

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Microondas de Frigidaire

Frigidaire

Frigidaire FGMV174KFC Manual del propietario

Frigidaire

Frigidaire GLMV168K Manual de usuario

Frigidaire

Frigidaire GMOS1968A Manual del propietario

Frigidaire

Frigidaire CPLMZ169GCC Manual de usuario

Frigidaire

Frigidaire FMT148 Manual de usuario

Frigidaire

Frigidaire GLMV168C Manual de usuario

Frigidaire

Frigidaire 316495054 Manual de usuario

Frigidaire

Frigidaire FMV158FM Manual de usuario

Frigidaire

Frigidaire FPMC2785K F Hoja de instrucciones

Frigidaire

Frigidaire FFMV162LSA Manual de usuario

Frigidaire

Frigidaire FFMV164LS Manual de usuario

Frigidaire

Frigidaire FMV152K Manual de usuario

Frigidaire

Frigidaire FGMO205KB - Gallery 2.0 cu. Ft. Microwave Manual de servicio

Frigidaire

Frigidaire GLMB186C Manual de usuario

Frigidaire

Frigidaire Gallery FGMC2765K Manual de usuario

Frigidaire

Frigidaire FCL-MW10W Manual de instrucciones

Frigidaire

Frigidaire FGMV173KQ - Gallery Series Microwave Manual de usuario

Frigidaire

Frigidaire FGMV173KB - Gallery Series Microwave Manual de usuario

Frigidaire

Frigidaire FMS062E1W Manual de usuario

Frigidaire

Frigidaire FGBM185K Manual de usuario

Frigidaire

Frigidaire MWV150K Manual de instalación y operación

Frigidaire

Frigidaire FGMV185KB - Gallery 1.8 cu. Ft. Microwave Manual de usuario

Frigidaire

Frigidaire FPMC2785KF - Professional 27" Electric Wall... Manual de usuario

Frigidaire

Frigidaire FFMV154CLS Instrucciones de funcionamiento y seguridad

Manuales populares de Microondas de otras marcas

Daewoo

Daewoo KOG-574R0S Manual de usuario

LG MH7040SS Manual de usuario

Sharp

Sharp R-895(AL)M Manual de usuario

Dometic

Dometic DOTRM13W Manual de usuario

Sanyo

Sanyo EM-X680 Manual de usuario

Sharp

Sharp R-393M Manual de usuario

KitchenAid

KitchenAid KMCX4510 Instrucciones de instalación

Smeg

Smeg S45MCX1 Manual de usuario

Russell Hobbs

Russell Hobbs RHM2044 Manual de usuario

Sunbeam

Sunbeam SMW759 Manual de usuario

Gallet

Gallet FMOE230S Manual de usuario

Bosch

Bosch CEG732X.1B Manual de usuario

Dometic

Dometic Roadmate 230 Manual de usuario

Samsung

Samsung SJ0396W Manual de usuario

Sanyo

Sanyo EM-P494WS Manual de usuario

Sharp

Sharp R-240 Manual de usuario

Electrolux

Electrolux EMS2840 Manual de usuario

Daewoo

Daewoo KOC-984T2S13 Manual de usuario
