Frigidaire FFU14F3AW Manual de usuario

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS

FFU14F3AW0 FFU14F3AW 134A white 115

MARKET

North America

Publication No.

5995354148

010604

-EN/SERVICE /GS

365

FREEZER

Model number

FFU14F3AW

FACTORY PARTS CATALOG

FREEZER

WIRING DIAGRAM - # 216803600

OWNER’S GUIDE - # 216802800

SERVICE DATA SHEET - # 216803600

ELECTROLUX HOME PRODUCTS NORTH AMERICA

P.O.BOX 212378, AUGUSTA, GA 30917

06/01 2

Publication No. FFU14F3AW

5995354148

DOOR

# = Fast-moving Parts 3 06/01

* = Non-Illustrated Parts

FFU14F3AW Publication No.

5995354148

DOOR

POS. NO PART NO DESCRIPTION

1 216522306 Gasket-door,white

2 5303925107 Lock Assy

5 216702900 Key,lock

9 216527605 Panel-inner door,white ,frzr

11 216557805 Panel-outer door,complete ,w/foam insul

12 240415201 Label-nameplate,white

13 08016354 Door Stop

14 5303313518 Washer,sealing

21A 08005520 Screw-dr stop mtg,flat hd metric , 4.0 x 0.7-19.7

22 216443600 Bearing

22A 216503200 Bearing-hinge,btm

26 216524300 Gasket,secondary

27 5303212828 Clip,panel

28 216523302 Rack-shelf

32 5309950074 Valve-breather

64 216403700 Plug-button,base door

93 5303302760 Screw

* 5303925098 Insulation

06/01 4

Publication No. FFU14F3AW

5995354148

CABINET

# = Fast-moving Parts 5 06/01

* = Non-Illustrated Parts

FFU14F3AW Publication No.

5995354148

POS. NO PART NO DESCRIPTION

3 216502600 Plug-drain,interior ,interior

5 # 216325600 Fan Blade

6 216603400 Breaker Kit w/corners,28", top or btm

7 216603800 Breaker Kit w/corners,lock catch

9 216604300 Breaker Kit w/corners

13 216787000 Motor-fan

14 # 216472300 Switch-light plunger

15 # 216608600 Lamp,light bulb ,40 W ,120 V

16 # 5300136117 Socket-light/lamp

18 216707200 Knob-control cold

19 216204900 Gasket,evap cover

20 5303288184 Cover-control housing

21 # 216788000 Control-temperature

22 05878562 Clamp,cap tube ,cold control

22A 5303916855 Tube,sensor sleeve ,plastic ,clear

23 06594648 Light-signal,amber

24 5300052943 Screw-clamp,truss hd cr ,control

25 216737000 Cover-evaporator

26 216503300 Ramp,closer ,door

27 5303205738 Screw-hinge,cr ,1/4-20 x 1.000 ,btm

28 216247400 Hinge-bottom

32 5308005500 Drain

33 216252001 Bracket,signal light

34 216557500 Shield-light

38 5303925086 Hinge-upper

39 5303294372 Nut-insert,hinge

40 5303212912 Cover-hinge

41 5303212937 Screw-top hinge

42 216546100 Shelf,16.69 X 23.88 WH,16.69x23.88,

42A 216546200 Shelf,14.50 X 23.88 WH,14.50x23.88 ,

47 216661600 Baffle-plate

49 216278800 Trivet

50 216394000 Bracket-motor mtg fan

63 216396900 Foot-adjustable

71A 216347500 Screw,quadrex

72 216591215 Grille/Kickplate

93 5303302760 Screw

108 216388600 Trap-drain

132 5303283898 Screw,6-20AB x 3/8

* 09948773 Insulation,drain tube

* 216502400 Grommet-shelf mtg

* 216802800 Owners guide

* 5303305324 Paint,touch-up ,white

CABINET

06/01 6

Publication No. FFU14F3AW

5995354148

SYSTEM

# = Fast-moving Parts 7 06/01

* = Non-Illustrated Parts

FFU14F3AW Publication No.

5995354148

POS. NO PART NO DESCRIPTION

1 # 5300123788 Condenser

2 5308000110 Strap-evap/heater,aluminum ,(2)

4 216634500 Drier-filter

5 216806400 Harness-main

14 216730700 Heater-defrost

15 216737400 Evaporator

15A 216565700 Heat Exchanger

18 216727600 Insulator-evap,styrofoam

19 216727700 Insulator-evap,styrofoam

20 216731000 Thermostat-defrost

23 216744400 Timer-defrost

24 08016580 Bracket

27 216498900 Grommet,compressor

29 # 216784300 Compressor,w/o electricals

30 216649313 Controller

31A 216601800 Pan-drain,production compr

32 216649200 Clip,controller

34 5306594529 Sleeve-compressor

35 5303272328 Screw,Ind hex sems ,1/4-28 unfx , compr

55 # 216787800 Capacitor-run

86 216036600 Screw,rwhd (gx-ca) ,8-32 x 1/2

87 08037849 Screw

130 216730400 Support-evaporator

SYSTEM
