Frigidaire FRA18EMU2 Instrucciones de instalación

frigidaire.com

Signature Features

Median

Air Conditioner / Heater

Product Dimensions

Height 17-7/8"

Width 23-5/8"

Depth 25-3/8"

More Easy-To-Use Features

Eortless™ Clean Filter

Our antibacterial filter reduces bacteria,

room odors and other airborne particles

for a cool, comfortable environment.

Multi-Speed Fan

Features three different fan speeds, for

more cooling flexibility.

Sleep Mode

Quiet operation keeps you cool without

keeping you awake. Plus, Sleep Mode

gradually increases room temperature

after being activated.

Quickly Cools

Quickly cool a room on hot days.

Comfort Control Design

Easily control the direction of your cool air,

wherever your unit is.

Eortless™ Restart

Automatically resumes operating at its

previous settings when power is restored

to your unit.

Clean Filter Alert

Notifies you when your filter needs to be

cleaned.

Power Cord

Comes with an extra long three-prong cord

— makes extension cords unnecessary.

SpaceWise® Adjustable Design

Optional Side Panels

Extend so you can adjust your unit to fit

your window.

24-Hour On/O Timer

Keep things cool on your schedule.

Performance

Cool

Heat

BTUs

18,500 / 18,200

16,000 / 13,000

Home Comfort

FRA18EMU2

Eortless™ Temperature

Control

Our air conditioners maintain the preset

room temperature, so you will remain

comfortable at all times.

Ready-Select® Controls

Easily select options with the touch of a

button.

Supplemental Heating

Option

Our versatile unit offers a supplemental

heating capability, providing you with an

additional heat source when needed.

Remote Control

Allows you to precisely control the

temperature and fan speed from across

the room.

Specifications

subject to change.

Performance

BTU (Cool)

BTU (Heat)

Dehumidiﬁcation (Pints / Hour)

Cool Area (Sq. Ft.)

Energy Eciency Ratio

Electrical

Volts

Amps (Cool)

Amps (Heat)

Watts (Cool)

Watts (Heat)

Length of Power Cord (Min. / Max.)

Plug Type (NEMA)

Features

Electronic Controls

Fan Speeds (Cool / Fan / Heat)

Low Voltage Start-Up

Auto Cool Function

Energy Save

Sleep Mode

Filter Check

24-Hour On / O Timer

Clean Air Ionizer

Remote Control

Air CFM (High / Med / Low)

Air Direction Control

Fresh Air / Exhaust Vent / Closed

Filter Type

Filter Access

Slide-Out Chassis

Window Mounting Kit (Included)

Warranty1

Certiﬁcations

Performance

Speciﬁcations

Refrigerant

Shipping Weight (Approx.)

Plug Type (NEMA)

6-30P

Product Dimensions

A - Height

B - Width

C - Depth

Window Dimensions

D - Height (Min.)

E - Width (Min. / Max.)

Wall Cutout Dimensions

F - Max. Wall Thickness

Height

Width

18-1/2"

26-1/2" / 40-1/2"

18"

23-7/8"

NOTE: For planning purposes only. Always consult local and national electric codes.

Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.

RAC Median Models

Frigidaire Baseline

Accessories information available

on the web at frigidaire.com

1Warranty 5 year sealed system / 1 year full parts and labor.

17-7/8"

23-5/8"

25-3/8"

18,500 / 18,200

16,000 / 13,000

5.5

1,170

9.7

230 / 208

8.4 / 9.1

22.2 / 20.0

1,900 / 1,883

4,900 / 4,000

5' / 6'

LCDI (6-30)

Ready-Select® Controls

3 / 3 / 3

Yes

Full-Function with Heat

459 / 406 / 344

8-Way

Yes / Yes / Yes

Antibacterial Mesh

Tilt-Out

Yes

Pleated Quick Mount

Yes

AHAM

R410a

126 Lbs.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Home Comfort

FRA18EMU2 Median Air Conditioner / Heater
