FRIENDCOM FC-301/D Manual de usuario
FC-301/D
USER MANUAL
SHENZHEN FRIENDCOM TECHNOLOGY DEVELOPMENT CO.,LTD
ADD: 6/F, 17 Building , Guangqian Industrial Park, Longzhu Road, Xili Town, Nanshan,
Shenzhen City 518055 P.R.CHINA.
TEL: +86-755-86026600 +86-755-86026192 FAX: +86-755-86026300
WEBSITE: www.friendcom.cn
- 1 -
TABLE OF CONTENTS
TABLE OF CONTENTS .....................................
．
01
．．
SPECIFICATIONS ..........................................02
CIRCUIT DIAGRAM........................................07
INTRODUCTION...........................................08
FEATURES................................................08
TROUBLE SHOOTING GUIDE...............................09
WIRING DIAGRAM.........................................10
PROGRAMMING ..........................................13
FACTORY DEFAULT SETTING ..............................27
- 2 -
SPECIFICATION
GENERAL
Equipment Type…………………………………Data Radio
Performance Specification…………..................TIA/EIA-603 & ETS 300-113
Band …………………………………………...UHF/VHF
Channel Spacing………………………………25KHz,12.5KHz programmable
RF Output Power……………………………….1W - 5W Programmable
Modulation type ………………………………..16K0F3E,8K5F3E
Intermediate Frequency………………………… 45.1MHz & 455KHz
Number of Channels…………………………….16
Frequency Source ……………………………….Synthesizer
Operation Rating…………………………………Intermittent
5:5:90 ( TX: RX: Standby )
Power Supply ……………………………………12.5V DC Nominal Voltage
Temperature Range
Storage………………………………………from –40°C to +80°C
Operating……………………………………from –30°C to +60°C
Current Consumption
Standby (Muted) ……………………………≤40mA
Transmit 5 Watts RF Power …………………< 1.5A
Transmit 1 Watt RF Power…………………..<0.8A
- 3 -
Frequency Bands ………………RX UHF: 400 – 470 MHz VHF: 136 – 174 MHz
………………TX UHF: 400 – 470 MHz VHF: 136 – 174 MHz
Dimensions………………………………………..(120mm)L x (60mm)W x (20mm)H
Weight……………………………………………..≤150 grams
TRANSMITTER
Sustained Transmission…………………………… Nominal conditions
Time: 5 10 30sec
Power: >95% >95% >90%
Frequency Error…………………………………..±2.5 ppm
Frequency Deviation:
25kHz Channel Spacing……………………..≤±5.0kHz,
12.5kHz Channel Spacing……………………≤±2.5kHz,
Audio Frequency Response………………………. Within +1/-3dB of 6dB octave
@300Hz to 2.55kHz for 12.5kHz C.S
@300Hz to 3.0khz for 25kHz C.S
Adjacent Channel Power
25kHz…………………………………………< 70 dBc @ Nominal Condition
<65 dBc @ Extreme Condition
12.5kHz ………………………………………< 60 dBc @ Nominal Condition
< 55 dBc @ Extreme Condition
Conducted Spurious Emission …………………….< -36 dBM
Modulation Sensitivity……………………………. 100mV RMS@60% peak Dev.
Hum & Noise:
25kHz Channel Spacing………………….….>40 dB (with no PSOPH)
- 4 -
12.5kHz Channel Spacing………………..……>36 dB (with POSPH)
Modulation Symmetry ……………………………..<10% Peak Dev@1kHz input
for nominal dev +20dB
Load Stability……………………………………No osc at >= 10:1 VSWR all
phase angles and suitable antenna
Nodestroyat>=20:1allphaseangle
RECEIVER
Sensitivity(12dB Sinad) ………………………….UHF <-117 dBm,
VHF<-1[email protected]
Amplitude Characteristic………………………….<±3dB
Adjacent Channel Selectivity:
25 kHz Channel Spacing …………………….≥70dB @ Nom.
12.5kHz Channel Spacing…………………….≥60dB@Nom.
Spurious Response Rejection………………………70dB
Image Response…………………………………… > 70 dB
IF Response ………………………………………. >70 dB
Others………………………………………………> 70 dB
Intermodulation Response Rejection………………≥65 dB
Conducted Spurious Emission @ Nominal Conditions………<-57 dBm
AF Distortion ………………………………………………....<5% @ Nom.,
<10%@ Extreme Condition
RX Hum & Noise:
25.0kHz CP……………………………………………< 40dB No PSOPH
12.5kHz CP ………………………………………..…< 40dB with PSOPH
- 5 -
Receiver Response Time …………………………….< 20ms
Squelch Opening sensitivity: ………………………-118dBm
Squelch Closing sensitivity ……………………….. -121dBm
Squelch Attack Time:
RF Level at Threshold ………………………… <40ms
RF Level at Threshold +20dB…………………<30ms
L.O. Frequency Temperature Stability…………….1 st <2.5 ppm,
2 nd <10 ppm for –30°C to +60°C
L.O. Frequency Aging Rate………………………….±2 ppm/year
REFERENCE CRYSTAL
Frequency…………………………………………………. 13MHz
Temperature Characteristic……………………………+/- 2.5PPM
from –30°C to +60°C
Aging Rate……………………………………………….< 2ppm/year in 1 st year
<1ppm/year thereafter
Lock Time …………………………………………………<10 ms
TX to RX ………………………………………………… < 20 ms
RX to TX ………………………………..……………….. < 25 ms
ENVIRONMENTAL ( performance without degradation unless stated)
Temperature……………………………………………… deg C
Operating………………………………………………….-30° to +60°C Degradation
Specified@Extreme
Storage …………………………………………………… -40°C to +80°C
- 6 -
Recharging ……………………………………………… -10 to +55
ESD………………………………………………………. 20kV (C-MIC >= 15kV)
Vibration………………………………………………… MIL STD 810 C Procedures I,II,V
and IEC68 26
·
Due to continuing researching and development the company reserves the
right to alter these specifications without prior notice.
- 7 -
FC-301/D CIRCUIT DIAGRAM
Fig.1. Circuit diagram
- 8 -
INTRODUCTION
The FC-301/D Series of RF Link Modules from Friendcom utilizes the latest
technology in its design and manufacturing. Both the UHF and VHF models
are PLL (Phase Lock Loop Synthesizer) / microprocessor controlled, and offer
one to five watts of power with 16 channel capability. Multiple functions
including AC audio coupling, 1200 to 9600 baud rates GMSK and FSK
modulation capability are standard in these fully programmable wide
bandwidth RF Link Module units.
FEATURES
●16 Channels
●1- 5 Watt Programmable Output
●12.5 / 25 kHz Programmable Channel Spacing
- 9 -
TROUBLE SHOOTING GUIDE
Table 1: Trouble shootings
SYMPTOM S
CAUSES
COUNTERMEASURES
Unit does not work
1.No power incomplete
connection
2. No input voltage of 5V or 8V
3. CPU does not work
4. EEPROM fail
5. Channel error
6. PLL error
1.Check COM1 connection
2. Check IC500、IC504
3. Check IC510
4. Check IC502
5. Check CF3
6. Check TCXO、VCO、PLL IC
Bad RX Sensitivity
1.Antenna signal short-circuit
2.Antenna signal open-circuit
3. Bad electronic turner
4. Defective high frequency
amplifier
5. Bad mixer
6. Local signal amplitude
become small
7. Bad 1st and 2nd intermediate
frequency
1. Check D106 D107
2. Antenna loose weld
3. Check L23 L24 L25 L26
4. Replace Q15
5. Check IC3 T3 T4
6. Check D103 Q111
7. Check XF1 XF2 IC2
Defective RX
1. No output signal
2. Bad signal waveform
3. Bad stability of VCO
1. Replace IC801
2. Check U2 c412 c404
3. Check component of VCO
PLL Error
1. TCXO frequency error
2. Bad stability of VCO
3. PLL can’t be locked
1.Check crystal oscillator of TCXO
2.Check the component of
TX/RXVCO
3. IC301 Q321 Q320 C327
Low TX Power
1. Bad amplifier circuit
2. Bad APC circuit
1. Replace IC102
2. Check D102 IC1
No TX Power
1. No power on TX
2. No signal on driver
3. Bad amplifier circuit
4. Bad APC circuit
1. Check Q502 Q503
2. Check Q1 Q2 D101
3. Check IC102 D102
4. Check IC1
No Modulation
1. No input signal
2. No TX signal
1. Check IC801
2. Check U1 R403 R404
