foxpeed AS8012 Manual de usuario
Model: AS8012
MIN
5 6 7 81 2 3 4
9
10
11 12 13
14
15 16
17
18
19 20 21
22
23 24
INCLUDED IN THIS STANDARD PACKAGE
FEATURES
PRECAUTIONS
MAINTENANCE&CARE
ILLUSTRATIONS OF THE DEVICE AND ACCESSORIES
MODES INSTRUCTION
RECOMMEND USE POSITIONS
OPERATING INSTRUCTIONS
TIPS FOR TENS UNIT PAD PLACEMENT
TROUBLESHOOTING
TRANSPORT AND STORAGE SYMBOLS
03
03
04
05
06
07
1 3
1 5
1 9
20
2 2
A/B dual independent channels,opeate their modes and
intensity level separately,enjoy 2 different massage at the same
time.
Multi-functional Tens Massager with 24 Preprogrammed
Massage Modes for Pain and Muscle Relief.
20 level intensity
20 minutes default timer, can adjustable from 10-90 minutes
Rechargeable lithium battery
Battery indicator to know when need to recharge battery
It is suggested that you do not use the massager on any given
areaof skin for a duration greater than 20 min 2 times per day.
Consult with your physician for longer or more frequent uses.
Device
1. When you are finished using the device, turn it off and take off
the pads. Store the unit in a cool, dry place until next use.
2. Please use a lightly moistened cloth to clean the device and
wipe gently.
3. Make sure the device is off when you clean it.
4. Do not let water to get into the device.
Pads
1. Make sure both pads not overlapping and make sure your skin is
free from any dirt, oil or lotion.
2. Applying a few drops of water before and after usage will
increase
the longevity of the pads.
3. Place pads on pad holder or place plastic film on the sticky side
of pad to keep the gel moisture.
4. Please replace the pads after using 15-20 times ( Varies widely
depending on use, body type and care).
NOTE: To purchase official replacement electrode pads, you can
find suitable pads on Amazon by search ASIN " B08G46HM4H " “Foxpeed
tens pads” or
HOW TO ORDER REPLACEMENT ELECTRODE PADS?
1. On/ off switch
2. Charging port
3. Timer
4. Battery indicator
5. LCD screen
6. A channel Intensity adjustment(+)
7. A channel Intensity adjustment(-)
8. B channel Intensity adjustment(+)
9. B channel Intensity adjustment(+)
10. 6 Main Modes adjustment
11. Time adjustment
56781234
9
10
11 12 13
14
15 16
17
18
19 20 21
22
23 24
12. 24 built-in Modes adjustment
13. Suspend & screen lock
14. Pad wires
15. Electrode pads 16. USB cable
14 15
16
MODES INSTRUCTION
TENS:Pain relief
To be used for temporary relief of pain associated with sore and
aching muscles in the shoulder, waist, back, upper extremities
(arm), and lower extremities (leg) due to strain from exercise or
normal household work activities.
EMS(also named PMS): Muscle conditioning
It is intended to be used to stimulate healthy muscles in order
to improve and facilitate muscle performance.
MASS(Massager): Relaxing body
It is intended to be used to relaxing body when you are tired.
TENS
①Angle scraping massage (45 degree angle scraping)
②Strong scraping massage (90 degree angle scraping)
③Acupuncture(gentle)
④Knock + Scrape
⑤ Lightly hammer
⑥
Stimulates circulation to end stasis, warms the channels to
relieve pain and eliminate toxins from the body. According to
traditional Chinese medical theory, scraping the skin can
stimulate one's immune system and then help to remove the
disorder.
Releases unhealthy elements from injured areas and
stimulates blood flow and healing.
This mode is used for the points on the Chinese meridian
pressure point chart to assist headaches, a variety of
ailments as well as muscle and joint pain. Particularly good
for fast relief of acute pain.
Provides the user with a beating and scraping sensation.
The appliance puts out quick and strong pulses in a regular
rhythm; good for all major muscle groups.
Stretching massage
For relieving back and neck pain, stiff muscles, anxiety,
fatigue, migraines, rheumatism, and even cellulite etc.
EMS
⑦
⑧
⑨
⑩
12
11
Kneading massage
For muscle strains, herniated discs, stenosis, spondylosis,
spondylolisthesis, and general arthritis pain.
Lifting massage
Relief of pain & muscle tension. Relieves the tension, brings
blood flow back to the joint and improves your mobility.
Tuina massage
Relief of pain & muscle tension. Relieves the tension, brings
blood flow back to the joint and improves your mobility.
Moxibustion (quick)
Knead gently (knead gently and slowly)
It helps chronic diseases such as insomnia, constipation,
headaches, and the tension associated with stress.
Provides the user with scratching and kneading sensation.
Releases unhealthy elements from injured areas and
stimulates blood flow and healing.
Slapping massage (quick slapping)
Helps to reduce muscle spasms, increase the range of
motion, injury recovery and the after surgery recovery.
13
14
15
16
Slow shot /Slow shot
The appliance puts out hard thumping sensation that
massage your muscles, which can give you an invigorated
and revitalized feeling.
Side palm kneading
It is a type of alternative medicine consisting of finger and
palm pressure, stretches, and other massages techniques.
Flat palm rub (slowly)
Enhance function, aid in the healing process, inhibit
motor-neuron excitability, decrease muscle reflex activity,
promote relaxation, recreational and well-being.
Flat palm kneading/gentle
Kneading massage (Kneading)
This mode is effective for joint pain, sciatica, muscle spasms,
and pain in the back, neck, and shoulders.
