Fortinet FortiGate 30D Manual de usuario

http://support.fortinet.com/

Toll free: 1 866 648 4638

Phone: 1 408 486 7899

Fax: 1 408 235 7737

Email: [email protected]

QuickStart Guide Video

http://forti.net/vqsg

Visit

https://

Visit

USB MGMT Port

FortiExplorer Setup Wizard

1. Follow prompts or click “Register” to register your device with FortiCare.

2. Click “Setup Wizard”.

3. Login using username “admin” and no password.

4. Follow Setup Wizard steps.

5. Click to complete the setup of your device.

Windows/OS X with USB

Microsoft Windows Install

2. Connect the USB cable and launch

FortiExplorer if it does not appear

automatically.

Mac OS X Install

2. Double-Click the  and drag

the FortiExplorer icon to the Applications

folder.

3. Connect the USB cable.

4. Click the FortiExplorer icon to launch

the application.

1. Download FortiExplorer from http://forti.net/fexp.

1110

Visit

http://forti.net/fexp-ios

USB Port

iPhone/iPad/iPod Touch with Apple USB cable

FortiExplorer App

1. Download the iOS FortiExplorer App to your device from http://forti.net/fexp-ios.

2. Use your Apple USB cable to connect to the USB port.

3. Launch the FortiExplorer App and select the device model.

4. Login using username “admin” and no password.



http://forticlient.com

1312

WAN (RJ-45)

FortiASIC-accelerated

Ethernet port

Internet

DC Power Jack

Device Guide

FortiGate/FortiWiFi 30D Non-PoE Models Only

Power

Off

WiFi (Wireless models only)

Active

Inactive

USB (USB-A)

Inserted

Not inserted

Status

Normal

Reset window

Fault

Booting up

USB (USB-A)

USB server port

USB MGMT (USB-B)

USB client port for management

LAN Ports 1 - 4 (RJ-45)

FortiASIC-accelerated switched

Ethernet ports for connection to

your network & the internet

Reset Button

Press and hold when Status



to factory defaults

WAN & LAN Ports 1 - 4

1G Link up

1G Link up & activity

10M/100M Link up

10M/100M Link up & activity

No Link

1514

USB (USB-A)

USB server ports

WAN (RJ-45)

FortiASIC-accelerated

Ethernet port

LAN Ports 1 - 4 (RJ-45)

FortiASIC-accelerated switched

Ethernet ports for connection to

your network & the internet

USB MGMT (USB-B)

USB client port for

management

Reset Button

Press and hold when Status



to factory defaults

DC Power Jack

Device Guide

FortiGate/FortiWiFi 30D PoE Models Only

Status

Normal

Reset Window

Booting up

WiFi (Wireless models only)

Active

Inactive

Power

Off

USB (USB-A)

Inserted

Not inserted

PoE

PD connected

PD not connected

PoE LAN Port 4

802.af, up to 15.4 W

Internet

WAN & LAN Ports 1 - 4

1G Link up

1G Link up & activity

10M/100M Link up

10M/100M Link up & activity

No Link

More Information

FortiGate Cookbook

Advanced installation and setup, networking, security policies



Authentication, Logging and reporting.

http://forti.net/cookbook

Training Services

Course descriptions, availability, schedules, and locations of

training programs in your area.

http://forti.net/training

CLI Reference



http://forti.net/cli

FortiOS Handbook



http://forti.net/handbook
