FOR-A MV-160HS Multi Viewer Manual de usuario

MV-160HS

Multi Viewer

2nd Edition

OPERATION

MANUAL

Precautions

Important Safety Warnings

[Power]

Operate unit only on the specified supply voltage.

Disconnect power cord by connector only. Do not pull on cable portion.

Do not place or drop heavy or sharp-edged objects on power cord. A damaged cord

can cause fire or electrical shock hazards. Regularly check power cord for

excessive wear or damage to avoid possible fire / electrical hazards.

[Grounding]

Ensure unit is properly grounded at all times to prevent electrical shock hazard.

Do not ground the unit to gas lines, units, or fixtures of an explosive or dangerous

nature.

Ensure power cord is firmly plugged into AC outlet.

[Operation]

Do not operate unit in hazardous or potentially explosive atmospheres. Doing so

could result in fire, explosion, or other dangerous results.

Do not allow liquids, metal pieces, or other foreign materials to enter the unit. Doing

so could result in fire, other hazards, or unit malfunction.

If foreign material does enter the unit, turn power off and disconnect power cord

immediately. Remove material and contact authorized service representative if

damage has occurred.

[Transportation]

Handle with care to avoid shocks in transit. Shocks may cause malfunction. When

you need to transport the unit, use the original packing materials or alternate

adequate packing.

Stop

Caution

Hazard

Caution

Hazard

Caution

[Circuitry Access]

Do not remove covers, panels, casing, or access circuitry with power applied to the

unit! Turn power off and disconnect power cord prior to removal. Internal servicing /

adjustment of unit should only be performed by qualified personnel.

Do not touch any parts / circuitry with a high heat factor.

Capacitors can retain enough electric charge to cause mild to serious shock, even

after power is disconnected. Capacitors associated with the power supply are

especially hazardous. Avoid contact with any capacitors.

Unit should not be operated or stored with cover, panels, and / or casing removed.

Operating unit with circuitry exposed could result in electric shock / fire hazards or

unit malfunction.

[Potential Hazards]

If abnormal smells or noises are noticed coming from the unit, turn power off

immediately and disconnect power cord to avoid potentially hazardous conditions. If

problems similar to above occur, contact authorized service representative before

attempting to again operate unit.

[Consumables]

The consumables used in unit must be replaced periodically. For further details on

which parts are consumables and when they should be replaced, refer to the

specifications at the end of the Operation Manual. Since the service life of the

consumables varies greatly depending on the environment in which they are used,

they should be replaced at an early date. For details on replacing the consumables,

contact your dealer.

[Rubber Feet]

If this product has come with rubber feet attached by screws, do not insert the

screws again without rubber feet after removing the rubber feet and screws. It may

cause damage to the internal circuits or components of the unit. To install the rubber

feet again to the unit, do not use other than the supplied rubber feet and screws.

Caution

Hazard

Stop

Caution

Upon Receipt

Unpacking

The MV-160HS units and their accessories are fully inspected and adjusted prior to shipment.

Operation can be performed immediately upon completing all required connections and

operational settings.

Check your received items against the packing lists below.

ITEM QTY REMARKS

MV-160HS 1

Rack Mount Brackets 1 set

AC Cable 1

AC Cable fook 1

Operation Manual 1 set This manual

Option

ITEM QTY REMARKS

MV-160OUT 1 DVI/VGA Output Board

MV-160PS 1 Redundant Power Unit

Check

Check to ensure no damage has occurred during shipment. If damage has occurred, or items

are missing, inform your supplier immediately.

Table of Contents

1. Prior to Starting ...........................................................................................................................1

1-1. Welcome.............................................................................................................................1

1-2. About the MV-160HS ..........................................................................................................1

1-3. About This Manual ..............................................................................................................2

2. Panel Descriptions......................................................................................................................3

2-1. Front Panel .........................................................................................................................3

2-2. Rear Panel..........................................................................................................................4

3. Split Screen Patterns and Window Layout..................................................................................5

3-1. Split Screen Patterns ..........................................................................................................5

3-2. Group Output ......................................................................................................................6

3-3. Window Display Layout.......................................................................................................7

4. Operating Procedure...................................................................................................................8

4-1. Operation at Startup............................................................................................................8

4-2. Displaying Full Screen ........................................................................................................8

4-3. Displaying Split Screen .......................................................................................................9

4-4. Assigning Input Video to Window......................................................................................10

4-5. Setting Window Display ....................................................................................................11

4-5-1. Adding Title ...............................................................................................................11

4-5-2. Adding Frame Marker ...............................................................................................13

4-5-3. Adding Audio Level Meter .........................................................................................13

4-5-4. Using Copy Function.................................................................................................14

4-6. Tally Settings.....................................................................................................................15

4-7. Using User Pattern Function.............................................................................................16

4-8. GROUP Menu Settings.....................................................................................................16

4-8-1. GROUP Window Display Layout Settings.................................................................16

4-8-2. GROUP Window Full/Quad Display Settings............................................................17

4-8-3. Border Settings .........................................................................................................18

4-8-4. Delinking Window and GROUP Window Settings.....................................................18

5. System Settings........................................................................................................................20

5-1. Selecting Video Format.....................................................................................................20

5-2. System Initialization ..........................................................................................................20

6. Menus.......................................................................................................................................21

6-1. WINDOW Menu ................................................................................................................21

6-2. GROUP Menu...................................................................................................................23

6-3. SYSTEM Menu .................................................................................................................24

7. External Control........................................................................................................................ 25

7-1. Tally Input (TALLY IN)....................................................................................................... 25

7-2. Remote Control (REMOTE) ............................................................................................. 27

7-3. Control via RS-232C ........................................................................................................29

8. System Block Diagram ............................................................................................................. 30

9. Optional Functions ................................................................................................................... 31

9-1. MV-160OUT (DVI/VGA Output)........................................................................................ 31

9-2. Selecting Resolution......................................................................................................... 31

9-3. DVI Output ....................................................................................................................... 32

9-4. VGA Output ...................................................................................................................... 33

10. Specifications & Dimensions .................................................................................................. 34

10-1. Unit Specifications.......................................................................................................... 34

10-2. External Dimensions ...................................................................................................... 36

1. Prior to Starting

1-1. Welcome

Congratulations! By purchasing MV-160HS Multi Viewer you have entered the world of FOR-A

and its many innovative products. Thank you for your patronage and we hope you will turn to

FOR-A products again and again to satisfy your video and audio needs.

FOR-A provides a wide range of products, from basic support units to complex system

controllers, which have been increasingly joined by products for computer video based systems.

Whatever your needs, talk to your FOR-A representative. We will do our best to be of continuing

service to you.

1-2. About the MV-160HS

The MV-160HS is a 16-split multi viewer that accepts up to 16 HD/SD-SDI signals.

The embedded audio level meter can be displayed for each input, so that it is easy to see the

audio signal is or is not present. It also supports 7 preset display patterns including 16-split

screen. These features make MV-160HS the most ideal for monitoring HD/SD-SDI video

signals and audio signals.

Features

 Accepts both HD-SDI and SD-SDI signals.

 Capable of displaying embedded audio level meter. (Up to four channels)

 Supported outputs;

 HD/SD-SDI output

 DVI (option)

 VGA (option)

 All 16 input videos can be fed to any selected split window

 Tally display function:

 Frame and marker display

 Title display with up to 8 characters (alphanumeric and symbol)

 Enabled external control over the remote control terminal or RS-232C interface

 Multiple split screen patterns

*Numbers in each window indicate WINDOW numbers.

16 split

Quad

1 2 3 4

5 6 7 8

9 10 11 12

13 14 15 16

3 4

GRP1 7 8

9 10 11 12

13 14 15 16

1 2

GRP2

5 6

9 10 11 12

13 14 15 16

1 2 3 4

5 6 7 8

GRP3 11 12

15 16

1 2 3 4

5 6 7 8

9 10 GRP4

13 14

GRP1 GRP2

GRP3 GRP4

12+ GRP1 split

12+ GRP3 split

12+ GRP2 split

12+ GRP4 split

1-3. About This Manual

This manual is intended to help the user easily operate the MV-160HS and make full use of its

functions during operations. Before connecting or operating your unit, read this operation

manual thoroughly to ensure you understand the product. After reading, it is important to keep

this manual in a safe place and available for reference.

Font Conventions

The following conventions are used through out this manual:

 Circled text (for example ENTER) is used for buttons.
