Fluke MT4 MAX Manual de usuario

MT4 MAX/MT4 MAX+/

MT4 MAX IND/

59E/59E+

Infrared Thermometer

PN 4326561 (English)

August 2013 Rev. 2, 5/2022

All Product names are trademarks of their respective companies.

Users Manual

LIMITED WARRANTY AND LIMITATION OF LIABILITY

The Fluke MT4 MAX, MT4 MAX+, 59E, and 59E+ Infrared Thermometers will be free from defects

in material and workmanship for 1 year from the date of purchase. The MT4 MAX IND Infrared

Thermometer will be free from defects in material and workmanship for 5 years from the date of

purchase. This warranty does not cover fuses, disposable batteries, or damage from accident,

neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.

Resellers are not authorized to extend any other warranty on Fluke’s behalf. To obtain service

during the warranty period, contact your nearest Fluke authorized service center to obtain return

authorization information, then send the product to that Service Center with a description of the

problem.

THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH AS FITNESS FOR A

PARTICULAR PURPOSE, ARE EXPRESSED OR IMPLIED. FLUKE IS NOT LIABLE FOR ANY SPECIAL,

INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM ANY

CAUSE OR THEORY. Since some states or countries do not allow the exclusion or limitation of an

implied warranty or of incidental or consequential damages, this limitation of liability may not

apply to you.

11/99

Fluke Corporation

P.O. Box 9090

Everett, WA 98206-9090

U.S.A.

Fluke Europe B.V.

P.O. Box 1186

5602 BD Eindhoven

The Netherlands

制造商：安徽世福仪器有限公司

生产地址：安徽省芜湖市鸠江经济开

发区龙腾路66号

电话：0553-5610888

Table of Contents

Title Page

Introduction ............................................................................................................................................. 1

Contact Fluke.......................................................................................................................................... 1

Safety Information................................................................................................................................. 2

Maintenance............................................................................................................................................ 5

How to Change the Battery...................................................................................................... 5

How to Clean the Product ........................................................................................................5

Product Disposal ................................................................................................................................... 6

Specifications ......................................................................................................................................... 6

Nominal Surface Emissivity ............................................................................................................... 10

The Product ............................................................................................................................................. 11

MT4 MAX/MT4 MAX+/MT4 MAX IND/59E/59E+

Users Manual

Introduction

The Fluke MT4 MAX, MT4 MAX+, MT4 MAX IND, 59E, and 59E+ Infrared Thermometers (the

Product) can determine the surface temperature by measuring the amount of infrared energy

radiated by the target’s surface.

Contact Fluke

Fluke Corporation operates worldwide. For local contact information, go to our website:

www.fluke.com.

To register your product, or to view, print, or download the latest manual or manual supplement,

go to our website.

+1-425-446-5500 fluke-info@fluke.com

Fluke Corporation

P.O. Box 9090

Everett WA 98206-9090

U.S.A.

Fluke Europe B.V.

P.O. Box 1186

5602 BD Eindhoven

The Netherlands

MT4 MAX/MT4 MAX+/MT4 MAX IND/59E/59E+

Users Manual

Safety Information

A Warning identifies hazardous conditions and procedures that are dangerous to the user. A

Caution identifies conditions and procedures that can cause damage to the Product or the

equipment under test.

Warning

To prevent possible electrical shock, fire, or personal injury:

Read all safety information before you use the Product.

Do not alter the Product and use only as specified, or the protection supplied by the

Product can be compromised.

Carefully read all instructions.

Do not use the Product if it operates incorrectly.

Do not use the Product around explosive gas, vapor, or in damp or wet environments.

Have an approved technician repair the Product.

Examine the case before you use the Product. Look for cracks or missing plastic.

Carefully look at the insulation around the terminals.

Infrared Thermometer

Safety Information

Do not look directly into the laser with optical tools (for example, binoculars,

telescopes, microscopes). Optical tools can focus the laser and be dangerous to the

eye.

Do not look into the laser. Do not point laser directly at persons or animals or

indirectly off reflective surfaces.

Use the Product only as specified or hazardous laser radiation exposure can occur.

See emissivity information for actual temperatures. Reflective objects result in lower

than actual temperature measurements. These objects pose a burn hazard.

Replace the batteries when the low battery indicator shows to prevent incorrect

measurements.

Remove the batteries if the Product is not used for an extended period of time, or if

stored in temperatures above 50 °C. If the batteries are not removed, battery

leakage may result.

Repair the Product before use if the battery leaks. Battery leakage may create a

shock hazard or damage the Product.

Be sure that the battery polarity is correct to prevent battery leakage.

MT4 MAX/MT4 MAX+/MT4 MAX IND/59E/59E+

Users Manual

Symbol Description

Consult user documentation.

WARNING. RISK OF DANGER.

Conforms to European Union directives.

Battery

WARNING. LASER RADIATION. Risk of eye damage.

Indicates a Class 2 laser. DO NOT STARE INTO BEAM The following text may

appear with the symbol on the product label: “IEC/EN 60825-1:2014.

Complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to

Laser Notice 50, dated June 24, 2007.” In addition, the following pattern on

the label will indicate wavelength and optical power: λ= xxxnm, x.xxmW.



This product complies with the WEEE Directive and its marking requirements.

The affixed label indicates that you must not discard this electrical/electronic

product in domestic household waste. Do not dispose of this product as

unsorted municipal waste. For information about take-back and recycling

programs available in your country, see the Fluke website.

Infrared Thermometer

Maintenance

Warning

To prevent possible electrical shock, fire, or personal injury, have an approved

technician repair the Product.

Caution

To avoid damage to the Product, do not leave the thermometer on or near objects of

high temperature.

How to Change the Battery

To install or change the AA IEC LR06 battery, open the battery compartment and replace the

battery as shown in Figure 16.

How to Clean the Product

Use soap and water on a damp sponge or soft cloth to clean the Product case. Carefully wipe the

surface with a moist cotton swab. The swab may be moistened with water. See Figure 17.

MT4 MAX/MT4 MAX+/MT4 MAX IND/59E/59E+

Users Manual

Product Disposal

Dispose of the Product in a professional and environmentally sound manner:

Delete personal data on the Product before disposal.

Remove batteries that are not integrated into the electrical system before disposal and

dispose of batteries separately.

If this Product has an integral battery, put the entire Product in the electrical waste.

Specifications

MT4 MAX/59E MT4 MAX IND MT4 MAX+/59E+

Temperature Range -30 °C to 350 °C

(-22 °F to 662 °F) -30 °C to 400 °C (-22 °F to 752 °F)

Accuracy (Calibration

geometry with

ambient temperature

23 °C ±2°C)

≥0°C: ±2.0 °C (≥32 °F: ±4.0 °F) or

±2.0 % of reading, whichever is

greater

≥0°C: ±1.5 °C (≥32 °F: ±3.0 °F) or

±1.5 % of reading, whichever is

greater

≥-10 °C to <0 °C: ±2.0 °C (≥14 °F to <32 °F: ±4.0 °F)

<-10 °C: ±3.0 °C (<14 °F: ±6.0 °F)
