Fluke 365 Manual de usuario

PN 3622684

August 2010

change without notice. All product names are trademarks of their respective companies.

365

Detachable Jaw

True-rms

Clamp Meter

Users Manual

Shop for Fluke products online at: 1.888.610.7664

www.MyFlukeStore.com

LIMITED WARRANTY AND LIMITATION OF LIABILITY

This Fluke product will be free from defects in material and workmanship for three years from the

date of purchase. This warranty does not cover fuses, disposable batteries, or damage from

accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or

handling. Resellers are not authorized to extend any other warranty on Fluke’s behalf. To obtain

service during the warranty period, contact your nearest Fluke authorized service center to obtain

return authorization information, then send the product to that Service Center with a description of

the problem.

THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH AS FITNESS

FOR A PARTICULAR PURPOSE, ARE EXPRESSED OR IMPLIED. FLUKE IS NOT LIABLE

FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSES,

ARISING FROM ANY CAUSE OR THEORY. Since some states or countries do not allow the

exclusion or limitation of an implied warranty or of incidental or consequential damages, this

limitation of liability may not apply to you.

11/99

Shop for Fluke products online at: 1.888.610.7664

www.MyFlukeStore.com

Table of Contents

Title Page

Introduction................................................................................................................. 1

Contact Fluke ............................................................................................................. 2

Safety Information ...................................................................................................... 2

The Meter ................................................................................................................... 7

Specifications ............................................................................................................. 14

Electrical Specifications.......................................................................................... 14

Mechanical Specifications ...................................................................................... 15

Environmental Specifications ................................................................................. 16

Shop for Fluke products online at: 1.888.610.7664

www.MyFlukeStore.com

Introduction

Warning

Read "Safety Information" before you use the Meter.

The Fluke 365 is a true-rms hand-held, battery-operated clamp meter (the Meter) that features a

detachable Jaw. The Meter measures:

•ac and dc current

•ac and dc voltage

•resistance

•continuity

The Meter ships with:

•TL75 or TL175 test leads

•carrying case

•two AA batteries (installed)

•magnetic hanger

•365 User Manual

Shop for Fluke products online at: 1.888.610.7664

www.MyFlukeStore.com

365

Users Manual

Safety Information

A Warning identifies conditions and actions that pose hazard(s) to the user. A Caution identifies

conditions and procedures that could cause Meter damage, equipment under test damage, or

permanent loss of data.

Symbols used on the Meter and in this manual are explained in Table 1.

Shop for Fluke products online at: 1.888.610.7664

www.MyFlukeStore.com

Detachable Jaw True-rms Clamp Meter

Safety Information

Warning

To prevent possible electrical shock or personal injury, follow these guidelines:

•Use the Meter only as specified in this manual or the protection provided by the

Meter can be compromised.

•Examine the case before you use the Meter. Look for cracks or missing plastic.

Carefully look at the insulation around the connectors.

•Never measure current while the test leads are inserted into the input jacks.

•Make sure the battery door is closed and latched before operating the Meter.

•Remove the test leads from the Meter before the battery door is opened.

•Examine the test leads for damaged insulation or exposed metal. Check test lead

continuity. Replace damaged test leads before using the Meter.

•Do not use the Meter if it operates incorrectly. Protection can be compromised.

When in doubt, have the Meter serviced.

•Do not use the Meter around explosive gas, vapor or in damp or wet

environments.

•Use only type AA batteries, properly installed in the Meter case, to power the

Meter.

•When measuring, keep fingers behind the Tactile Barrier. See "The Meter" .

•To avoid false readings that can lead to electrical shock and injury, replace the

batteries as soon as the low battery indicator () appears.

•When servicing the Meter, use only specified replacement parts.

Shop for Fluke products online at: 1.888.610.7664

www.MyFlukeStore.com

365

Users Manual

•Have the Meter serviced only by qualified service personnel.

•Be careful around voltages >30 V ac rms, 42 V ac peak, or 60 V dc. Such voltages

pose a shock hazard.

•Do not apply more than the rated voltage, as marked on the Meter, between the

terminals or between any terminal and earth ground.

•When using the probes, keep fingers behind the finger guards on the probes.

•Connect the common test lead before connecting the live test lead. When

disconnecting test leads, disconnect the live test lead first.

•Do not work alone so assistance can be rendered in an emergency.

•Use extreme caution when working around bare conductors or bus bars. Contact

with the conductor could result in electric shock.

•Adhere to local and national safety codes. Individual protective equipment must

be used to prevent shock and arc blast injury where hazardous live conductors

are exposed.

•Disconnect circuit power and discharge all high-voltage capacitors before you

do diode tests or measure resistance or continuity.

•Do not measure ac/dc current in circuits carrying more than 600 V or 200 A with

the Meter Jaw.

•Never operate the Meter with the back cover removed or the case open.

Shop for Fluke products online at: 1.888.610.7664

www.MyFlukeStore.com

Detachable Jaw True-rms Clamp Meter

Safety Information

Caution

To avoid possible damage to the Meter or to equipment under test:

•Use the proper jacks, function, and range for the measurement application.

•Clean the case and accessories with a damp cloth and mild detergent only.

Do not use abrasives or solvents.

Table 1. Symbols

Symbol Meaning Symbol Meaning

AC (Alternating Current) Earth ground

DC (Direct Current) AC and dc current.

Hazardous voltage Risk of Danger. Important

information. See Manual.



Battery. Low battery when shown.

The Meter shuts down when the

battery reaches 2.0 V. Double insulated



Do not dispose of this product as

unsorted municipal waste. Go to

Fluke’s website for recycling

information.

Conforms to relevant North American

Safety Standards.

Shop for Fluke products online at: 1.888.610.7664

www.MyFlukeStore.com

365

Users Manual

Symbol Meaning Symbol Meaning

CAT III

IEC Measurement Category III

CAT III equipment has protection

against transients in equipment in

fixed-equipment installations, such

as distribution panels, feeders and

short branch circuits, and lighting

systems in large buildings.

Application around and removal from

HAZARDOUS LIVE conductors is

permitted.

Conforms to European Union

directives. Examined and licensed by TÜV

Product Services.

Conforms to relevant Australian standards.

Note

The Measurement Category (CAT) and voltage rating of any combination of test probe,

test probe accessory, current clamp accessory, and the Meter is the LOWEST rating of

any individual component.

Shop for Fluke products online at: 1.888.610.7664

www.MyFlukeStore.com

Detachable Jaw True-rms Clamp Meter

The Meter

Clamp Meter

fig01.eps
