Fluke 1742 Manual de usuario
1742/1746/1748
3 Phase Power Quality Logger
Introduction,
Before You Start,
Terms to Know
PN 5041162
February 2020
©2020 Fluke Corporation. All rights reserved. Specifications are subject to change without
notice. All product names are trademarks of their respective companies.
FLUKE CONNECT® APPLICATION AND SERVICES
END USER LICENSE AGREEMENT (EULA) AND SERVICES
AGREEMENT
For complete details, go to https://connect.fluke.com/eula.
Visit Fluke's website at www.fluke.com.
To register your product, visit http://register.fluke.com.
To view, print, or download the latest manual supplement, visit
http://us.fluke.com/usen/support/manuals.
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
U.S.A.
Fluke Europe B.V.
P.O. Box 1186
5602 BD Eindhoven
The Netherlands
ООО «Флюк СИАЙЭС»
125167, г. Москва,
Ленинградский проспект дом 37,
корпус 9, подъезд 4, 1 этаж
3
2
3 4
1
6
5
7
8
4
Introduction
With the wireless connectivity (WiFi) feature of the Product, you can:
•
Configure the Logger, verify measurement, and set up a logging session with
Energy Analyze Plus PC software and the Fluke Connect smartphone app
•
Download data to Energy Analyze Plus PC software
•
Stream all data to the Fluke Connect Cloud
•
Manage assets and share data with the Fluke Connect smartphone app
•
Receive alarm notification from a remote monitoring session
Before You Start
What you need:
Android or iOS smartphone (go to https://www.fluke.com/en-us/support/fluke-
connect-frequently-asked-questions to find a list of supported devices)
Internet access
WiFi-Infrastructure license that enables Logger connection with WiFi access
points for remote monitoring through WiFi (provided with Product registration)
USB Drive (included with Product)
Power Quality Logger (the Product or Logger)
PC
USB Cable A, mini-USB
Energy Analyze Plus Software (go to https://www.fluke.com/en-us/support/
software-downloads for the latest software update)
During this setup you will need to document the Login name and password for:
•
Power Quality Logger
•
Fluke Connect app
•
WiFi Password (for the Logger)
•
WiFi SSID and password for the Internet WiFi Access Point (or use an
Ethernet connection)
5
3 Phase Power Quality Logger
Terms to Know
Definitions of terms used in this document:
WLAN A wireless local area network (WLAN) is a wireless
distribution method for two or more devices that use
high-frequency radio waves and often include an
access point to the Internet. A WLAN allows you
maintain a network connection as you move around
the coverage area, often a home or small office.
WiFi Hotspot With the built in USB WiFi Adapter, the Logger is a
WiFi hotspot for:
•
wireless control of the Logger
•
download of measurement data
The WiFi direct connection uses WPA2-PSK (pre-
shared key) with AES encryption.
WiFi Infrastructure WiFi Infrastructure mode is how you connect your
devices using a wireless access point as a central
device. To join the WLAN, all wireless clients must be
configured to use the SSID of the access point. The
access point is then connected with the wired
network to allow wireless clients access to, for
example, Internet connections.
With a second WiFi-to-USB adapter the Logger can
connect to a WiFi access point and supports
WPA2 PSK security as well as no security. This
connection requires a DHCP service running in the
access point to assign IP addresses automatically.
6
1742/1746/1748
Instructions
Terms to Know
Local Logging Logger mode starts a session to store all
measurement data on the Logger.
Remote Monitoring All measurement data is transferred in real-time to
the Fluke Connect Cloud for secure storage.
Measurement data is also available on the Logger
(limited by the internal data storage size) for
download to Energy Analyze Plus software. From the
cloud, your team has access from anywhere to
measurement data with a supported mobile device or
PC web browser. Only Team users defined in Fluke
Connect can access this data.
To sync data to the Fluke Connect Cloud, the Logger
must be connected to a WiFi access point or Local
Area Network with Internet access. WiFi connection
requires a DHCP service running in the access point
to assign IP addresses automatically.
