Process & Temperature Meter

LI5X

Instruction Manual

• Accepts Current, Voltage, TC, & RTD Inputs

• 4 Digit Display, 0.56" (14 mm) High, Red LEDs

• Linear or Square Root with Low-Flow Cutoff

• Maximum/Minimum Display

• UL Type 4X, NEMA 4X, IP65 Front

• Universal Power Supply 85-265 VAC

• 12-36 VDC/12-24 VAC Power Option

• Two Relays or 4-20 mA Output Option

• 24 VDC Transmitter Power Supply Options

• Serial Communication Adapters

RS-232 & RS-422/485 Options

• Modbus®RTU Option

• Copy Meter Settings to Other Meters

• MeterView®Software - Configuration & Data Acquisition

Sunlight

Readable

Display!

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

LI5X Process & Temperature Meter Instruction Manual

All trademarks mentioned in this document are the property of their re-

spective owners.

Visit our Web Site

http://www.flowline.com

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

LI5X Process & Temperature Meter Instruction Manual

INTRODUCTION

The LI5X is a multipurpose, easy to use digital panel meter. It accepts

current, voltage, thermocouple, and RTD signals. The four front panel

buttons make the setup and programming an easy task.

The isolated 24 VDC transmitter power (optional) can be used to power

the input transmitter, the 4-20 mA output, or other devices.

The two relays (optional) can be used for alarm indication or process con-

trol applications, such as pump alternation control.

The 4-20 mA isolated output and the Modbus RTU serial communication

options make the LI5X an excellent addition to any system.

ORDERING INFORMATION

Model Options

LI50-1001 24 VDC Transmitter Power Supply

LI50-1001-MB 24 VDC Transmitter Power Supply, Modbus

LI51-1001 2 Relays, 24 VDC Transmitter Power Supply

LI51-1001-MB 2 Relays, 24 VDC Transmitter Power Supply, Modbus

LI52-1001 4-20 mA Output, 24 VDC Transmitter Power Supply

LI52-1001-MB 4-20 mA Output, 24 VDC Transmitter Power Supply, Modbus

Accessories

Model Description

LM91-1001 Low cost NEMA 4X Enclosure for LI5X Meter

LI97-1001-232 RS-232 Serial Adapter

LI97-1001-S01 MeterView®Software for 1 Meter

LI97-1001-S02 MeterView®Software for up to 10 Meters

LI97-1001-S03 MeterView®Software for up to 100 Meters

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

LI5X Process & Temperature Meter Instruction Manual

Table of Contents

INTRODUCTION ------------------------------------------------------------ 3

ORDERING INFORMATION --------------------------------------------- 3

SPECIFICATIONS---------------------------------------------------------- 7

General-------------------------------------------------------------------------------7

Process Input ----------------------------------------------------------------------8

Temperature Inputs -------------------------------------------------------------- 9

Relays Option-------------------------------------------------------------------- 10

Isolated 4-20 mA Transmitter Output ------------------------------------ 11

Serial Communications------------------------------------------------------- 11

COMPLIANCE INFORMATION ----------------------------------------12

Safety ------------------------------------------------------------------------------- 12

Electromagnetic Compatibility--------------------------------------------- 12

SAFETY INFORMATION ------------------------------------------------13

INSTALLATION ------------------------------------------------------------14

Unpacking------------------------------------------------------------------------- 14

Panel Mounting------------------------------------------------------------------ 14

Connections---------------------------------------------------------------------- 15

Connector Labeling ---------------------------------------------------------- 15

Power Connections ---------------------------------------------------------- 15

Signal Connections ---------------------------------------------------------- 16

Serial Communication ------------------------------------------------------- 19

Relays and 24 V Output Connections ----------------------------------- 19

Switching Inductive Loads-------------------------------------------------- 20

4-20 mA Output & Input Signal Connections -------------------------- 21

SETUP AND PROGRAMMING ----------------------------------------22

Front Panel Buttons and Status LED Indicators --------------------- 23

Display Functions and Messages----------------------------------------- 24

Main Menu ------------------------------------------------------------------------ 27

Setting Numeric Values ------------------------------------------------------ 28

Setting Up the Meter (setu) ------------------------------------------------- 29

Setting the Input Signal (inpt) -------------------------------------------- 30

Setting the Decimal Point (dc.pt) ----------------------------------------- 31

Setting the Temperature Scale (F C) ---------------------------------- 31

Setting the Relay Operation (rely) -------------------------------------- 32

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

LI5X Process & Temperature Meter Instruction Manual

Relay and Alarm Operation ------------------------------------------------ 35

Scaling the 4-20 mA Analog Output (Aout) ---------------------------- 41

Program the Sensor Break Output Value (SEbr) --------------------- 42

Analog Output when Display is Out of Range------------------------- 42

Programming the Meter (prog)--------------------------------------------- 43

Scaling the Meter (scal)---------------------------------------------------- 44

Calibrating the Meter (Cal)------------------------------------------------- 46

Recalibrating Temperature Inputs (Cal) -------------------------------- 46

Recalibrating Process Inputs (ICal)------------------------------------- 47

Setting Up the Password (pass) ------------------------------------------- 48

Locking the Meter ------------------------------------------------------------ 48

Unlocking the Meter---------------------------------------------------------- 48

Advanced Features Menu---------------------------------------------------- 50

Advanced Features Menu & Display Messages ---------------------- 51

Offset Adjustment (Adj)----------------------------------------------------- 53

Noise Filter (fltr)------------------------------------------------------------ 53

Noise Filter Bypass (byps) ------------------------------------------------- 54

Serial Communications (serl) -------------------------------------------- 54

Select Menu (SElc) ---------------------------------------------------------- 55

Linear or Square Root Function (linr or Sqrt) ---------------------- 55

Low-Flow Cutoff (cutF) ----------------------------------------------------- 56

Display Intensity (inty) ----------------------------------------------------- 56

Meter Copy Function (Copy) ----------------------------------------------- 57

Internal Calibration (ICal)-------------------------------------------------- 59

OPERATION ----------------------------------------------------------------62

Front Panel Buttons Operation -------------------------------------------- 62

Maximum/Minimum Readings---------------------------------------------- 63

MOUNTING DIMENSIONS ----------------------------------------------64

TROUBLESHOOTING----------------------------------------------------65

Diagnostics Menu (diag)----------------------------------------------------- 65

Determining Software Version -------------------------------------------- 65

Reset Meter to Factory Defaults ------------------------------------------- 66

Factory Defaults & User Settings----------------------------------------- 67

Troubleshooting Tips --------------------------------------------------------- 69

QUICK USER INTERFACE REFERENCE GUIDE----------------70

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

LI5X Process & Temperature Meter Instruction Manual

Table of Figures

Figure 1. Panel Cutout and Mounting............................................... 14

Figure 2. Connector Labeling for Two Relays & 24 V Supply......... 15

Figure 3. Power Connections ............................................................ 15

Figure 4. Transmitter Powered by Ext. Supply or Self-Powered .... 16

Figure 5. Transmitters Powered by Internal Supply (Optional) ...... 16

Figure 6. Voltage Input Connections ................................................ 17

Figure 7. Thermocouple Input Connections ....................................17

Figure 8. Three-Wire RTD Input Connections .................................. 18

Figure 9. Two-Wire RTD Input Connections..................................... 18

Figure 10. Four-Wire RTD Input Connections.................................. 19

Figure 11. Relay & 24 V Output Connections................................... 19

Figure 12. AC and DC Loads Protection........................................... 20

Figure 13. Low Voltage DC Loads Protection .................................. 20

Figure 14. 4-20 mA Output & Input Signal Powered by Meter ........ 21

Figure 15. 4-20 mA Output Powered Externally............................... 21

Figure 16. Meter Copy Connection ................................................... 57

Figure 17. Meter Dimensions – Side View ........................................ 64

Figure 18. Case Dimensions - Top View........................................... 64

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

LI5X Process & Temperature Meter Instruction Manual

SPECIFICATIONS

Except where noted all specifications apply to operation at +25°C.

General

DISPLAY 0.56" (14 mm) high, red LED

Four digits (-1999 to 9999), automatic lead zero blanking.

DISPLAY INTENSITY Eight intensity levels

DISPLAY

UPDATE RATE

Process/RTD: 3.7-5/second

Thermocouple: 1.8-2.5/second

OVERRANGE Display flashes 9999

UNDERRANGE Display flashes -1999

PROGRAMMING

METHODS

Four front panel buttons, PC and MeterView®software, or

cloning using Copy function

NOISE FILTER Programmable from 2 to 199 (0 will disable filter)

RECALIBRATION All ranges are calibrated at the factory. Recalibration is

recommended at least every 12 months.

MAX/MIN

DISPLAY

Max/min readings reached by the process are stored until

reset by the user or until power to the meter is turned off.

PASSWORD Programmable password restricts modification of

programmed settings.

NON-VOLATILE

MEMORY

All programmed settings are stored in non-volatile memory

for a minimum of ten years if power is lost.

POWER AC: 85-265 VAC, 50/60 Hz, 20 VA

DC: 90-265 VDC, 20 Watts

FUSE Required fuse: UL Recognized, 5 A max, slow blow

Up to 6 meters may share one 5 A fuse

ISOLATED

TRANSMITTER

POWER SUPPLY

24 VDC ±10% @ 200 mA max. (-1 option)

NORMAL MODE

REJECTION

64 dB at 50/60 Hz

ISOLATION 4 kV input/output-to-power line

500 V input-to-output, output-to-P1

OVERVOLTAGE

CATEGORY

Installation Overvoltage Category II:

Local level with smaller transient overvoltages than Instal-

lation Overvoltage Category III.

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

LI5X Process & Temperature Meter Instruction Manual

ENVIRONMENTAL Operating temperature range: 0 to +65°C

Storage temperature range: -40 to +85°C

Relative humidity: 0 to 90% non-condensing

CONNECTIONS Removable screw terminal blocks accept 12 to 26 AWG

wire, RJ11 for serial communication adapters

ENCLOSURE 1/8 DIN, high impact plastic,

UL 94V-0, color: gray

MOUNTING 1/8 DIN panel cutout required. Two panel mounting

bracket assemblies provided

TIGHTENING

TORQUE

Screw terminal connectors: 4.5 lb-in (0.5 Nm)

OVERALL

DIMENSIONS

2.45" x 4.68" x 4.19" (62 mm x 119 mm x 106 mm)

(H x W x D)

WEIGHT 8.0 oz (227 g) (no options)

9.7 oz (275 g) (2 relays & 24 V transmitter supply options)

WARRANTY 2 years parts and labor

Process Input

INPUTS Field selectable:

±20 mADC (0-20, 4-20 mA) and ±10 VDC (0-5, 1-5, 0-10 V)

ACCURACY ±0.05% of span ±1 count, square root: 10-100% F.S.

LOW-FLOW

CUTOFF

0-9999 (0 disables cutoff function)

TEMPERATURE

DRIFT

50 PPM/°C from 0 to 65°C ambient

DECIMAL POINT Up to three decimal places for process inputs:

d.ddd, dd.dd, ddd.d,or dddd

CALIBRATION

RANGE

An Error message will appear if input 1 signal and input 2

signals are too close together.

Input

Range

Minimum Span

Input 1 & Input 2

4-20 mA 0.40 mA

±10 V 0.20 V

INPUT

IMPEDANCE

Voltage ranges: greater than 1 MΩ

Current ranges: 50 - 100 Ω(depending on resettable fuse impedance)

INPUT

OVERLOAD

Current input protected by resettable fuse.

Fuse resets automatically after fault is removed.

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

LI5X Process & Temperature Meter Instruction Manual

Temperature Inputs

INPUTS Field selectable: type J, K, T, or E thermocouples;

100 Ωplatinum RTD (0.00385 or 0.00392 curve)

RESOLUTION 1°for all thermocouples and RTD inputs

1°or 0.1°for Type T thermocouple

ACCURACY

Input Type Range Accuracy

Type J -58°to 1382°F

-50°to 750°C

±2°F

±1°C

Type K -58°to 2300°F

-50°to 1260°C

±2°F

±1°C

Type T -292°to 700°F

-180°to 371°C

±2°F

±1°C

Type T

0.1°Res

-199.9°to 700.0°F

-180.0°to 371.0°C

±1.8°F

±1.0°C

Type E -58°to 1578°F

-50°to 870°C

±2°F

±1°C

100 ΩRTD -328°to 1382°F

-200°to 750°C

±1°F

±1°C

COLD

JUNCTION

REFERENCE

Automatic, fixed, no user calibration needed

TEMPERATURE

DRIFT

±2°C maximum

0 to 65°C ambient temperature

OFFSET

ADJUSTMENT

Programmable to ±19.9°. This parameter allows the user to

apply an offset value to the temperature being displayed.

INPUT

IMPEDANCE

Greater than 100 kΩ

SENSOR BREAK

DETECTION

Open TC or RTD sensor indicated by display flashing oPEn.

All relays and alarm status LEDs go to alarm state.

Analog output goes to the programmed sensor break value.

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

LI5X Process & Temperature Meter Instruction Manual

Relays Option

RATING 2 SPDT (form C); rated 3 amps @ 30 VDC or 3 amps @

250 VAC resistive load; 1/14 HP @ 125/250 VAC for

inductive loads

ELECTRICAL

NOISE

SUPPRESSION

A suppressor (snubber) should be connected to each relay

contact switching inductive loads, to prevent

disruption to the microprocessor’s operation.

Recommended suppressor value: 0.01 µF/470 Ω, 250 VAC

DEADBAND 0-100% of full scale, user selectable

HIGH OR LOW

ALARM

User may program any alarm for high or low trip point.

RELAY

OPERATION

Automatic (non-latching)

Latching

Pump alternation control

RELAY RESET User selectable via front panel buttons or PC

Automatic reset only (non-latching)

Automatic + manual reset at any time (non-latching)

Manual reset only, at any time (latching)

Manual reset only after alarm condition has cleared (latching)

Automatic reset: Relays will automatically reset when the

input passes the reset point.

Manual reset: Front panel ACK button. Pressing ACK re-

sets all manually resettable relays.

TIME DELAY 0 to 199 seconds, on and off delays

Programmable and independent for each relay

FAIL-SAFE

OPERATION

Programmable

Independent for each relay

AUTO

INITIALIZATION

When power is applied to the meter, relays will reflect the

state of the input to the meter.

Fail-safe operation: relay coil is energized in non-alarm condition. In

case of power failure, relay will go to alarm state.

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

Spec Tech Industrial Electric

www.spectechind.com

888-773-2832

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Instrumento de medición de FlowLine

FlowLine

FlowLine LI25 Series Manual de usuario

FlowLine

FlowLine DeltaSpan LD30 Series Manual de usuario

FlowLine

FlowLine DataLoop LI24 Series Manual de usuario

FlowLine

FlowLine EchoSpan LU81-5101 Series Manual de usuario

FlowLine

FlowLine PodView LI40 Series Manual del operador

FlowLine

FlowLine DataLoop LI23-1001 Manual de usuario

FlowLine

FlowLine LI20 Manual de usuario

FlowLine

FlowLine DeltaSpan LD31 Series Manual de usuario

FlowLine

FlowLine MicroPoint LI42 Series Manual de usuario

FlowLine

FlowLine EchoPod DL14 Series Manual de usuario

FlowLine

FlowLine LI25 Series Manual de usuario

FlowLine

FlowLine EchoPod DL14 Series Manual de usuario

FlowLine

FlowLine Symprobe LP75 Manual de usuario

FlowLine

FlowLine DataLoop LI23 Series Manual de usuario

FlowLine

FlowLine LI1 Series Manual de usuario

FlowLine

FlowLine LI21-1001 Manual de usuario

FlowLine

FlowLine LI25 Series Manual de usuario

FlowLine

FlowLine EchoTouch US01 Series Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
