FLIR FXV101-H Manual de usuario

DRAFT

Instruction Manual

FLIR FX

DRAFT

Instruction Manual

FLIR FX

#LX400034; r.16787/16787; en-US iii

DRAFT

Table of contents

1 Safety Precautions ..............................................................................1

2 What is included with my FLIR FX camera?.............................................2

3 How do I set up my FLIR FX camera? .....................................................3

4 What are the parts of my FLIR FX camera? .............................................5

4.1 Front ........................................................................................5

4.2 Top ..........................................................................................5

4.3 Left..........................................................................................6

4.4 Right........................................................................................6

4.5 Back ........................................................................................7

4.6 Indoor Stand..............................................................................7

5 How do I activate manual recording? .....................................................8

6 How do I view recordings on my computer?............................................9

7 How do I wall mount my FLIR FX camera? ............................................ 11

8 FLIR FX Specifications .......................................................................13

9 Notices.............................................................................................14

#LX400034; r.16787/16787; en-US v

DRAFT

Safety Precautions

• Camera is not weatherproof. Use the appropriate outdoor accessory if using the cam-

era outdoors or where it will be exposed to moisture.

• Make sure that outdoor power outlets and cable connections are properly sheltered

from the elements.

• Do not use the camera below 32°F / 0°C or above 104°F / 40°C.

• Only use the camera with approved FLIR accessories.

• Do not use or install the camera near a radiator or heat source.

• Do not cover the camera with a towel or blanket.

• Do not point the camera directly towards the sun or a source of intense light.

• Aiming the camera through a window will cause the nighttime LEDs to reflect off of the

glass, causing a bright spot in the image.

• Keep the cables at least 3ft / 1m away from baby cribs and out of reach of children and

infants.

• Use the included cable clips to help keep cables away from children.

• Do not disassemble the product. No user serviceable parts inside.

• Do not disassemble or do a modification to the battery. The battery contains safety and

protection devices which, if damage occurs, may cause the battery to become hot, or

cause an explosion or an ignition.

• If you are not using the product for a prolonged time, charge the battery every 6 months

to keep the battery in working condition.

• Dispose or recycle the product and batteries in accordance with local laws, which may

vary by location.

• If using an accessory with replaceable batteries, only use replacement batteries speci-

fied by FLIR. Use of other types of batteries may damage the product.

• The camera makes a clicking noise when changing between day and night modes. This

clicking is normal and indicates that the camera filter is working.

• Do not connect more than one USB cable to the product at once.

#LX400034; r.16787/16787; en-US 1

DRAFT

What is included with my FLIR FX

camera?

The standard model FXV101–H comes with the following components:

• Camera with indoor stand.

• microUSB cable.

• 8GB microSD card pre-installed in the camera.

• Power adapter.

• Power points for European and UK use.

• Mounting screws and drywall anchors.

• Extra mounting / camera ID plate for convenience.

• Quick start guide and safety information.

Note

Other models or configurations may come with slightly different components or accessories.

#LX400034; r.16787/16787; en-US 2

DRAFT

How do I set up my FLIR FX

camera?

1. Connect the included USB cable to the power adapter. Connect the other end of the

USB cable to the camera and connect the power adapter to a power outlet.

Note

• The REC LED will glow orange to indicate the camera is charging. It will glow green when the

camera is finished charging. The battery will take 6 hours to fully charge.

• You can connect the power adapter to either the USB cable on the camera or camera stand. Do

not connect a USB cable to both the camera and stand at the same time.

2. Press the power button on the camera. The camera will start up and the Direct Mode

LED will glow orange.

#LX400034; r.16787/16787; en-US 3

How do I set up my FLIR FX camera?

DRAFT

3. Download the FLIR FX app from the App Store or Google Play Store. Start up the app

and follow the start up wizard in the app to connect to the camera.

#LX400034; r.16787/16787; en-US 4
