INSTRUCTION MANUAL

MODEL:9127

PACKAGE LIST

BCD

F G H

①② ③ ④

⑤⑥ ⑦

Casters

Quantity:5

Star Base

Quantity:1

Gas Lift

Quantity:1

Seat Cushion

Quantity:1

Seat Plate

Quantity:1

Back Cushion

Quantity:1 Armrests

Quantity:2

Steel Plate

Quantity:3

Bolts M8x20mm Bolts M6x25mm Bolts M6x30mm Bolts M8x45mm

Quantity:4

Quantity:1

Quantity:4 Quantity:4

Quantity:4 Quantity:4 T-Wrench

Plastic CapsSpacer

Left Right

ASSEMBLY INSTRUCTIONS

STEP 1 : Turn the Star Base upside down, then press the Casters into

the holes at the end of each base leg.

STEP 2 : Turn the Star Base upright and insert the Lift into the center

hole of the Star Base.

STEP 3:Align the seat plate to the bottom of the seat cushion, make

sure that the front of the seat plate is facing the front of the seat cush

ion Attach the seat plate to the seat cushion using four M6X25mm bo

lts,tighten all the bolts with the T-wrench.

⑦

②

⑤

STEP 4 : Attach the Steel Plate to the seat cushion with three M8x20mm

Bolts.

⑦

①

Note: Do not tighten the bolts fully.

STEP 5:Turn the seat cushion upright and align the center hole of the

seat plate over the lift, then push the seat cushion down onto the lift

ﬁrmly until the connection is secure.

STEP 6:Attach the Steel Plate to the back cushion with four M6x30mm

Bolts.

③⑦

STEP 8:Tighten all the screws that are not tightened.

STEP 7:Attach armrest to the connector with M8*45mm Bolts on both

sides, using the T-Wrench，Then tighten all the screws ，Finally Press

the plastic caps into the adjuster holes to cover the bolts.

④⑦

⑥

⑦

①

(100%)

INSTRUCTIONS FOR USE

1.Seat Height:Paddle-shaped lever on the right side

To raise

while taking your weight oﬀ chair，

lift lever up.

To lower

while seated,lift lever up.

To increase tension:

while seated,turn knob forward

(toward+sign).

To decrease tension:

while seated,turn knob

backward(toward-sign).

2.Tilt Tension: Long stem under the seat cushion with knob

*At the proper height,your feet should rest ﬂat on the ﬂoor.

*set the tilt tension to control the resistance you feel when leaning back.

INSTRUCTIONS FOR USE

*At the proper height,your feet should rest ﬂat on the ﬂoor.

3.Operating the tilt lockout.

To let your chair tilt back,pull

the control handle out.

To stop your chair from tilting,

sit forward,then push the

control handle in.

Pull the lever FULLY and lean

back slowly until desired angle

is achieved,then slowly return

the lever to its starting position

Ensure the lever locks back in

place.

4.Backrest Recline

INSTRUCTIONS FOR USE

*At the proper height,your feet should rest ﬂat on the ﬂoor.

5.Relax with footrest

Pull out the pole of the

footrest,and turn the

footrest to the front.
