FIT IMMERSION : USER GUIDE
MAINTENANCE &UPDATES
Updates will be available on our server. When an update is available, the application downloads it and proposes to install it. If you
encounter any difficulties, please contact us and we will provide you the link to download the update manually. The update will not
affect your personal configurations.
After a few months, the CR2032 battery of the cadence sensor may need to be replaced. The opening is located on the back of the
sensor. Once replaced the green and red LEDs should light up for a short time. If this is not the case, check if the cover is correctly
closed: the dot should be between two marks. If the LEDs do not light up when the cover is closed, the battery probably needs to be
replaced.
TROUBLESHOOTING
NO SPEED SYNCHRONIZATION
The speed sensor goes into standby mode when not in use and requires a certain amount of time in motion to start measuring speed.
If after 1-2 minutes of pedaling the speed remains at a default value or displays 0 RPM, check if you got the message "Connected to
sensor SCxxxxx". You should get this message by switching the display off and on again (short press on the on/off button) .
If the message does not appear or the speed remains at default value after 1-2 minutes of pedaling try to restart the sensor by opening
and closing the battery cover. Be careful to close the cover in the right way and do not damage the contacts. When you close the
sensor the LEDs should light up very briefly. If this is not the case your battery may need to be replaced (if you have been using the
product for more than a month).
If you have an Android phone or tablet you can test the sensor with the "nRF Toolbox" application. In this application click the "CSC"
icon and press the "Connect" button. The sensor is named SCxxx (where xxx is a number).
BLACK SCREEN
Sometimes the application " crashes " during a long break or during intensive use. In this case you can reboot the headset or restart
application. To restart the application without rebooting press the button " N " -> "Back Home" then search for " Fit Immersion " in
the list of applications.
MESSAGE « TRACKS DATABASE INITIALIZATION… »
If this message appears when you try to start a training session, try again a few seconds later. If the problem persists, reboot the headset.
If the problem persists check the state of the sd card using the file explorer (in the list of applications in the system).
CONTACT US
By email : sav@fitimmersion.com
Facebook chat: facebook.com/fitimmersion
