Fishman PREFIX PREMIUM BLEND Manual de usuario

www.ﬁshman.com

USER GUIDE

PREFIX PREMIUM BLEND

Welcome

Thank you for making Fishman a part of your acoustic experience. We are proud

to offer you the ﬁnest acoustic ampliﬁcation products available; high-quality

professional-grade tools to empower you to sound your very best. We are

conﬁdent Preﬁx Premium Blend will both enhance and inspire your music making.

Quick Start

Before you begin, set the controls as shown:

1. Plug in • Use a ¼-inch instrument cable.

2. Tune up • Press the Tuner button. When

engaged, Tuner

mutes the output. Press again

to exit Tuner.

3. Turn up • Raise the Volume and adjust the

Blend control to your liking.

4. Pickup tone • Adjust tone controls to

your liking.

Controls

Volume • For the cleanest signal, set the Volume knob as high as possible,

without causing distortion or feedback.

Blend • Move the Blend slider to change the balance between the pickup and

the microphone.

Bass • Boost here to add depth and weight to the sound of the guitar. Note

that this control only affects the pickup signal.

Contour EQ • Two sliders (Contour and Contour Frequency) make up this

EQ. The Contour Frequency slider lets you tune in on a speciﬁc range of sound

that you can boost or cut with the Contour slider.

Treble • Boost to cut through the mix. Cut to mellow and subdue the sound.

Note that this control only affects the pickup signal.

Notch • Tune the Notch ﬁlter to remove low-end feedback. Raise the Volume

until feedback occurs, then slowly turn the Notch to the right until the feedback

is eliminated.

Phase • Use the Phase switch to improve bass response at low volume and

suppress feedback at high volume. If feedback occurs, push the Phase switch. If

feedback recurs when you change your location, press the switch again.

Microphone Position

Position the microphone to ﬁnd the “sweet spot” inside the instrument. Take the

time to experiment with microphone placement until you ﬁnd the position that

works best in your instrument.

Plug in the guitar and move the Blend slider to the left for mic only. Start with

the mic capsule so that it faces the back of the guitar. Move the mic closer to the

soundhole for more bass. Turn the capsule toward the sides of the instrument for

less bass.

Tu n e r

Depress the Tuner button to turn the circuit on and off. This digital chromatic

tuner accommodates all standard and alternate tunings and mutes the output

when engaged. It can be activated without an instrument cable connected, in

which case it will turn itself off after three minutes.

Note that the tuner is calibrated to A=440.

Power

Plug in the guitar, and the Preﬁx Premium Blend switches on. The Battery LED

will ﬂash once at power-up to tell you the preamp is on.

Low Battery Indicator

When the Battery indicator lights steadily, it is time to change the battery. To

conserve power, unplug the instrument and turn off the tuner when not in use.

Replace the battery by ﬂipping open the preamp body using the latch located at

the top of the preamp. Be sure to observe the correct polarity during this instal-

lation.

Sample Settings

Fingerstyle “Scooped” Mid

This will add fullness to the bass This setting emphasizes extreme bass

and deﬁnition to the treble. and treble

Stereo Operation

A small switch, located on the side of the preamp, let’s you choose between

mono and stereo operation. Factory preset to mono, you use the onboard

controls to affect your mic and pickup sound and connect to your ampliﬁer or PA

with a standard guitar cable

If you wish to split the pickup and microphone signals for separate external

processing, move this switch to stereo and connect to your ampliﬁer or PA with a

stereo “Y” cable. In this mode, the pickup signal goes to the tip output and the

microphone goes to the ring output.

Mono / Stereo switch

MONO CABLE

Microphone & Pickup

Signals

STEREO "Y" CABLE

Tip

Pickup

Ring

Microphone

Microphone Trim Adjustment

The microphone and pickup levels are preset at the factory and do not require

adjustment. However, a microphone trim control may be adjusted to alter the

microphone and pickup balance. Set the Blend slider to the center position and

adjust the trim control as necessary.

Trim
