USER GUIDE
Archtop Guitar Pickup
Welcome
Thank you for making Fishman a part of your acoustic experience. We are proud
to offer you the finest acoustic amplification products available; high-quality
professional-grade tools which empower you to sound your very best.
Troubleshooting
If you are unfamiliar with this product, please pay close attention to the dimen-
sional requirements for installation. Failure to do so can result in permanent
damage to the pickup.
Installation by a qualified professional is strongly recommended.
Should you have any problems, please check with your installer or refer to the
online installation guide for this product. Technical support, troubleshooting tips
and installation information can be found at http://www.fishman.com/support/
Dimensions
2.125” String Spacing
The Archtop Guitar Pickup is suitable for most instruments with a distance of
2.914 inch (74.01 mm) between adjustable bridge posts (center to center).
Bridge radius is 12 inches.
Plugging In
An impedance matching preamp is recommended, but not required. This will
help realize the full frequency response potential of the pickup and allow for
cable runs longer than 10 feet without signal deterioration. Use a high quality,
low capacitance 1/4 inch shielded instrument cable. This will ensure minimal tone
coloration and hum.
www.fishman.com
009-020-002 Rev B 3-08
