First Alert D-520 Manual de usuario

Indoor/Outdoor

Digital Wireless Camera

Model D-520

USER'S MANUAL

continuing product development, the product inside the packaging may look slightly different than

the one on the package.

Lehigh Consumer Products, LLC is a subsidiary of Jarden Corporation (NYSE: JAH). To obtain

warranty service, contact the Consumer Affairs Division at 1-800-323-9005, Monday through

Friday, 7:30 a.m.- 5:00 p.m., Central Standard Time.

Made in China

M08-0260-000

Table of Contents

Safety ...............................................................................................................................1

Safety Precautions ........................................................................................................................... 1

FCC Compliance ............................................................................................................................. 1

Getting to Know Your Model D-520 Camera .................................................................2

Check Package Contents.................................................................................................................. 2

Camera Components........................................................................................................................ 2

Setting Up Your Model D-520 Camera...........................................................................3

General Precautions......................................................................................................................... 3

Installing the Camera....................................................................................................................... 3

Troubleshooting..............................................................................................................5

Technical Information .....................................................................................................6

Warranty...........................................................................................................................7

Product Limited Warranty................................................................................................................ 7

Warranty Exclusions........................................................................................................................ 7

Obtaining Service ............................................................................................................................ 8

Safety

SAFETY PRECAUTIONS

Do not drop, puncture, or disassemble the camera.

Never tug on the power adapter. Use the plug to remove it from the wall.

Use the device with care. Avoid pressing hard on the camera or receiver body.

Do not expose the camera to high temperatures.

For your own safety, avoid using the camera when there is a storm or lightning.

Use the device with care. Avoid pressing hard on the camera body.

Do not crush or damage the power cable.

FCC COMPLIANCE

This device complies with Part 15 of the FCC Rules. Operation is subjected to the

following two conditions: (1) this device may cause harmful interference, and (2) this

device must accept any interference received, including interference that may cause

undesired operation.

This equipment has been tested and found to comply with limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in residential installations. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio

communications.

However, there is no guarantee that interference will not occur with a particular

installation. If this equipment does cause interference to radio or television equipment

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment into an outlet on a circuit different from that to which the

received is connected.

Consult the dealer or an experience radio/TV technician for help.

Notice: Changes or modifications to the product could void the user's

authority to operate the product.

Getting to Know Your

Model D-520 Camera

Congratulations on purchasing your First Alert Security Camera product. First Alert has

been helping families and businesses stay safe for over 50 years. By having a First Alert

Security Camera, you’re taking the first step in protecting your home or business from

damage or theft. We’re watching, even when you’re not.

CHECK PACKAGE CONTENTS

After unpacking the carton, check the contents for damage. Contact your supplier or dealer

immediately if any part is missing or damaged.

Digital Wireless Color Camera (1)

Camera Antenna (1)

Camera Stand (1)

Mounting Kit (1)

DC 5V Power Supply (1)

User's Manual (1)

CAMERA COMPONENTS

1Antenna 5Link LED 9 Pairing Key

2EDS 6PIR 10 Power Jack

3Power LED 7IR LED 11 Microphone

4Camera Lens 8Camera Stand 12 Power Adapter

Setting Up Your

Model D-520 Camera

GENERAL PRECAUTIONS

Use only the power supply provided with the system.

Unplug the power supply when the system is not in use for extended periods.

Do not place the camera near a radiator, vent, or other place where it might be

exposed to heat, moisture, dust, vibrations, or strong magnetic fields.

Do not attempt to repair the camera. Contact a qualified technician for service. Any

change or modification may damage the equipment and invalidate the warranty.

When installing the camera, follow manufacturer’s advice when using power tools,

steps, ladders, etc. and wear suitable protective equipment (e.g., safety goggles)

when drilling holes. Before drilling holes through a ceiling, check for hidden

electricity cables and water pipes.

INSTALLING THE CAMERA

1Select the position for the camera and secure the camera stand.

Screws and anchors are supplied. Use an appropriate screw type for the mounting surface.

2Screw the camera onto the bracket.

Setting Up Your D-520 Security Camera

Model D-520 User's Manual

3Adjust camera to the proper view angle. Make sure the lens is upright relative to your

subject. Tighten the thumb bolt.

4Screw the antenna into place on the rear of the camera. Adjust the antenna to an

upright position.

5Plug the power cable end into the camera, and then plug the adapter end into an

electric outlet.

Note: If pairing (linking) an additional camera, follow the steps on the receiver menu.

Troubleshooting

Problem Possible Causes Remedies

System Message

shows “No Signal” No power supply to

camera If camera power status indicator light is off,

check power adapter and power cable

connection.

Channel is not synched

up to camera Move the camera closer to the receiver, and

connect the camera to the desired channel. Go

to “Camera Setup” in the Menu. Use the

“Pairing” sub-menu to connect the camera to

the receiver.

Service out of range Move the camera closer to the receiver.

Signal is blocked If possible, remove major obstacles in

between the camera and the receiver. Or,

relocate the camera to another location.

Low or unstable

signal Antenna direction is

limited Adjust the camera antenna and receiver

position.

Signal has been blocked If possible, remove major obstacles in

between the camera and receiver. Or, relocate

the camera to another location.

Strong radio signal

nearby Keep WIFI router away from the camera

and/or receiver.

Strong electromagnetic

interference nearby Keep active appliances such as hair dryers,

heat fans, air conditioners, water pumps, or

microwave ovens away from the camera

and/or receiver.

Dim or overly bright

image at night time Low light vision distance

is too short/too far Adjust the camera to have the view fit the

ideal distance: 15 to 24 feet.

Audio feedback Camera and receiver are

too close The camera has a high sensitivity

microphone. Keep the camera at least 10 feet

away from the receiver. If the camera must be

within 10 feet of the receiver, keep the

volume down.

Poor image quality Interference Place the camera and/or receiver antenna at a

new angle or readjust its position to make an

improvement.

Remove obstacles between the camera and

receiver that might affect the signal (e.g.,

furniture, cabinets, and walls.)

Relocate the camera closer to the receiver.

Setting Up Your D-520 Security Camera

Model D-520 User's Manual

Technical Information

Operating Power 5V DC

Operating Temperature 14° F - 122° F

Indoor/Outdoor Both

Dimensions

Camera and Stand

4.7” x 2.8” x 2.7”

Image Sensor CMOS

Viewing Angle 56 degrees

Microphone Yes

Audio Range 16 ft

Motion Detection Yes

Color Yes

Infrared LEDs 27

Distance 40 ft

Wireless Range 750 ft

Wireless Frequency 2.4 GHz

Transmission Channels 40
