First Alert P-500 Manual de usuario

Indoor Analog

Wired Mini Camera

Model P-500

USER'S MANUAL

continuing product development, the product inside the packaging may look slightly different than

the one on the package.

Lehigh Consumer Products, LLC is a subsidiary of Jarden Corporation (NYSE: JAH). To obtain

warranty service, contact the Consumer Affairs Division at 1-800-323-9005, Monday through

Friday, 7:30 a.m. - 5:00 p.m., Central Standard Time.

Made in China

M08-0253-000

Table of Contents

Safety ...............................................................................................................................1

Safety Precautions ........................................................................................................................... 1

FCC Compliance ............................................................................................................................. 1

Getting to Know Your P-500 Camera.............................................................................2

Check Package Contents.................................................................................................................. 2

Features............................................................................................................................................ 2

Setting Up Your P-500 Camera....................................................................................... 3

General Precautions ......................................................................................................................... 3

Installing the Camera....................................................................................................................... 3

Connecting the Camera to a VCR/DVR and TV ............................................................................. 4

Viewing the Cameras on Your TV................................................................................................... 4

Troubleshooting ..............................................................................................................5

Technical Information .....................................................................................................6

Warranty...........................................................................................................................7

Product Limited Warranty................................................................................................................ 7

Warranty Exclusions ........................................................................................................................ 7

Obtaining Service ............................................................................................................................ 8

Safety

SAFETY PRECAUTIONS

Do not drop, puncture, or disassemble the camera.

Never tug on the power adapter. Use the plug to remove it from the wall.

Do not expose the camera to high temperatures.

For your own safety, avoid using the camera when there is a storm or lightning.

Use the device with care. Avoid pressing hard on the camera body.

Do not crush or damage the power cable.

FCC COMPLIANCE

This device complies with Part 15 of the FCC Rules. Operation is subjected to the

following two conditions: (1) this device may cause harmful interference, and (2) this

device must accept any interference received, including interference that may cause

undesired operation.

This equipment has been tested and found to comply with limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in residential installations. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio

communications.

However, there is no guarantee that interference will not occur with a particular

installation. If this equipment does cause interference to radio or television equipment

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment into an outlet on a circuit different from that to which the

received is connected.

Consult the dealer or an experience radio/TV technician for help.

Notice: Changes or modifications to the product could void the user's

authority to operate the product.

Getting to Know Your

P-500 Camera

Congratulations on purchasing your First Alert Security Camera product. First Alert has

been helping families and businesses stay safe for over 50 years. By having a First Alert

Security Camera, you’re taking the first step in protecting your home or business from

damage or theft. We’re watching, even when you’re not.

CHECK PACKAGE CONTENTS

After unpacking the carton, check the contents for damage. Contact your supplier or dealer

immediately if any part is missing or damaged.

Wired Camera with Stand and 7” Wires (1)

Power Supply (1)

Camera Stand (1)

Mounting Kit (1)

18 ft. AV/Power Extension Cable (1)

User’s Manual (1)

FEATURES

The P-500 security camera is a very simple solution for surveillance at home or business

use. With clear picture quality, you will keep your home or other places you want to

protect in a highly safety degree by connecting the camera to your security monitor or

DVR for convenient monitoring or recording.

¼” CMOS

380 TV lines resolution

6 mm lens

35 degree viewing angle

Includes audio surveillance capability

camera stand

camera

body

Setting Up Your

P-500 Camera

GENERAL PRECAUTIONS

Use only the power supply provided with the system.

Unplug the power supply when the system is not in use for extended periods.

Do not place any of the equipment near a radiator, vent, or other place where it

might be exposed to heat, moisture, dust, vibrations, or strong magnetic fields.

Do not attempt to repair the camera. Contact a qualified technician or the dealer for

service. Any change or modification may damage the equipment and invalidate the

warranty.

When installing the camera, follow manufacturer’s advice when using power tools,

steps, ladders, etc. and wear suitable protective equipment (e.g., safety goggles)

when drilling holes. Before drilling holes through a ceiling, check for hidden

electricity cables and water pipes.

INSTALLING THE CAMERA

1Remove cover from camera lens. Select the position for the camera and secure the

camera stand.

Screws and anchors are supplied. Use an appropriate screw type for the mounting surface.

2Adjust camera to the proper view angle. Make sure the lens is upright relative to your

subject. Tighten the set screws.

3Connect the camera to power using the supplied power cable and adapter.

camera stand

camera lens

set screw

Setting Up the P-500 Camera

Model P-500 User's Manual

CONNECTING THE CAMERA TO A VCR/DVR AND TV

1Connect audio and video plugs from the camera to the VCR/DVR. If more length is

required, an 18 ft. AV / Power Extension Cable is included.

2Flexible power connection option - Either connect power adaptor directly to

camera unit or through extension cable.

3Connect AV cables from the VCR/DVR to the TV.

VIEWING THE CAMERAS ON YOUR TV

1Power on the camera and TV.

2Using your TV’s remote control tune your TV to the correct INPUT (e.g., INPUT1).

You should now see your images on the TV screen. Follow your manufacturer’s instructions to

record to your VCR or DVR.

Setting Up the P-500 Camera

Model P-500 User's Manual

TROUBLESHOOTING

Problem Solution

No picture.

Make sure cover has been removed from camera

lens.

Make sure the cameras and receiver are plugged in.

Make sure the TV/ VCR/ DVR is tuned to the

correct input channel.

Technical Information

Image Device 1/4" CMOS

Video System NTSC

Resolution 380 TV lines

Effective Pixels NTSC: 510 (H) x 492 (V)

Lens 6 mm

Viewing Angle 35 degrees

Minimum Illumination < 2.0 Lux

Signal/Noise Ratio > 46 dB

White Balance Automatic

Electronic Shutter Time 1/60 – 1/150,000 sec

Gain Control Automatic

Backlight Compensation Yes

Wide Dynamic Range No

Microphone Yes

Audio Range 10 ft

Operating Temperature 14°F – 113°F

Power Supply DC 12V

Indoor/Outdoor Indoor

Dimensions 1.5" x 1.2" x 1.2"
