Finelite E2-ID Instrucciones de instalación
E2 Indirect/Direct Linear
Finelite, Inc. ·30500 Whipple Road ·Union City, CA 94587-1530 ·(510) 441-1100 ·Fax: (510) 441-1510 ·www.finelite.com
E2-ID Recycling Luminaire Disassembly Instructions
STEEL Aluminum e
7
Luminaire breaks down easily for recycling at the end of usable life*.
Top Diffuser
Top LED Boards
Backplate
Endcaps
Luminaire Body
Backplate
Bottom LED Boards
Bottom Diffuser
End Suspension Brackets
Capture Brackets
Capture Brackets
© 2017 FINELITE, INC. ALL RIGHTS RESERVED. FORM CPG0080. 07/17
*Recycling information typical for all luminaire sizes. Contact factory for more information.
Retention Clips
Underlap Backplate
Retention Collar
and Set Screw
4-Conductor Cable
Retention Collar
and Set Screw
E2 Indirect/Direct Linear
Finelite, Inc. ·30500 Whipple Road ·Union City, CA 94587-1530 ·(510) 441-1100 ·Fax: (510) 441-1510 ·www.finelite.com
= Aluminum
= Steel
= E-Waste
(and Non-Recyclable)
= Plastic
= Copper Wire
11%
4%
2%
5%
78%
95% Recyclable
E2-ID-L components are constructed from aluminum, steel, e-waste, plastic, and copper wire.
E2-ID-L is 95% recyclable at the end of useful life.
E2-ID-L Recycling Luminaire Breakdown
E2 Indirect/Direct Linear
Finelite, Inc. ·30500 Whipple Road ·Union City, CA 94587-1530 ·(510) 441-1100 ·Fax: (510) 441-1510 ·www.finelite.com
e
STEEL
The E2-ID Large Capacity Power Supply Box breaks down easily for recycling at the end of usable life*.
Driver Sleds
Drivers
*Recycling information typical for power supply box. Contact factory for more information.
Battery Sleds
Lid
Batteries
Battery Backup
Driver Sled
Battery Backup Driver
Feed Plate
Base
Gantry Assembly
Collar
Electrical Cover
Magnets
Canopy
E2-ID Recycling Large Capacity Power Supply Box Disassembly Instructions
© 2017 FINELITE, INC. ALL RIGHTS RESERVED. FORM CPG0080. 07/17
E2 Indirect/Direct Linear
Finelite, Inc. ·30500 Whipple Road ·Union City, CA 94587-1530 ·(510) 441-1100 ·Fax: (510) 441-1510 ·www.finelite.com
E2-ID Recycling Large Capacity Power Supply Box Disassembly Instructions
66% Recyclable
E2-ID Large Capacity PS Box components are constructed from steel and e-waste.
E2-ID Large Capacity PS Box is 66% recyclable at the end of useful life.
= Steel
= E-Waste
(and Non-Recyclable)
34%
66%
E2 Indirect/Direct Linear
Finelite, Inc. ·30500 Whipple Road ·Union City, CA 94587-1530 ·(510) 441-1100 ·Fax: (510) 441-1510 ·www.finelite.com
e
STEEL
The E2-ID Low Profile T-Bar Power Supply box breaks down easily for recycling at the end of usable life*.
Driver Sleds
Luminaire Sensor
Power Pack Sled
*Recycling information typical for power supply box. Contact factory for more information.
Drivers
Low Profile T-Bar
Power Supply Box
Feed Plate
Magnets
Luminaire Sensor
Power Pack
Collar
Gantry Assembly
Electrical Cover
Canopy
E2-ID Recycling Low Profile T-Bar Power Supply Box Disassembly Instructions
© 2017 FINELITE, INC. ALL RIGHTS RESERVED. FORM CPG0080. 07/17
E2 Indirect/Direct Linear
Finelite, Inc. ·30500 Whipple Road ·Union City, CA 94587-1530 ·(510) 441-1100 ·Fax: (510) 441-1510 ·www.finelite.com
E2-ID Recycling Low Profile T-Bar Power Supply Box Disassembly Instructions
= Steel
= E-Waste
(and Non-Recyclable)
17%
83%
83% Recyclable
E2-ID Low Profile PS Box components are constructed from steel and e-waste.
E2-ID Low Profile PS Box is 83% recyclable at the end of useful life.
E2 Indirect/Direct Linear
Finelite, Inc. ·30500 Whipple Road ·Union City, CA 94587-1530 ·(510) 441-1100 ·Fax: (510) 441-1510 ·www.finelite.com
e
STEEL
The E2-ID Retrofit Power Supply Box breaks down easily for recycling at the end of usable life*.
*Recycling information typical for power supply box. Contact factory for more information.
Driver Sleds
Base
Drivers
Lid
Feed Plate
Gantry Assembly
Collar
Electrical Cover
Canopy
Magnets
E2-ID Recycling Retrofit Power Supply Box Disassembly Instructions
© 2017 FINELITE, INC. ALL RIGHTS RESERVED. FORM CPG0080. 07/17
E2 Indirect/Direct Linear
Finelite, Inc. ·30500 Whipple Road ·Union City, CA 94587-1530 ·(510) 441-1100 ·Fax: (510) 441-1510 ·www.finelite.com
E2-ID Recycling Retrofit Power Supply Box Disassembly Instructions
= Steel
= E-Waste
(and Non-Recyclable)
22%
78%
78% Recyclable
E2-ID Retrofit PS Box components are constructed from steel and e-waste.
E2-ID Retrofit PS Box is 78% recyclable at the end of useful life.
E2 Indirect/Direct Linear
Finelite, Inc. ·30500 Whipple Road ·Union City, CA 94587-1530 ·(510) 441-1100 ·Fax: (510) 441-1510 ·www.finelite.com
STEEL
The E2-ID Splice Box breaks down easily for recycling at the end of usable life*.
*Recycling information typical for splice box. Contact factory for more information.
Collar Canopy
Electrical Cover
Splice Box
Non-Powered
Magnets
Gantry Assembly
E2-ID Recycling Splice Box Disassembly Instructions
© 2017 FINELITE, INC. ALL RIGHTS RESERVED. FORM CPG0080. 07/17
E2 Indirect/Direct Linear
Finelite, Inc. ·30500 Whipple Road ·Union City, CA 94587-1530 ·(510) 441-1100 ·Fax: (510) 441-1510 ·www.finelite.com
E2-ID Recycling Splice Box Disassembly Instructions
= Steel
100%
100% Recyclable
E2-ID Splice Box components are constructed from 100% steel.
E2-ID Splice Box is 100% recyclable at the end of useful life.
