AZ31

MAINBOARD

MANUAL

DOC No.: M00402

Rev. : A2

Date : 7, 2000

Part No. : 25-11523-22

Handling Precautions

Warning:

1. Static electricity may cause damage to the integrated circuits on

the motherboard. Before handling any motherboard outside of its

protective packaging, ensure that there is no static electric charge

in your body.

2. There is a danger of explosion if the battery is incorrectly

replaced. Replace only with the same or an equivalent type

recommended by the manufacturer.

3. Discard used batteries according to the manufacturer’s

instructions.

Observe the following basic precautions when handling the motherboard

or other computer components:

nWear a static wrist strap which fits around your wrist and is

connected to a natural earth ground.

nTouch a grounded or anti-static surface or a metal fixture such as a

water pipe.

nAvoid contacting the components on add-on cards, motherboards,

and modules with the golden fingers connectors plugged into the

expansion slot. It is best to handle system components by their

monting brackets.

The above methods prevent static build-up and cause it to be discharged

properly.

Trademark

All trademarks mentioned in this manual are registered properly of

the respective owners.

Handling Precautions

Thismanualmaynot,inwholeorinpart,bephotocopied,reproduced,

transcribed, translated, or transmitted in whatever form without the

written consent of the manufacturer, except for copies retained by the

purchaser for personal archival purposes.

Notice

TableofContents

Table of Contents

Chapter 1 Overview

Package Checklist .......................................................................... 1-2

The AZ31 Mainboard................................................................ 1-3

Main Features................................................................................ 1-4

ACPIReady ................................................................................... 1-6

FICUniqueInnovationforUsersII(NOVUS II) -

Enhanced Mainboard Features and System Support .................... 1-6

Chapter 2 Installation Procedures

QuickReference (fromPage 2-2 to2-4) .......................................... 2-2

Mainboard Layout .................................................................... 2-2

1).Clear CMOS, FSBSpeed Select,Over VoltageDriving .2-3

2). Front Panel Block Cable Connection ............................ 2-4

3).CPUFan Installation .................................................... 2-4

1). Set System Jumpers .................................................................. 2-5

ClearCMOS:CLR_CMOS ................................................. 2-6

Enabling Over Voltage Driving: Magic Tuner ................... 2-6

FSBSpeedSelect:100MHz/133MHz ................................. 2-6

2). Install RAM Modules .............................................................. 2-7

Install and Remove DIMMs .............................................. 2-7

3).Installthe CPU .......................................................................... 2-8

4). Install Expansion Cards............................................................. 2-9

5). Connect Devices....................................................................... 2-10

Floppy Diskette Drive Connector: FDD ............................ 2-10

IDEHDDDeviceConnectors:PRIMARY,SECONDARY .. 2-11

ATX Power Connector: ATX_PWR .................................. 2-11

CPUFan Connector:CPU_FAN ........................................ 2-12

System Case Fan Connectors: CHS_FAN, SYS_FAN ....... 2-12

CDAudioo-In Connectors: CD_IN1, CD_IN2.................. 2-13

FrontPanel Block Connector: FPNL.................................. 2-13

PS/2 Keyboard and Mouse Connector: PS2_KB, PS2_MS 2-15

Universal Serial Bus Connectors: Rear USBs, Front USBs 2-15

PrinterConnector: LPT...................................................... 2-16

Serial Port Connectors: COM ............................................ 2-16

AudioI/OJacks: LINE_OUT, LINE_IN,MIC_IN .............. 2-17

NOVUSII ModuleConnector:NOVUS II ......................... 2-17

AZ31MainboardManual

Chapter 3 BIOS Setup

CMOSSetup Utility ....................................................................... 3-1

Standard CMOS Setup................................................................... 3-2

Hard Disk Configurations.......................................................... 3-2

Advanced BIOS Features .............................................................. 3-3

Advanced Chipset Features .......................................................... 3-6

Integrated Peripherals.................................................................... 3-11

Power Management Setup ............................................................. 3-15

PNP/PCIConfigurations ................................................................ 3-20

PC Health Status ............................................................................ 3-21

Frequency/Voltage Control ............................................................ 3-22

LoadFail-Safe Defaults.................................................................. 3-23

LoadOptimized Defaults................................................................ 3-23

Supervisor/User Password ............................................................ 3-24

Save and Exit Setup ....................................................................... 3-25

Exitwithout Saving ........................................................................ 3-25

Quick Reference (German) G-1

Quick Reference (French) F-1

Quick Reference (Spanish) S-1

Quick Reference (Japanese) J-1

Quick Reference (Chinese) C-1

Quick Reference (Simplified Chinese ) SC-1

1 - 1

Overview

Chapter 1

The new Socket A 1stMainboard AZ31 is an microATX sized motherboard

supporting the latest generation of AMD Athlon and Duron processors at

industry leading speeds. By utilizing DDR ( Double Data Rate ) transfer rate

the100 MHz AMD Athlonsystem bus effectively reachesspeeds of 200 MHz.

The AMD Athlon processor offers high-performance cache technology, in-

cluding128KBof on-chip level one(L1) , while the Duronfeatures full-speed,

on-chip L2 cache memory, and enhanced 3DNow!™ technology. The

1stMainboard AZ31 has 3 DIMM, for up to 1.5 GB of SDRAM, utilizes the

latestPC133SDRAM technology and isequipped with ECC memory support.

The1stMainboardAZ31 is based aroundthe high performance KT133 chipset

comprisedof VIAVT 8363system controllerfor theNorth Bridge,and theVIA

686A ( Super South ). The KT133’s support for AGP 4x provides the end-user

a photo-realistic 3D experience suitable for the most robust 3D games and

software environments. Onboard AC97 sound ensures high quality audio, but

with the option of being disabled through the BIOS.

The 1stMainboard AZ31 also comes equipped with the new NOVUS II range

of innovative features that assist in the installation and maintenance of your

1stMainboard. The features include Easy Key, which provides instant key-

board access to the BIOS for adjustments to Clock and Default settings and

LogoGenie, which allows you to create your own customized logo to be dis-

played during system boot up. The BIOS Guardian is an Anti Virus utility that

prevents viruses from damaging your system BIOS and rendering your sys-

tem inoperative. Clockometer is a user friendly Graphic User Interface (GUI)

that allows you to change clock speed settings directly, without having to

enterthe BIOS Sub-Menus.Moreover,audio alert II(mfg. optional) ,a friendly

onboard voice caution, will advice the error during system boot up.

Expansionis providedby 1AGP and 3PCIslots. Inaddition, the1stMainboard

AZ31 is equipped with 2 dual channeled enhanced PCI bus master IDE con-

nectors. Standard I/O connections include 1 serial port, 1 parallel port, 1 PS/2

mouse and keyboard connector, 2 USB connectors, 2 front USB pin-headers

and 1 media connector ( Line-In, Line-Out, Mic-In).

1 - 2

AZ31MainboardManual

Package Checklist

If you discover any item below was damaged or lost, please contact your

vendor.

þThe mainboard þThis user manual

þOneFDD cable þOne HDD cable

þOneATA/66cable þAudio Alert II module (optional)

þTwo software CDs (CD Pro, CD Plus and its manual)

IMPORTANT:AMDCPUHEATSINKINSTALLATION

Be ware finish heat hink install. Before you boot system, please

check the heat sink is complete contact with die of CPU.

The poor contact will bring about over heat, it may damage your

processor.

Itisstrongly recommended that atleasta200-wattATX powerpupply

be used for this motherboard. Make sure that your ATX power sup-

ply can supply at least 20 amperes on teh +5-Volt lead and 10ma

on the +5-Volt standby lead (+5VSB). Your system may become

unstable / unreliable and may experience difficulty in powering up if

your power supply is inadequate.

1 - 3

Overview

The AZ31 Mainboard

1 - 4

AZ31MainboardManual

Main Features

■Easy Installation

||BIOS with support for Plug and Play, auto detection of IDE hard drives,

||LS-120|drives, IDE ZIP drives, Windows 95, Windows 98, Windows NT

||4.0,Windows2000, |andOS/2.

■Leading Edge Chipset

VIAVT8363and 686A (Super South)provide integrated DRAM control-

lers with new Dynamic Power Management Architecture (DPMA), con-

currentPCI (2.2),AGP 1.0/2.0compliantand USB.

■Versatile Main Memory Support

Accepts up to 1.5GB DRAM using three DIMMs of 32, 64, 128, 256,

512MB with support for lightenning-fast SDRAM (100/133MHz). The

latestVirtualChannel Memory(VCM)SDRAM alsosupported.Thisboard

allows the FSB and DRAM to be asynchronous.

■Enhanced PCI Bus Master IDE Controller with Ultra DMA/33 and

Ultra DMA/66 Support

Integrated Enhanced PCI Bus Master IDE controller features two dual-

channel connectors that up to four Enhanced IDE devices, including CD-

ROM and Tape Backup Drives, as well as Hard Disk Drives supporting

the new Ultra DMA/66 protocol. Standard PIO Mode 3, PIO Mode 4,

DMA Mode 2, DMA Mode 4 devices are also supported.

■AMD® Athlon™ Processors Support

Duron Socket A CPU 600/650/700/750MHz at 100MHz FSB with AMD

bus for double data transfer rate at 100MHz for an effective 200MHz

transfer rate.

Athlon Socket A CPU 750/800/850/900*/950*MHz and up to 1GHz*at

100MHz FSB with AMD Athlon bus for double data rate transfers at

100MHzfor effective 200MHztransfer rate.

1 - 5

Overview

■AGP and PCI Expansion Slots

One AGP Bus expansion slot and three PCI Bus expansion slots provided

the room to install a full range of add-on cards.

■Compact Onboard Audio Subsystem

Embeded in VIA 686A®, the audio processor offers an integrated PCI

audiocontroller, DOS games compatibleengine, and offersthe feature of

high-quality music synthesizer. The subsystem utilizes line-out, line-in,

and MIC mini-jack external jacks, one joystick port with MIDI interface.

■■

■Super Multi Input/Output (I/O) Support

IntegratedPlugand Play multi-I/O chipsetfeatures one high-speed UART

16550 compatible serial port, one EPP/ECP capable parallel port, and one

FDD connector.

■■

■Convenient Rear Panel USB Connection Support

Two USB ports integrated in the rear I/O panel with two manufacturing

optional USB front panel connections allow convenient and high-speed

Plug and Play connections to the growing number of USB compliant

peripheral devices on the market.

■■

■Onboard Accelerated Graphics Port (AGP)

Themotherboard isinstalled one 32-bitAGP buswith a dedicated66MHz/

133MHzpath from the graphicscard to thesystem memory offeringmuch

greater bandwidth than the 32-bit PCI bus does. AGP enabled 3D graph-

ics cards can directly access main memory across this fast path instead of

using local memory. To make use of the improved AGP performance, the

motherboardshould be installedwith SDRAM typememory and theVGA

card and drivers should also be fully AGP compliant. Using Microsoft’s

Windows 98 and Windows 2000 which implement DirectDraw will allow

the system to take full use of AGP’s benefits without the need to install

additional drivers.

1 - 6

AZ31MainboardManual

It is compatible with all other none ACPI operating systems. If you want to

setup ACPI feature under Windows 98, please follow the description below:

Run Windows 98 setup by using setup/p j on the command line for installing

Windows 98 with the ACPI control feature.

If you type setup without the parameter /p j, Windows 98 will be installed as

APM, PnP mode, no ACPI will be used. For more detail information, please

visit the web site of Microsoft. Its address is: www.microsoft.com/hwtest/.

FIC Unique Innovation for Users II (NOVUS

II) - Enhanced Mainboard Features and System Support

■■

■LogoGenie

A user friendly GUI supporting Windows 98, LogoGenie allows you to

customize, create or select a Logo which will be displayed when the sys-

tem is booting.

Before execute this LogoGenie function, please make sure the related

BIOS feature, BIOS Guardian, is disabled; and refer to its related

README file.

NOTE:

1. LogGenie supports Award BIOS only.

2. If you create a Logo file (.bmp) by LogoGenie, the file size must

||||be 640 x 464 x 16 colors (around 145K).

NOTE: If BIOS date is after 12/02/1999, the ACPI will be installed

automatically. Users do not need to setup in the above-mentioned

way.

ACPI Ready

Thismainboard fully implements thenew ACPI (Advanced Configurationand

Power Interface) 1.0B Hardware and BIOS requirement. If you install ACPI

aware of operating system, such as Windows 98, you fully utilized the power

saving under ACPI. (Windows 2000 Professional supports ACPI functions.)

Tabla de contenidos

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario
