Fibocom FG360-NA Instrucciones de instalación

FG360-NA Hardware Guide

Version: Draft V1.0.2

Date: 2021-05-06

FG360-NA Hardware Guide 2/28

Applicability Type

NO.

Product Model

Description

FG360-NA Hardware Guide 3/28

Without the prior written permission of the copyright holder, any company or individual is prohibited to

excerpt, copy any part of or the entire document, or distribute the document in any form.

Notice

The document is subject to update from time to time owing to the product version upgrade or other reasons.

Unless otherwise specified, the document only serves as the user guide. All the statements, information

and suggestions contained in the document do not constitute any explicit or implicit guarantee.

Trademark

The trademark is registered and owned by Fibocom Wireless Inc.

FG360-NA Hardware Guide 4/28

Change History

Version

Author

Update Date

Remark

V1.0.2

Shaofeng

2021-05-06

Section 2.1.1: update band information

V1.0.1

Xu Xialin

2021-04-22

Section 2.1.1: add weight information

Section 2.3: Add section 2.3 antenna configuration

Section 3.1: Update pin name of Pin

193,175,157,148,139,130

Section 4.1: Update module appearance

Section 3.1: Add PCIe D as reserved and update pin

name of Pin 3,265,38,39,41,44

V1.0.0

Peng Yujun

Xu Xialin

2021-03-09

Initial version


Reproduction forbidden without Fibocom Wireless Inc. written authorization - All rights reserved.
FG360-NA Hardware Guide                                                                               5/28
Contents
1Foreword........................................................................................................................6
1.1 Introduction...................................................................................................................6
2Overview ........................................................................................................................6
2.1 Introduction...................................................................................................................6
2.1.1 Key Features................................................................................................................... 6
2.2 Application Framework .................................................................................................9
2.3 Antenna Configuration................................................................................................10
3Pin Definition ...............................................................................................................16
3.1 Pin Map ......................................................................................................................16
3.1.1 Table of Pin No. and Pin Name..................................................................................... 17
3.1.2 Pin Definition ................................................................................................................. 19
4Structural Specification ..............................................................................................27
4.1 Product Appearance ...................................................................................................27
4.2 Dimension of Structure ...............................................................................................27
4.3 Storage.......................................................................................................................28
4.4 Packing.......................................................................................................................28




FG360-NA Hardware Guide 6/28

1 Foreword

1.1 Introduction

The document describes the electrical characteristics, RF performance, dimensions and application

environment, etc. of FG360-NA (hereinafter referred to as FG360). With the assistance of the document

and other instructions, the developers can quickly understand the hardware functions of FG360 modules

and develop products.

2 Overview

2.1 Introduction

The FG360 series module is a 5G module which supports NSA and SA network architectures. The FG360

integrates core devices such as Baseband, Memory, PMU, Transceiver, and PA. It supports 5G NR Sub6,

FDD-LTE, TDD-LTE, and WCDMA long-distance communication modes. Supports uplink 2×2 MIMO and

downlink 4×4 MIMO multi-antenna configuration in SA mode. It also supports GNSS wireless positioning

technology. The FG360 is designed in an LGA package and is suitable for a variety of eMBB scenarios,

such as CPE, VR/AR, gateway, TV box, and intelligent monitoring.

2.1.1Key Features

Table 2-1 Key features

Performance

Description

Operating Band

LTE FDD: B2, B4, B7,B5, B12, B13,B14,B17,B25,B26,B30,B66, B71

LTE TDD: B41 ,B48

NR: n2,n25, n41, n66, n71

WCDMA/HSPA+: B2,B4,B5

GNSS

Support GPS, GLONASS, Galileo, BDS, QZSS

3GPP Release 15

LTE

3GPP Release 15

UMTS

3GPP Release 8

Feature

NR:

DL 4×4 MIMO: n2,n25, n41, n66

UL 2×2MIMO: n41

FG360-NA Hardware Guide 7/28

LTE:

DL 4×4MIMO: B2, B4, B7, B25,B30,B66

NSA and SA supported

SRS: n41, Support: 1T2R, 1T4R, 2T4R

HPUE: B41, n41

Data Transmission

SA 5G/NR Sub-6 Peak

DL 4.67Gbps/UL 1.25Gbps

NSA Peak

DL 3.74Gbps/UL 700Mbps

LTE

DL 1.6Gbps (CAT19)/UL 211Mbps (CAT18)

UMTS/HSPA+

DL UMTS: 384kbps/UL 384 kbps

DL DC-HSPA+: 42 Mbps (CAT24)/UL 11.5Mbps

(CAT7)

Power Supply

DC: 3.3~4.4V, typical voltage: 3.8V

Antenna Type:

External

Antenna Gain:

<3.76dBi

Temperature

Normal operating temperature: -30~75℃1

Extended operating temperature: -40~85℃2

Storage temperature: -40~85℃

Physical

characteristics

Dimension: 41 mm×44mm×2.75 mm

Package: 430 pin LGA

Weight: about 12.0 g

CPU

ARM Cortex-A55, quad core, up to 2.0 GHz

Memory

2GB LPDDR4x+32GB eMMC Flash

Interface

USB Interface

USB2.0 high speed (HS) interface, data transmission rate up to 480Mbps

USB3.0 Super-speed (SS) interface, data transmission rate up to 5Gbps

PCIe Interface

PCIe Gen3 2Lane×1, PCIe Gen3 1Lane×2 (PCIe only support RC mode)

SIM Interface

Dual SIM: 1.8V/3V

SIM1: USIM

SIM2: ESIM/USIM

I2C

One set of I2C interface, data transmission rate up to 400Kbit/s

ADCs

A/D conversion channel, Voltage Range: 0~1.45V

Software

Firmware update

USB/PCIe/FOTA

Operating System

Linux/Android/Windows

FG360-NA Hardware Guide 8/28

Note：

1. When temperature keeps in the range of -30~75°C, the module can work normally. Module

performance meets the 3GPP specifications.

2. When temperature keeps in the range of -40~85°C, module performance may be slightly out of

3GPP specifications.

FG360-NA Hardware Guide 9/28

2.2 Application Framework

The application framework below shows the main hardware functions of the FG360 module:

Baseband

RF transceiver

PMU

Memory

Peripheral interface

Main PMU

ET TRX Blocks

Transceiver

DRF

RFFE

Baseband

eMCP

eMMC

LPDDR4X

BBCLK

26MHz

RFCLK

26MHz

Sleep CLK

32KHz

SPMI

ANT0 ANT1 ANT2 ANT3 ANT4 ANT5 GNSS

PWRKEY

RESET_N

VBAT

JTAG

USIM1 SDIO PCIe3.0

Coex

UART I2S

SGMII

GPIO/EINT USB2.0/3.0 UART

eSIM

I2C

SPI ADCs MIPI

DSI

26MHz

Crystal

Sub PMU

Figure 2-1 Hardware block diagram

FG360-NA Hardware Guide 10/28

2.3 Antenna Configuration

FG360 module supports seven antennas and the configuration is as below table:

PAD

Function

Description

Band

Configuration(TX)

Band

Configuration(RX)

Frequency

Range(MHz)

130

LMHB TRX

B2/4/5/7/12/13/14/17/

25/30/41/66/71

n2/25/41/66/71

B2/4/5/7/12/13/14/17/25/30/

41/66/71

n2/25/41/66/71

617~2690

175

41TRx+MHB/UCB/

LAA Rx

B41

n41

B2/4/7/25/30/41/48/66

n2/25/41/66

1710~5925

157

MHB/UCB/LAA Rx

Only SRS

B2/4/7/25/30/41/48/66

n2/25/41/66

1930~5925

139

LMHB Rx

Only SRS

B2/4/5/7/12/13/14/17/25/30/

41/66/71

n2/25/41/66/71

617~2690

148

Reserved

193

Reserved

199

GNSS

GNSS receive

2.4 Waring

2.4.1 Important Notice to OEM integrators

1. This module is limited to OEM installation ONLY.

2. This module is limited to installation in fixed applications, according to Part 2.1091(b).

3. The separate approval is required for all other operating configurations, including portable

configurations with respect to Part 2.1093 and different antenna configurations

4. For FCC Part 15.31 (h) and (k): The host manufacturer is responsible for additional testing to verify

compliance as a composite system. When testing the host device for compliance with Part

15 Subpart B, the host manufacturer is required to show compliance with Part 15 Subpart B while the

transmitter module(s) are installed and operating. The modules should be transmitting and the evaluation

should confirm that the module's intentional emissions are compliant (i.e. fundamental and out of band

emissions). The host manufacturer must verify that there are no additional unintentional emissions other

than what is permitted in Part 15 Subpart B or emissions are complaint with the transmitter(s) rule(s).

The Grantee will provide guidance to the host manufacturer for Part 15 B requirements if needed.
