FERREX FAPS 20-I Manual de usuario

20 V LI-ION CORDLESS

JIGSAW

User Manual

ID: #05007

User-friendly

Manual

Original instructions

Package contents........................................................................ 3

Components .......................................................................................6

General information.................................................................... 7

Reading and storing the user manual ........................................... 7

Explanation of symbols .................................................................... 7

Safety ...........................................................................................8

Explanation of notes .........................................................................8

Proper use...........................................................................................8

Residual risks......................................................................................9

General safety notes for power tools..............................................9

Using and handling the power tool...............................................11

Cordless tool use and care...............................................................12

Preparation ............................................................................... 14

Protective cover ............................................................................... 14

Attaching the sliding shoe ............................................................. 15

Inserting/changing the saw blade............................................... 15

Adjusting the saw shoe for mitre cuts.......................................... 16

Dust blower function........................................................................17

Attaching the shaving/chip extraction system ...........................17

Attaching the parallel guide.......................................................... 18

Using the rechargeable battery.................................................... 18

Charging the rechargeable battery ............................................. 19

Inserting and removing the rechargeable battery ................... 19

Operation................................................................................... 19

Setting the stroke rate .................................................................... 19

Setting the pendulum stroke ........................................................20

Switching the product on and off ................................................. 21

Sawing............................................................................................... 21

Sawing out sections ........................................................................ 22

Performing plunge cuts .................................................................22

Troubleshooting........................................................................ 23

Cleaning and maintenance....................................................... 23

Storage ...................................................................................... 24

Transport ................................................................................... 24

Replacing the carbon brushes ......................................................24

Technical data ........................................................................... 25

Rechargeable battery and charger information........................25

Noise/vibration information .................................................... 26

Disposal...................................................................................... 28

Disposing of the packaging ...........................................................28

Disposing of the product ................................................................28

Declaration of conformity......................................................... 29

Contents

Package contents

Dok./Rev.-Nr. 197376_20190708

2 3 4

13 12 11 10 9 8

Package contents

D E

15 16 17

18 19

Package contents

J K

13 9

Package contents

Components

1Dial for the stroke rate control

2Locking key for On/Off switch

3On/Off switch

4Handle

5Battery holder

6Sliding switch for dust blower function

7Saw shoe

8Sliding shoe

9Pendulum stroke adjustment

10 Guide roller

11 Saw blade holder

12 Locking screws (Parallel guide)

13 Protective cover

14 Locking lever for saw shoe

15 Saw blade

16 Parallel guide

17 Adapter for shaving/chip extraction system

18 LED light

19 Directional guide

General information

Reading and storing the user manual

This user manual accompanies this 20 V Li-ion cordless Jigsaw (referred

to below only as the ‘product’). It contains important information on

safety, usage and care.

Before using the product, read the user manual carefully. Pay particular

attention to the safety instructions and warnings. Failure to comply with the

instructions in this user manual may result in severe injury or damage to the product.

You must comply with applicable local or national regulations concerning the use of

this product. Keep this user manual in a safe place for future reference. Make sure to

include this user manual when passing the product on to third parties.

This user manual can be downloaded in PDF format from our website at

www.conmetallmeister.de.

Explanation of symbols

The following symbols are used in this user manual, on the product or on the

packaging.

This symbol provides you with useful supplementary information on

assembly or use.

Declaration of conformity (see chapter ‘Declaration of conformity’):

Products marked with this symbol meet all applicable Community

regulations for the European Economic Area.

Read the user manual.

Wear protective goggles.

Wear a dust mask.

Wear ear protection.

Wear suitable secure footwear.

Safety

Wear suitable protective gloves.

Safety

Explanation of notes

The following symbols and signal words are used in this user manual.

WARNING!

Indicates a hazardous situation that, if not

avoided, could result in death or serious injury.

CAUTION!

Designates a dangerous situation that may result

in minor or moderate injury if not avoided.

NOTICE!

Warns of possible damage to property.

Proper use

The product is only suitable for private use – such as for hobbies or do-it-yourself

work – when undertaking the following:

• for cutting wood, metal, plastic,

• for straight cuts and cutting at angles (only for wood and plastics) with a mitre of

15°, 30° and a max. of 45°.

Any other applications are expressly prohibited and are deemed improper use.

This product does not come with a rechargeable battery or charger. These must be

bought separately: The product can be operated with the 20 V rechargeable battery

or with the 20/40V rechargeable battery available from Activ Energy®. Only use the

rechargeable batteries specified in the chapter ‘Technical data’ for the product. Do not

operate the product with rechargeable batteries from other manufacturers.

Neither the manufacturer nor the retailer can accept any responsibility for injury,

loss or damage caused by misuse of this product of any kind. Examples of misuse are

given in the following non-exhaustive list:

• using the product for other purposes other than those intended;

• failure to observe the safety instructions and warnings as well as the assembly,

operating, maintenance and cleaning instructions contained in this user manual;

Safety

• failure to comply with any regulations relating to accident prevention,

occupational health or safety, which speciﬁcally and/or generally apply to the use

of the product;

• use of accessories and spare parts not intended for the product;

• changes to the product;

• product repairs performed by parties other than the manufacturer or a qualiﬁed

professional;

• use of the product for commercial, artisan or industrial purposes;

• operation or maintenance of the product by persons not familiar with how to

handle the product and/or who are not aware of the related risks.

Residual risks

Despite proper use, inconspicuous residual risks cannot be completely ruled out.

The following risks may arise due to the design of the product:

• touching the exposed areas of the saw blade (cut injury);

• reaching into the rotating saw blade (cut injury);

• kickback of the work piece and parts of the work piece if used improperly;

• contact with projectile fragments of the saw blade in the event of breakage (cut

injury);

• loss of hearing if the required ear protection is not worn when working with the

device (hearing loss);

• contact with electrical current due to a defective or cut supply cable, motor

housing (electrical shock);

• emission of wood dust (injury to health);

• injury to health attributed to hand and arm vibration if the saw is not guided in a

controlled manner and maintained properly.

General safety notes for power tools

WARNING Read all the safety notes, instructions, illustrations and

technical details supplied with this power tool. Failure to follow the safety

notices and instructions may result in an electric shock, fire and/or severe

injury.

Keep all safety notes and instructions for future reference.

The term “power tool” used in the safety instructions refers to mains-operated

power tools (corded) and battery-powered power tools (cordless).

Safety

Work place safety

a) Keep your work area clean and well lit.

Cluttered or dark areas

invite accidents.

b) Do not work with the power tool in areas with a risk of explosion

where ﬂammable liquids, gases or dusts are present.

Power tools

create sparks which may ignite the dust or fumes.

c) Keep children and other persons away from the power tool while

you are using it.

If you are distracted, you could lose control of the

power tool.

This jigsaw is not intended to be used by children or persons with

impaired physical, sensory or mental abilities or those without

sufﬁcient experience or knowledge.

Electrical safety

a) The connector plug for the power tool must ﬁt in the socket. The plug

must not be modiﬁed in any way. Do not use any adapter plugs in

combination with power tools with protective earthing.

Unmodiﬁed

plugs and matching outlets will reduce the risk of electric shock.

b) Avoid body contact with earthed surfaces like pipes, heaters,

stoves and refrigerators.

There is an increased risk of electric shock

if your body is earthed or grounded.

c) Keep power tools away from rain or moisture.

Water entering a

power tool will increase the risk of electric shock.

d) Do not use the cord for improper purposes such as for carrying

the power tool, for hanging it up or for pulling or unplugging

it from the socket. Keep cord away from heat, oil, sharp edges

and moving parts.

Damaged or entangled cords increase the risk of

electric shock.

e) When operating a power tool outdoors, use only extension cords

that are suitable for outdoor use.

Use of a cord suitable for outdoor

use reduces the risk of electric shock.

f) If operating the power tool in a damp environment cannot be

avoided, use a RCD.

Use of an RCD reduces the risk of electric shock.

Safety of persons

a) Be careful, pay attention to what you are doing and approach

work with a power tool in a reasonable manner. Do not use

Tabla de contenidos

Otros manuales de Herramientas eléctricas de FERREX

FERREX

FERREX Z1G-DS-65H Hoja de información del producto

FERREX

FERREX DC-180E-1 Manual de usuario

FERREX

FERREX TD9511 Manual de usuario

FERREX

FERREX FM300 Manual de usuario

Manuales populares de Herramientas eléctricas de otras marcas

AEG

AEG OMNI-JS Manual de usuario

SIP

SIP 01533 Manual de usuario

Ribimex

Ribimex PRS499 Manual de usuario

3M Fiber Optic Connector Crimp Tool Manual de usuario

Ryobi

Ryobi P524 Manual de usuario

ROJEK

ROJEK FSN 300A Manual de usuario

Kemper

Kemper 1740PRO Manual de usuario

WABCO

WABCO OptiTire Manual de usuario

EINHELL

EINHELL TE-MS 18/210 Li Manual de usuario

Orgapack

Orgapack OR-T 85 Guía rápida

TOUGHCUT

TOUGHCUT Diamond 400 Manual de usuario

Yaros

Yaros PB-3603 Manual de usuario

Fein

Fein BSS 2.0 E Guía de configuración

Baileigh Industrial

Baileigh Industrial SS-2725 Manual de usuario

Milwaukee

Milwaukee 2674-20 Manual de usuario

Fein

Fein BLs 1.6 Manual de usuario

Princess

Princess Electric Multi Sharpener Manual de usuario

FOREDOM

FOREDOM K.1050 Manual
