FERREX 13177 Manual de usuario
User Manual
Product
Info
51.7CC 2 STROKE
PETROL BACKPACK
BLOWER
https://help.tools
Read all safety warnings and all instructions thoroughly before operating this product.
Ensure you keep your manual in a safe place for future reference.
IM Ed4 02/2020
13177
QR codes take you where you want to go
quicky and easily
Whether you require product information, spare parts or accessories,
details on warranties or after sales service, or if you want to watch
a product demonstration video, our QR codes will take you there in
no time at all.
What is a QR code?
A QR-code (QR=Quick Response) is a type of matrix that can be read
with a smartphone camera and that contains a link to a website or
contact details, for example.
Advantage: You are not required to manually enter a website address
or contact details.
How it works
To scan the QR code, all you need is a smartphone with QR codes
reader
software and an Internet connection*. This type of software can be
downloaded for free from your smartphone’s app store.
Try it out now
Just scan the QR code with your smartphone and
nd out more about the Aldi product you have
purchased*.
* Depending on your tari you may be charged for the connection.
Product
Info
Contents
Pack contents / parts 2
Description of symbols 3
General Safety Warnings 4
Additional safety rules for Petrol Blowers 9
Parts List 11
Assembly 14
Preparation 19
Operation 23
Maintenance 29
Storage and Transportation 32
Environmental Protection 32
Noise and vibration 33
Warranty 34
Troubleshooting 36
Specications 37
Pack contents / parts
Congratulations on the purchase of your Ferrex® 51.7cc 2 Stroke Petrol Backpack
Blower. When you open your packaging, rst remove all items and check there
are no parts damaged or missing. If you nd anything wrong, do not operate the
product until the parts have been replaced or the fault has been rectied. Failure
to do so could result in serious personal injury.
Intended use of 51.7cc 2 Stroke Petrol Backpack Blower
NOTE: This product is for private domestic DIY use only. It is not suitable for
commercial or trade use.
This 51.7cc 2 Stroke Petrol Backpack Blower is designed for moving leaves and
other garden debris; perfect for patios and driveways.
IMPORTANT INFORMATION.
NOTE: This is a 51.7cc 2 Stroke Petrol Backpack Blower. The fuel tank must be
lled with a 40:1 mix of fuel and 2 stroke oil. Fresh unleaded fuel must be used in
this unit.
Do NOT use Ethanol based fuels. Use good quality 2 Stroke oil.
NOTE: First time users or inexperienced operators pay particular attention to the
operation of the Blower, including details of starting and stopping and correct
use of the Blower on pages 23-27, as well as the maintenance instructions on
pages 28-30.
Contents of carton
1 x 51.7cc Petrol Backpack Blower
1 x Flexible pipe with 2 adjustable
clamps (not tted)
1 x Upper blow tube with tting clamp
ring for throttle handle (not tted)
1 x Middle blow tube with
assembly screw (not tted)
1 x Lower blow tube with
assembly screw (not tted)
1 x Throttle control handle (not tted)
1 x Socket spanner for spark plug
1 x Combination screwdriver
(Philips / slot type)
1 x Fuel / Oil mixing bottle
1 x Instruction manual
1 x Warranty Card & Certicate
1 x Quick Start Guide
2
Description of symbols
3
The instruction manual, rating plate, or on the product itself, may show
these symbols. These represent important information about the product or
instructions on its use.
Read instruction manual before operating this machine
Keep bystanders away. Beware of objects being ung out. Use at a distance of at
least 15m from other people.
Warning of hazard. Risk of hand and feet injuries.
Warning
Explosive material
Extremely hot surface. Do not touch a hot muer, gear box or cylinder, you may
get burned. These parts get extremely hot from operation and remain hot for a
short time after the unit is turned o.
Conforms to relevant standards for electrical safety and electromagnetic compatibility.
Wear breathing protection. Wear hearing protection. Wear eye protection
Do not put in water or expose to rain.
Wear protective gloves
Wear protective footwear
60 Months Warranty (5 years)
General safety warnings
4
Safety instructions
WARNING! Read and understand all instructions. Failure to
follow all instructions listed below may result in electric
shock, re and/or serious injury.
The term“power tool”in all of the warnings below refers to your mains-
operated (corded) power tool, garden power tool, battery-operated
(cordless) power tool or your petrol operated garden tool.
Save these instructions
Work area
• Ensure the area to be blown is clear and free of debris, rocks, gravel,
garden furniture etc.
• Keep work area clean and well lit. Cluttered and dark areas invite
• accidents.
• Do not operate power tools in explosive atmospheres, such as in
the presence of ammable liquids, gases, or dust. Power tools create
sparks which may ignite the dust or fumes.
• Ensure all animals, children and bystanders are at least 20m away
while operating this blower. Distractions can cause you to lose control.
Personal safety
• Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the inuence of drugs, alcohol, or medication. A moment of
inattention while operating power tools may result in serious personal
injury.
• Use safety equipment. Always wear eye protection. Safety equipment
such as a dust mask, non-skid safety shoes, hard hat, or hearing pro-
tection used for appropriate conditions will reduce personal injuries.
5
• Remove any adjusting key or spanner before turning the tool on. A span-
ner or a key that is left attached to a rotating part of the power tool may
result in personal injury.
• Do not overreach. Keep proper footing and balance at all times. This ena-
bles better control of the power tool in unexpected situations.
• Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
• If devices are provided for the connection of dust extraction and collection
facilities ensure that these are connected and properly used. Use of these
devices can reduce dust-related hazards.
Power tool use and care
• Do not force the power tool. Use the correct power tool for your applica-
tion. The correct power tool will do the job better and safer at the rate for
which it was designed.
• Do not use the power tool if the switch does not turn it on and o. Any
power tool that cannot be controlled with the switch is dangerous and
must be repaired.
• Turn tool o completely before making any adjustments, changing acces-
sories, or storing power tools. Such preventive safety measures reduce the
risk of starting the power tool accidentally.
• Store idle power tools out of the reach of children and do not allow per-
sons unfamiliar with the power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands of untrained users.
• Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may aect the power tool’s
operation. If damaged, have the power tool repaired before use. Many ac-
cidents are caused by poorly maintained power tools.
• Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
• Use the power tool, accessories and tool bits etc., in accordance with these
instructions and in the manner intended for the particular type of power
tool, taking into account the working conditions and the work to be per-
formed. Use of the power tool for operations dierent from intended could
result in a hazardous situation.
Safety rules for Petrol Backpack Blowers
Training
• Read the instructions carefully. Get familiar with the controls and proper
use of the equipment.
• Non-skilled persons and rst time users should read and understand the
full instruction manual before proceeding with use of the product or
recommended maintenance tasks.
• Only use the blower for the purpose for which it was designed, i.e.
blowing garden debris. Any other use can be hazardous, causing dam-
age to the machine.
• Never allow children or people unfamiliar with these instructions to use
the blower. Local regulations may restrict the age of the operator.
• Never use the blower:
– When people, especially children, or pets are nearby.
– If the operator has taken medicine or substances that can aect his abil-
ity to react and concentrate.
• Remember that the operator or user is responsible for accidents or haz-
ards occurring to other people or their property.
• Do not use unit around people with long hair.
• Dress appropriately. Do not operate with loose clothing or jewellery.
Ensure there is a gap between the air intake and the operator.
Preparation
• While blowing always wear sturdy non-skid footwear and long trousers.
Do not operate the equipment with bare feet or open sandals.
WARNING: DANGER!
Engine fuel is highly ammable:
– Store fuel in containers specically designed for this purpose.
– Refuel using a funnel and outdoors only. Do not smoke while refuelling
or whenever handling the fuel.
– Add fuel before starting the engine. Never remove the cap of the fuel
tank or add fuel while the engine is running or when the engine is hot.
– If fuel is spilled, do not attempt to start the engine but move the ma-
6
chine away from the area of spillage and avoid creating any source of igni-
tion until the fuel has evaporated and the vapour dispersed.
– Replace all fuel tanks and containers caps securely.
• Substitute faulty silencers.
• Before use, always inspect the machine and check that the screws are not
worn or damaged.
• It is advisable to wear suitable eye protection (safety glasses) ear protec-
tion, and sturdy gloves when operating the blower.
• Always check for any objects that may block the air intake screen before
beginning work. A clogged air intake reduces the machine’s blowing ca-
pacity and increases the engine’s working temperature, which can result in
engine failure. Stop the engine and remove the object.
Maintenance and storage
• Keep all nuts, bolts and screws tight to be sure the equipment is in safe
working condition. Regular maintenance is essential for safety and perfor-
mance.
• Never store the equipment with fuel in the tank inside a building where
vapour may reach a ame or a spark or a source of extreme heat i.e a water
heater.
• Allow the engine to cool before storing in an enclosed space.
• To reduce the re hazard, keep the engine, exhaust silencer, battery
compartment (if applicable) and fuel storage area free of grass, leaves, or
excessive grease.
• If the fuel tank has to be drained, this should be done outdoors and when
the engine is cool.
• For reasons of safety, do not use the equipment with worn or damaged
parts. Parts are to be replaced and not repaired. Parts that are not of the
same quality can damage the equipment and be dangerous for your
safety.
• Fuel goes o fairly quickly. If you nd your blower does not start, rst
change the fuel in the tank with newly purchased fuel.
Service
• Have your power tool serviced by a qualied repair personnel using only
7
identical replacement parts (recoil starter, spark plug, collection bag,
tubes, blades / impellor). This will ensure that the safety of the power
tool is maintained.
Operation safety instructions
WARNING. Stop the engine and unplug the spark plug before
any repairs or maintenance operations.
• This machine is extremely noisy and operators must wear acoustic
protection equipment.
• Rotating parts can cause serious injury, avoid contacting the rotating
parts when is still rotate.
• Try not to cause any disturbance. Use this machine at reasonable
times of the day only (not early morning or late evening when the
noise could cause disturbance).
• Check that all nuts, bolts and screws are well tightened before every
use.
• Do not run the engine in an enclosed and/or poorly ventilated area.
The gas of the engine contains carbon monoxide, which is dangerous
to your health.
• Work only when there is sucient light.
• Do not use the blower when it is raining or when the grass is wet.
• Do not use the blower near open windows due to possible debris
entering.
• Caution must be taken while blowing on slopes.
• Turn o the engine if you must leave the blower unattended.
• Never change the rated speed of the engine in any way.
• Stop the engine and remove the spark plug cover in these cases:
– Before any maintenance, repairing or checking operations.
– If you leave the blower unattended.
– If the blower vibrates in an abnormal way, take the blower to an au-
thorised service centre.
– Check the bolts and nuts regularly. Bolts and nuts may vibrate loose
over time.
8
Tabla de contenidos
Otros manuales de Soplador de FERREX
