Page 6
FEATURES
Fibre Optic.
o Connector: FC/PC.
o Fibre: Mono Mode.
o Maximum Distance: 5km.
Video.
o Connector: BNC 75-5.
o Video Signal:1Vpp (75 Ohm).
o Noise Signal Ratio (NSR) >67dB.
o Bandwidth: 5Hz – 10MHz.
Data.
o Connector: 2.5mm, 4 terminal grid.
o Protocol: RS-485.
o Speed:< 300Kbps.
o Operating Mode: full duplex.
Audio.
o Connector: 2.5mm, 4 terminal grid.
o Input/Output Impedance: 600 Ohm.
o Input/Output Level: 0dBm.
o Frequency Response: 10Hz – 20 KHz.
o Noise Signal Ratio: 80dB.
Contact.
o Connector: 2.5mm, 4 terminal grid.
o Input Contact: 0/5V opto-coupled. Contact Opening/Closing Transmission.
o Output Contact: 0.1A relay
Environmental Requirements.
o Operating Temperature: -20º C ~ +85º C
o Relative Humidity: 10% ~ 95%
