FeiYu Tech Pocket 3 Manual de usuario
Stabilized Camera Instructions
Tutorial
V 1.0
Catalogue
1. Overview …………………………………………………………………………… 1
2. List …………………………………………………………………………………… 1
3. Start to Use ………………………………………………………………………… 2
3.1 Charging ………………………………………………………………………………………… 2
3.2 Insert MicroSD card …………………………………………………………………………… 2
3.3 Mount the expansion base …………………………………………………………………… 3
3.4 Usage for protective cover …………………………………………………………………… 3
4. Operation ………………………………………………………………………… 4
4.1 Follow mode introduction …………………………………………………………………… 4
4.2 Power button …………………………………………………………………………………… 4
4.3 Gimbal mode button ………………………………………………………………………… 4
4.4 Shutter button ………………………………………………………………………………… 4
4.5 Indicator light instructions …………………………………………………………………… 5
4.6 Gimbal calibration …………………………………………………………………………… 5
4.7 Reset …………………………………………………………………………………………… 5
5. Using the FeiyuCam App ……………………………………………………… 6
5.1 Connect with Feiyu Pocket 3 via Wi-Fi ……………………………………………………… 6
5.2 Camera Interface ……………………………………………………………………………… 6
5.3 Firmware update ……………………………………………………………………………… 8
6. Optional accessories …………………………………………………………… 9
6.1 Remote handle (Optional) …………………………………………………………………… 9
6.2 Smartphone holder (Optional) …………………………………………………………… 10
6.3 Extension Bar (Optional) …………………………………………………………………… 10
6.4 Waterproof Case (Optional) ……………………………………………………………… 11
7. Specications ………………………………………………………………… 13
Suggestion
This product includes below information, please read the information before
using it.
(1) Quick start guide
(2) Online instruction
(3) Tutorial
Tutorial
* The tutorial videos can be watched at FeiyuTech ocial website or scan the QR code.
https://www.feiyu-tech.com/play/
Download APP
Connect with FeiyuCam App to achieve more functions.
Scan the QR code to download the app, or search for "FeiyuCam" in the App Store or
Google Play.
* Requires iOS 13.0 or above, Android 6.0 or above.
iOS Android
- 1 -
1. Overview
Please tear lens lm before using
[1]
[9]
[12]
[13]
[11]
[2]
[3]
[4]
[6]
[7]
[5]
[10]
[8]
[1] Power button
[2] Screen
[3] Microphone
[4] USB-C charging port
[5] Dovetail slot
[6] Tilt axis
[7] Camera lens
[8] Pan axis
[9] Shutter button/ Indicator
[10] Gimbal mode button
[11] Roll axis
[12] MicroSD card slot
[13] Magnetic base
2. List
② ③ ④ ⑥ ⑦ ⑧
①⑤
① Feiyu Pocket 3 x 1
② Expansion base x 1
③ Tripod x 1
④ Protective cover x 1
⑤ USB-C cable x 1
⑥ Wristband x 2
⑦ Portable bag x 1
⑧ Manual x 1
- 2 -
3. Start to Use
(1) Please fully charge the battery before powering on the product for the
rst time.
(2) When not in use, power o the product.
3.1 Charging
Connect USB-C cable with charging port to charge.
We recommend that you charge your camera at least once a month.
Charging status While working (screen status) While o (indicator status)
Charging Display Red light is on
Complete Disappear Light is o
Indicator 5V 2A
3.2 Insert MicroSD card
An UHS - Ⅰ Speed Grade 3 (U3) rating microSD card
(equipped by user) is required.
Please format the microSD card with Feiyu Pocket 3
when insert it at the rst time.
- 3 -
3.3 Mount the expansion base
Slide the magnetic base (the bottom part of Feiyu Pocket 3)
into the expansion base as shown in the gure. And make
the ball on the expansion base clip in the dovetail slot.
Slide it in the opposite direction of mounting to take o.
Use the expansion base to install tripod, wristband, and other accessories via the 1/4
inch screw hole and wristband slot on the base.
3.4 Usage for protective cover
When not in use, please cover the gimbal with the protective cover.
Hold the two sides of protective cover (which have an opening) rmly, and push it
down to cover the camera (As the picture shown below). Reveal the charging port
through the opening which is larger.
Pull the protective cover up in the same way in opposite direction to take it down.
Hold
Firmly 按压
Hold
Firmly 按压
Hold
Firmly 按压
- 4 -
4. Operation
4.1 Follow mode introduction
Pan mode (HF): Pan follow, only the pan axis follows the movement of user's hand.
Follow mode(TF): Pan and tilt follow, where both the pan and tilt axes follow the movement
of user's hand, but roll axis does not.
All follow mode(AF): Pan, tilt and roll follow, where all 3 axes follow the movement of user's
hand.
Lock mode(LK): All 3 axes do not follow the movement of user's hand, gimbal keeps the
direction of the camera xed.
Diving mode(DV): A follow mode which use with waterproof case for Feiyu Pocket 3 (optional).
In this mode, lens turn upward, and all 3 axes follow the movement of user's hand.
4.2 Power button
Long press for 1s: Power ON/ OFF
Single tap: Switch among photo mode/ video mode/ recently
used function
Single tap (Connect computer when the camera is on):
switch between PCCAM/Udisk mode
Long press for 8s: Power o forcely
4.3 Gimbal mode button
Single tap: Follow mode/All follow mode/Pan mode (Switch in
turn)
Double tap: Recenter
Triple tap: Enter/ Exit sele mode
Tap four times: Enter diving mode (Single tap again to exit)
Press and hold: Enter lock mode
4.4 Shutter button
Single tap: Start recording/ Stop recording/ Take photo
Long press for 3s: Turn on/ o Wi-Fi
- 5 -
4.5 Indicator light instructions
Indicator status Indicator status (While OFF)
Take photo Recording Update
rmware Charging Complete
Green light ash once Green light keeps ashing Red light is on Light is o
Indicator
4.6 Gimbal calibration
When camera is not level, users can use calibration
function to x.
Method: Press the power button and gimbal mode
button at the same time
4.7 Reset
Reset the camera parameters to factory default
Settings
Method: Press the power button and shutter button
at the same time
- 6 -
5. Using the FeiyuCam App
5.1 Connect with Feiyu Pocket 3 via Wi-
Fi
Turn on FeiyuCam App, tap [ Feiyu Pocket ] option,
long press shutter button to turn on Wi-Fi, follow
the prompts to connect Feiyu pocket 3.
MANUAL CONNECTION
CONNECT OTHER DEVICES
Home
Album
Feiyu Pocket
Steps
1. Long press round button to turn on WI-FI.
2. Enter WI-FI code to connect new devices.
Feiyu Pocket 3
CONNECTING DEVICES VCAM_XXXX
No device connected
Help
Connect pocket
5.2 Camera Interface
[1] [2] [3] [4] [5] [6]
[7]
[8]
[9]
[10]
[11]
[12][13]
[14][15][16]
[17]
[18]
[19]
[22]
[20]
[21]
[1] Album Enter album
- 7 -
[2] Lock Screen orientation lock
[3] Gesture shooting Make a "V" gesture in front of the camera to take
photo or start recording.
[4] Battery indicator Show battery level of Feiyu pocket.
[5] File format Prompt the le format of the saved le.
[6] Storage spaces Display remaining storage spaces.
[7] Mirror Images from the camera are mirrored after turn it
on.
[8] Recenter Lens return to center and keep towards front or
back as before.
[9] Shoot Start recording or take photo.
[10] Camera turn
around
Camera horizontally rotate 180° to shoot, which can
be used to take sele
[11] Camera settings Set parameters of current shooting mode, format
microSD card, view device information.
Modes
Parameter
Photo-
graph Video Slow
motion Timelapse Panoramic
photo Hyperlapse
Viewing angle √ √
Anti-icker √ √ √ √ √ √
Grid √ √ √ √ √ √
Watermark √ √ √ √ √
Proportion √
Photo format √
Video format √ √ √ √
Color √ √ √ √
White balance √ √ √ √ √ √
Panoramic mosaic √
[12] Joystick
Long press the circle and turn left and right to
control pan axis, turn up and down to control tilt
axis.
[13] Exposure
compensation Set or display current exposure compensation.
[14] ISO Set or display current ISO.
