Fein ABOP 6 Guía de configuración

ABOP 6, 10, 13-2

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.08 1/69 Version 1

Repair instructions

ABOP 6, 10, 13-2

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.08 2/69 Version 1

1. Models described

2. Technical data

3. Provisions

4. Tools required

5. Lubricants and auxiliary substances required

6. Disassembly

7. Assembly

8. Troubleshooting

9. Connection diagram

Contents

ABOP 6, 10, 13-2

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.08 3/69 Version 1

These instructions describe how to repair the following models:

Model Order no.

ABOP 6 710501

ABOP 10 710502

ABOP 13-2 710503

1. Models described

ABOP 6, 10, 13-2

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.08 4/69 Version 1

2. Technical data

Technical data

The complete technical data can be found in the operating instructions for the model.

Test data

Up-to-date test data for all models can be found on the FEIN Extranet (Customer Service → Repair Guides).

Lubricants

The lubricants and container sizes available from FEIN can be found on the FEIN Extranet (Customer Service

→ Repair Guides).

Lists of spare parts

Lists of spare parts and exploded views are available online at www.fein.com

ABOP 6, 10, 13-2

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.08 5/69 Version 1

3. Provisions

Provisions

Please note that power tools may only be repaired, maintained and checked by a trained

electrician, as improper repair can result in serious risks to the user.

The provisions set out in DIN VDE 0701-0702 should be observed after repairs.

Only use original FEIN spare parts!

The relevant accident prevention regulations of the employers’ liability insurance associations are

to be observed when commissioning.

The German Equipment and Product SafetyAct applies for correct use.

Outside Germany, the regulations applicable in the relevant country must be observed!

ABOP 6, 10, 13-2

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.08 6/69 Version 1

4. Tools required

Standard tools

Torx 15 and 20 screwdrivers

Small slotted screwdriver

Arbor press

Plastic hammer

Slide gauge

Cable hooks

Circlip pliers

Special tools

Unlocking tool

Arbor

Sleeve: Inner diameter 55 mm

Outer diameter 65 mm

Sleeve: Inner diameter 15 mm

Outer diameter 25 mm

Sleeve: Inner diameter 7 mm

Outer diameter 30 mm

Ball bearing support 19 mm

Ball bearing puller 15 mm 6 41 07 015 00 0

Ball bearing puller 19 mm 6 41 07 019 00 7

Drawing-off socket cap 6 41 04 150 00 8

Open-ended spanner 17 mm (width 4 mm) 6 29 03 002 00 9

Test board 6 41 340 0100 0

NOTE

You can only order special tools with an

order number from FEIN.

ABOP 6, 10, 13-2

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.08 7/69 Version 1

4. Tools required

Special tools

Unlocking tool

FEIN recommends using this unlocking tool because it is designed

precisely for the plug contact used.

Order no.: 1-1579007-6 (not available from FEIN)

Manufacturers: www.te.com

ABOP 6, 10, 13-2

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.08 8/69 Version 1

5. Lubricants and auxiliary substances

required

Lubricants

ABOP 6

Grease 0 40 101 0100 4 12 g Gearbox

ABOP 10

Grease 0 40 101 0100 4 12 g Gearbox

Grease 0 40 205 0000 2 Bearing journal of spur gear shaft

ABOP 13-2

Grease 0 40 101 0100 4 25 g Gearbox

Grease 0 40 205 0000 2 Bearing journal of spur gear shaft

Sealants

ABOP 6, 10, 13-2

Surface seal Loctite 5188 Gearbox head

ABOP 6, 10, 13-2

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.08 9/69 Version 1

6. Disassembly

1. Remove battery.

2. Clamp socket wrench in drill chuck.

3. Firmly hold drill shaft with open-ended spanner.

4. Unscrew drill chuck with socket wrench. Tool:

-Open-ended spanner, 17 mm (width

4 mm)

6 29 03 002 00 9

-Socket wrench

ABOP 6, 10, 13-2

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.08 10/69 Version 1

6. Disassembly

1. Remove screws from gearbox head.

2. Remove gearbox head.

Tool:

-Torx 20 screwdriver
