Feig Electronic ID ISC.LRU1002 Manual de usuario

INSTALLATION

final –public (B)

2017-05-05 –M61110-2e-ID-B.docx

ID ISC.LRU1002 (EU: 4127.001.00; FCC: 4128.001.00)

UHF Long Range Reader

IDENTIFICATION

Installation

ID ISC.LRU1002

FEIG ELECTRONIC GmbH

Page 2 of 32

M61110-2e-ID-B.docx

Note

FEIG ELECTRONIC GmbH

Lange Strasse 4

D-35781 Weilburg

Tel.: +49 6471 3109-0

http://www.feig.de

With the edition of this document, all previous editions become void. Indications made in this manual may be

changed without previous notice.

Copying of this document, and giving it to others and the use or communication of the contents thereof are

forbidden without express authority. Offenders are liable to the payment of damages. All rights are reserved

in the event of the grant of a patent or the registration of a utility model or design.

Composition of the information in this document has been done to the best of our knowledge. FEIG

ELECTRONIC GmbH does not guarantee the correctness and completeness of the details given in this

manual and may not be held liable for damages ensuing from incorrect or incomplete information. Since,

despite all our efforts, errors may not be completely avoided, we are always grateful for your useful tips.

The instructions given in this manual are based on advantageous boundary conditions. FEIG ELECTRONIC

GmbH does not give any guarantee promise for perfect function in cross environments and does not give

any guaranty for the functionality of the complete system which incorporates the subject of this document.

FEIG ELECTRONIC call explicit attention that devices which are subject of this document are not designed

with components and testing methods for a level of reliability suitable for use in or in connection with surgical

implants or as critical components in any life support systems whose failure to perform can reasonably be

expected to cause significant injury to a human. To avoid damage, injury, or death, the user or application

designer must take reasonably prudent steps to protect against system failures.

FEIG ELECTRONIC GmbH assumes no responsibility for the use of any information contained in this docu-

ment and makes no representation that they free of patent infringement. FEIG ELECTRONIC GmbH does

not convey any license under its patent rights nor the rights of others.

IDENTIFICATION

Installation

ID ISC.LRU1002

FEIG ELECTRONIC GmbH

Page 3 of 32

M61110-2e-ID-B.docx

Contents

1. Safety Instructions / Warning - Read before start-up ! 5

2. Performance Features of Reader Family ID ISC.LRU1002 6

2.1. Performance features........................................................................................................6

2.2. Available reader types.......................................................................................................6

3. Installation 7

4. Terminals 8

4.1. Antenna Connection .........................................................................................................9

4.2. Power Supply................................................................................................................... 10

4.2.1. Power Supply via connection X2................................................................................10

4.3. Interfaces ......................................................................................................................... 11

4.3.1. Ethernet Interface on connector X1............................................................................11

4.3.2. USB Mini Interface on connector X3 .......................................................................... 11

4.3.2.1. USB-Stick Service-Functions.........................................................................12

4.3.2.2. Reading of Log and Service Data...................................................................12

4.3.2.3. Storing the reader configuration on a USB flash drive....................................13

4.3.2.4. Copy the configuration onto the reader (Config-Cloning)................................13

4.3.3. RS232 Interface on connector X4 ..............................................................................15

4.3.4. Data-Clock Interface on connector X4........................................................................ 16

4.4. Inputs and Outputs on connector X4............................................................................. 18

4.4.1. 24 V DC voltage on connector X4..............................................................................18

4.4.2. Digital Inputs on connector X4 ...................................................................................19

4.4.3. Digital outputs on connector X4 .................................................................................20

4.4.4. Relay output on connector X4.................................................................................... 21

5. Operating and Display Elements 22

5.1. Status LED....................................................................................................................... 22

5.2. Reset Push Button T1 .....................................................................................................23

5.3. Reader Power Adjustment..............................................................................................24

IDENTIFICATION

Installation

ID ISC.LRU1002

FEIG ELECTRONIC GmbH

Page 4 of 32

M61110-2e-ID-B.docx

5.3.1. EU reader according to EN302 208............................................................................24

5.3.2. FCC-Reader according to FCC 47 Part 15.................................................................25

6. Technical Data 26

7. Radio Approvals 29

7.1. Europe (CE)...................................................................................................................... 29

7.2. USA (FCC) and Canada (IC)............................................................................................30

7.2.1. USA (FCC) and Canada (IC) warning notices............................................................30

7.2.2. Label Information.......................................................................................................31

7.2.3. Installation with FCC / IC Approval.............................................................................31

7.2.4. USA (FCC) and Canada (IC) approved antennas ......................................................31

ANNEX A - Accessories 32

IDENTIFICATION

Installation

ID ISC.LRU1002

FEIG ELECTRONIC GmbH

Page 5 of 32

M61110-2e-ID-B.docx

Safety Instructions / Warning - Read before start-up !

The device may only be used for the intended purpose designed by for the manufacturer.

The operation manual should be conveniently kept available at all times for each user.

Unauthorized changes and the use of spare parts and additional devices which have not been

sold or recommended by the manufacturer may cause fire, electric shocks or injuries. Such

unauthorized measures shall exclude any liability by the manufacturer.

The liability-prescriptions of the manufacturer in the issue valid at the time of purchase are valid

for the device. The manufacturer shall not be held legally responsible for inaccuracies, errors,

or omissions in the manual or automatically set parameters for a device or for an incorrect

application of a device.

Repairs may only be executed by the manufacturer.

Installation, operation, and maintenance procedures should only be carried out by qualified

personnel.

Use of the device and its installation must be in accordance with national legal requirements

and local electrical codes .

When working on devices the valid safety regulations must be observed.

This device is not suitable to be used in places where children are present. Prevent children

access to the device.

Equipment is intended for use only in restricted access area.

Special advice for carriers of cardiac pacemakers:

Although this device doesn't exceed the valid limits for electromagnetic fields you should keep

a minimum distance of 25 cm between the device and your cardiac pacemaker and not stay in

an immediate proximity of the device respective the antenna for some time.

IDENTIFICATION

Installation

ID ISC.LRU1002

FEIG ELECTRONIC GmbH

Page 6 of 32

M61110-2e-ID-B.docx

Performance Features of Reader Family ID ISC.LRU1002

2.1.

Performance features

The reader has been developed for reading passive data carriers, so-called „Smart Labels“, using

an operating frequency in the UHF range. The output power is configurable in the range between

100 mW and 2 W. This allows read ranges of up to 12 m.

2.2.

Available reader types

The following readers are available:

Table 1: Available Reader Types

Order Number

Reader type

Description

4127.001.00

ID ISC.LRU1002-EU

Device version for Europe

4128.001.00

ID ISC.LRU1002-FCC

Device version for North America

4861.000.00

ID ISC.LRU1002-MA

Device version for Morocco

IDENTIFICATION

Installation

ID ISC.LRU1002

FEIG ELECTRONIC GmbH

Page 7 of 32

M61110-2e-ID-B.docx

Installation

The Reader is designed for wall-mount, including outdoors. Outdoors the reader should be

mounted like shown in the picture below to ensure the watertightness of the device.

Holes for mounting on a wall with countersunk head screws are provided in the housing. The

maximum head screw diameter should not exceed 8,0 mm. The thread diameter is 5,3 mm (M5

screws). The screws must have a minimum length of 45 mm depending on the installation

situation. It is not necessary to open the reader housing for installation.

Figure 1: Installation Drawing

IDENTIFICATION

Installation

ID ISC.LRU1002

FEIG ELECTRONIC GmbH

Page 8 of 32

M61110-2e-ID-B.docx

Terminals

On the lower side of the reader housing different connectors are positioned. Figure 2 shows the

arrangement of the connectors and Table 2: Connection terminals gives an overview on the avail-

able interfaces and signals. Table 3: Push button function shows the available push buttons.

Figure 2: Connection Overview

Table 2: Connection terminals

Connector

Description

ANT 1-4

Connection of the external antennas (Impedance 50)

10/100Tbase network connection with RJ-45

Power supply 24VDC ± 20%

USB Mini Interface

Digital input, digital output, relay output and RS232 interface

Table 3: Push button function

Push button

Description

Internal push button for complete configuration reset

ANT 1 - 4

IDENTIFICATION

Installation

ID ISC.LRU1002

FEIG ELECTRONIC GmbH

Page 9 of 32

M61110-2e-ID-B.docx

4.1.

Antenna Connection

The external SMA antenna connectors are positioned on the lower side of the reader.

The maximum tightening torque for the SMA sockets is 0.45 Nm (4.0 lbf in).

For supplying a DC voltage to external components e.g. the UHF antenna multiplexer ID

ISC.ANT.UMUX, it is possible to enable a supply voltage (24 V DC / max. 500mA) on the antenna

cable. This need to be configured in the reader.

Table 4: External antenna connection

Terminal

Description

ANT 1 - 4

Connection for external antennas (input impedance 50)

Figure 3: External antenna connection ANT1-4

CAUTION:

Exceeding the tightening torque will destroy the plug.

The activation of the DC voltage on the antenna cable can damage the antennas from other

manufacturers. It is recommend to use high resistance UHF antennas. For any further ques-

tions please contact the technical support.

IDENTIFICATION

Installation

ID ISC.LRU1002

FEIG ELECTRONIC GmbH

Page 10 of 32

M61110-2e-ID-B.docx

4.2.

Power Supply

4.2.1.

Power Supply via connection X2

The supply voltage of 24 V DC has to be connected to Terminal X2.

Figure 4: Connector X2 Pin assignment for power supply

Table 5: Pin assignment for power supply

Terminal

Abbreviation

Description

X2 / Pin 1

VDC

Supply voltage 24 V DC ±20 %

X2 / Pin 2

GND

Ground –supply voltage

CAUTION:

The reader has to be supplied by a limited power supply according EN 62368-1 Chapter Q.1,

or with a NEC Class 2/LPS certified power supply.

Each reader has to be supplied by a separate external power supply.

Reversing the polarity of the supply voltage on X2 may destroy the device.

External wiring for the power supply must fulfil the following norms/validation procedure:

Conductor Cross-section

Validation procedure

from 0,5 mm2 or bigger

IEC 60332-1-2 and IEC 60332-1-3

smaller than 0,5 mm2

IEC 60332-2-1 and IEC 60332-2-2

Tabla de contenidos

Otros manuales de Lector de tarjetas de Feig Electronic

Feig Electronic

Feig Electronic ID ISC.LRU3000 Manual de usuario

Feig Electronic

Feig Electronic OBID ID CPR.02.VP/AB-ATS Manual de usuario

Feig Electronic

Feig Electronic OBID classic-pro ID CPR.03.20-CD Manual de usuario

Feig Electronic

Feig Electronic OBID i-scan ID ISC.SPAD102 Manual de usuario

Feig Electronic

Feig Electronic OBID i-scan UHF Manual de usuario

Feig Electronic

Feig Electronic OBID i-scan ID ISC.MR200-EP Manual de usuario

Feig Electronic

Feig Electronic ID CPR30+ Manual de usuario

Feig Electronic

Feig Electronic OBID classic-pro Series Manual de usuario

Feig Electronic

Feig Electronic OBID ID ISC.LR1002 Manual de usuario

Feig Electronic

Feig Electronic ID ISC.LRU3500-EU Manual de usuario

Feig Electronic

Feig Electronic Obid ID RWA02.ABC-A Manual de usuario

Feig Electronic

Feig Electronic OBID i-scan ID ISC.MR100-A Manual de usuario

Feig Electronic

Feig Electronic IBID i-scan ID ISC.MR200 Manual de usuario

Feig Electronic

Feig Electronic ID RWA12.ABC-AK Guía del usuario

Feig Electronic

Feig Electronic OBID i-scan ID ISC.MR200-A Manual de usuario

Feig Electronic

Feig Electronic OBID i-scan UHF Manual de usuario

Feig Electronic

Feig Electronic ID ISC.PRH101-A Manual de usuario

Feig Electronic

Feig Electronic OBID i-scan ID ISC.PRH110-A Manual de usuario

Feig Electronic

Feig Electronic OBID i-scan ID ISC.LR200 Series Manual de usuario

Feig Electronic

Feig Electronic OBID i-scan ID ISC.LR2000 Manual de usuario

Manuales populares de Lector de tarjetas de otras marcas

Lindy

Lindy 43185 Manual de usuario

Lindy

Lindy 43185 Manual de usuario

ViziT

ViziT RD-4F Manual de usuario

Jinmuyu Electronics

Jinmuyu Electronics MR811 Series Manual de usuario

AVID ID

AVID ID AVID1043 Manual de usuario

Conrad

Conrad PCMCIA Manual de usuario

Rosslare

Rosslare DR-6255 Manual de usuario

Lindy

Lindy 51541 Manual de usuario

Diapro T?bbi Ürünler

Diapro T?bbi Ürünler Across System Manual de usuario

Johnson Controls

Johnson Controls Kantech tyco ioSmart Manual de usuario

ACS

ACS ACR122L Manual de usuario

Secukey

Secukey S2-MF Manual de usuario

Elecom

Elecom MR-SMC07 series Manual de usuario

Alien

Alien ALR-9800 Manual de usuario

ACS

ACS ACR310 Manual de usuario

Datamars

Datamars R-IN1300 MID Manual de usuario

Alarm Lock

Alarm Lock AL-PRE2 Manual de usuario

xpr

xpr B100PROX-AH Guía del usuario
