Digital Thermometer
USER MANUAL
The Device
Probe indicator
Temperature unit ( °C / °F )
Current temperature Value
Bluetooth indicator
Power ON/OFF
Pairing button
Stop alarm button
Battery cover
Probe sockets
Probe with cable AAA battery x 2
(not included)
1
2
Instructions
Two AAA size batteries are needed for this device. Make sure they
are put in the right direction by following the icons on the unit.
Download the APP
Search the keyword FCC BBQ in Appstore or Google Play, or
scan the following QR code with your phone.
Download and install it for free.
Make sure your phone meet the requirements:
●iPhone 4S, and later models;
●iPod touch 5th, ipad 3rd generations and later models,
●all ipad mini;
●Android devices running version 4.4 or later, with blue-tooth
4.0 module.
1. Open the battery cover.
2. Put in batteries, noticing the icons
that show directions.
3. Lock the battery cover.
WWW.FCCPRODUCTS.NO
Install the probes
The device will keep scanning the sockets when its power is
switched on, the Probe Indicators will blink one by one from 1 to 2
where probes are plugged in.
Then insert the probes into the food, make sure the front tip of the
probe is in the center of the food to get accurate temperature.
Pair with your phone
1. Press and hold the power button on
the device for 3 seconds to power it on.
2. Keep the bluetooth connection on the
phone activated.
3. Launch the app, and follow the
instructions in the app to pair and
activate the device.
4. Connected successfully.
Once paired the device with your phone, you don’t need to do it
again, unless you change to other phones.
Bluetooth Indicator
No icon
Icon fixed
Icon blinking
1
2
Probe 1
Probe 2
Enjoy your barbecue time
Choose the food type and preference for the food where each
probe is inserted, the app and the device will display its current and
target temperature.
When the food is ready, the app and the device will alarm.
The user interface of the app may be changed when upgraded.
Please follow the instructions in the app.
Power ON/OFF
Power ON:
Press and hold the power button for 3 seconds.
Power OFF:
Press and hold the power button for 3 seconds.
Auto-off after 8 hours out of connection with phone.
Options
Device
settings
Preference
Display
Probe number
Current
temperatur
Target
temperatur
Temperature
history
Connection
status
Timer
Preference
Setup
Beef Medium
Turkey Done
BBQ 2X
45%
1
2
77°
85°
140°
165°
WARNING
●The heat resistance varies in different components of the probe.
●DO NOT put the probes directly in the fire frame.
●The probes are NOT dishwasher safe.
Teflon cable
with stainless steel mesh
(Length: about 115cm
250°C
For long-time monitoring
Sensor
250°C / 482°F
For long-time monitoring
300°C / 572°F
For instantaneous test
Consumer contact
This product is covered by a warranty in accordance with
consumer legislation. It has undergone strict quality controls and
testing at the factory.
If there are any parts missing or the product has been
damaged, please contact your dealer or the consumer
contact below for help.
Faults due to misuse, lack of maintenance or modification of the
product will invalidate the warranty.
Damaged parts not due to a fault with the product will be
invoiced according to our price list with and added carriage and
administration fee.
If new parts are needed or in the event of a warranty claim,
please contact your dealer or consumer contact:
Always attach your receipt when making a warranty claim.
Produced in China for FCC Products AS
We are always looking for ways we can improve our products.
Therefore, we reserve the right to change technical specifications at any time.
You will always find the latest manual on www.fccproducts.no.
+47 924 78 600
support@fccproducts.no
www.fccproducts.no
FCCPRODUCTSAS
KJELLERVEST KJELLER NORWAY
