FANATEC CSL Elite Racing Wheel Manual de usuario
Manual
US
www.fanatec.com
“PlayStation” and the “PS” Family logo are registered trademarks of
Sony Interactive Entertainment Inc.
Thank you for choosing
To get the most out of your CSL Elite Racing Wheel, please read this manual
before use. It contains important health and safety information and should be
retained for future reference.
3
INDEX
1. General ............................................................................................................... 5-6
2. Introduction ........................................................................................................ 7
3. Compatibility....................................................................................................... 7
4. Plug & Play.......................................................................................................... 8-9
5. Preparation ......................................................................................................... 10-11
4.1 Package contents ........................................................................................ 10-11
6. Assembly............................................................................................................. 12-18
6.1 Plan your conguration .............................................................................. 12
6.2 Mounting the CSL Elite Racing Wheel using the table clamp ................. 12-13
6.3 Hardmounting the CSL Elite Racing Wheel............................................... 14
6.4 Attaching the CSL Elite Steering Wheel (PS4TM version) ......................... 15
6.5 Connections ................................................................................................. 16-17
6.7 Drilling Template.......................................................................................... 17
7. Functions & Features......................................................................................... 19-32
7.1 Firmware and driver update........................................................................ 19-27
7.2 Start-Up procedure ...................................................................................... 27-28
7.3 Tuning menu................................................................................................. 28-31
7.4 Revolution Lights (RevLEDs) ..................................................................... 31-32
7.5 Cooling system ............................................................................................ 32
8. Electronic operation........................................................................................... 33-35
8.1 Hotkeys......................................................................................................... 33-35
9. Cleaning .............................................................................................................. 36
10. Troubleshooting ............................................................................................... 36-37
11. Serial number..................................................................................................... 38
12. Trademarks ........................................................................................................ 38
13. Ecology Advice.................................................................................................. 39
14. FCC Compliance................................................................................................ 39
15. Warranty ............................................................................................................. 40
4
WARNING! Photosensitive Seizures
A very small percentage of people may experience a seizure when exposed to certain visual im-
ages, including ashing lights or patterns that may appear in video games. Even people who have
no history of seizures or epilepsy may have an undiagnosed condition that can cause these „pho-
tosensitive epileptic seizures” while watching video games. These seizures may have a variety
of symptoms, including light-headedness, altered vision, eye or face twitching, jerking or shaking
of arms or legs, disorientation, confusion, or momentary loss of awareness. Seizures may also
cause loss of consciousness or convulsions that can lead to injury from falling down or striking
nearby objects. Immediately stop playing and consult a doctor if you experience any of these
symptoms. Parents should watch for or ask their children about the above symptoms – children
and teenagers are more likely than adults to experience these seizures.
The risk of photosensitive epileptic seizures may be reduced by taking the following precautions:
• Sit farther from the TV screen.
• Use a smaller TV screen.
• Play in a well-lit room.
• Do not play when you are drowsy or fatigued.
If you or any of your relatives have a history of seizures or epilepsy, consult a doctor before play-
ing.
WARNING! Musculoskeletal disorders
Use of game controllers, keyboards, mice, or other electronic input devices may be linked to seri-
ous injuries or disorders. When playing video games, as with many activities, you may experience
occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. However,
if you experience symptoms such as persistent or recurring discomfort, pain, throbbing, aching,
tingling, numbness, burning sensation, or stiffness, DO NOT IGNORE THESE WARNING SIGNS.
PROMPTLY SEE A QUALIFIED HEALTH PROFESSIONAL, even if symptoms occur when you
are not playing a video game. Symptoms such as these can be associated with painful and some-
times permanently disabling injuries or disorders of the nerves, muscles, tendons, blood vessels,
and other parts of the body. These musculoskeletal disorders (MSDs) include carpal tunnel syn-
drome, tendonitis, tenosynovitis, vibration syndromes, and other conditions.
While researchers are not yet able to answer many questions about MSDs, there is general
agreement that many factors may be linked to their occurrence, including medical and physical
conditions, stress and how one copes with it, overall health, and how a person positions and
uses their body during work and other activities (including playing a video game). Some studies
suggest that the amount of time a person performs an activity may also be a factor. If you have
questions about how your own lifestyle, activities, or medical or physical condition may be related
to MSDs, see a qualied health professional.
5
ATTENTION
• The device must not be exposed to rain or humidity in order to avoid risk of re and or electric
shock.
• Operating room temperature: 59°F - 95°F
•
The recommended operation time of the wheel with continuous force feedback activity is 1 hour.
Let the wheel cool down for a few minutes before you continue.
• Excessive use may cause health risks. Take a break of 5 minutes every 20 minutes, and do not
drive for more than 2 hours per day.
• Utilization of the vibration and Force Feedback function may cause damage to your health.
• Not intended for children under the age of 6 years old. Contains small pieces which pose a
choking hazard!
• Do not open the casing of the device.
• This device contains components that cannot be repaired by the user, opening will void the
warranty.
WARNING! Electrical Safety
The CSL Elite Racing Wheel must be connected to an appropriate power source:
•
Use only the power supply and power cord that came with your CSL Elite Racing Wheel.
Replacements may only be issued from an authorized repair center.
• Do not use non-standard power sources, such as generators or inverters, even if the voltage
and frequency appear acceptable. Only use AC power provided by a standard wall outlet.
• To avoid damage, do not expose your CSL Elite Racing Wheel to sources of heat.
• When connecting and / or disconnecting any steering wheel to / from CSL Elite Racing Wheel
take care of the pins inside the quick release.
• Only use Fanatec®steering wheels with the CSL Elite Racing Wheel base.
• Do not try to use the CSL Elite Racing Wheel with an external power source different from the
power supply packaged with the CSL Elite Racing Wheel or received from authorized repair
center.
• Unplug the power cord of your CSL Elite Racing Wheel during storms or when unused for long
periods of time.
• If the CSL Elite Racing Wheel becomes damaged in any way, stop using it immediately and
contact Fanatec®Customer Support.
GENERAL
1
6
GENERAL NOTES
•
PC is mandatory to perform rmware updates! We recommend to use always the latest rmware
but the CSL Elite Racing Wheel is fully workable out-of-box and compatible with existing
peripheral devices [per September 2017].
• All specications in this document are subject to change. The CSL Elite Racing Wheel rmware
and/or PC driver may be updated to implement new features or general improvements.
•
This product contains the CSL Elite Steering Wheel (PS4TM version), all other Fanatec®
steering wheels which might be mentioned in this manual are not included within the CSL Elite
Racing Wheel package and sold separately. You can obtain them from the Fanatec webshop:
https://www.fanatec.com/us-en/
•
Additional peripheral devices like shifters, pedals, LED displays and others which
might be mentioned in this manual are not included within the CSL Elite Racing Wheel
package and are sold separately. You can obtain them from the Fanatec Webshop:
https://www.fanatec.com/us-en/
•
This manual discusses assembly, connections, and functions related to Fanatec®steering
wheels and other additional devices (e.g. PlayStation®4 and PC’s.) This is not a replacement
manual for the other corresponding products! Read the quick guides or user manuals for the
other products as well!
•
The warranty does not include defects that are due to commercial use of the product. See
chapter “Warranty” at the end of this user manual as well as the terms & conditions at
www.fanatec.com for more details.
• Manufactured & distributed under license from Sony Interactive Entertainment LLC.
•
”PlayStation” and the “PS” Family logo are registered trademarks of Sony Interactive
Entertainment Inc.
7
INTRODUCTION
COMPATIBILITY
You have purchased an innovative product which will redene your driving ex-
perience on PlayStation®4. The CSL Elite Racing Wheel provides high steering
accuracy, strong force feedback, smooth belt drive operation and 1080°’s of
rotation angle.
The steering wheel also offers some innovations you’ve never seen before,
such as interchangeable button caps. The original PlayStation®4 button caps
can be replaced with the included racing style button caps. The shifter paddles
offer a high quality haptic feedback/click. The dark grey leather rim grip with
the blue stitching provides a ne nish and comfortable feeling in the driver’s
hands.
The CSL Elite Racing Wheel (CSL E RW PS4) can be used with a wide range
of CSL and ClubSport series steering wheels. Preference will depend on your
personal driving style – it is simply your choice! Additional peripheral devices
from Fanatec®such as pedals, shifters and handbrake are fully compatible with
the CSL Elite Racing Wheel. You can obtain them from the Fanatec webshop:
https://www.fanatec.com/us-en/
The CSL Elite Racing Wheel can be used on PlayStation®4 and PC*.
IMPORTANT: We recommend to use always the latest rmware but
the CSL Elite Racing Wheel is fully workable out-of-box and compatible
with existing peripheral devices [per September 2017]. Therefore a PC is
mandatory! See chapter ‘Firmware and driver update’ for more details!
2
3
*PC compatibility not tested nor endorsed by Sony Interactive Entertainment LLC.
8
PLUG & PLAY
4
This chapter shows just a quick plug & play guide and is not a replacement for
the chapters afterwards, we recommend to read the later chapters to achieve
the best user experience and get your probably upcoming questions answered.
Especially refer to chapter 10 ‘Troubleshooting’ to get quick help if needed.
Slide CSL Elite Steering Wheel onto
wheel base axle. Turn the steering wheel
top side down, insert the xation screw
and tighten the clamp mechanism.
Mount the table clamp to the base
bottom side and clamp the CSL Elite
Racing Wheel to your table.
Connect your peripheral devices to the corresponding port at the CSL Elite
Racing Wheel back side.
Also connect the PS4TM
system or your PC* to
the USB port and plug in
the power supply.
9
Power on the CSL Elite Racing Wheel and wait until
calibration run is is completed.
Switch to the mode you want to use by pressing the
mode button:
• Blue indicates „PlayStation®4 mode“
• Red indicates „PC* mode“
• Purple indicates „ClubSport Wheel Base V2
compatibility mode“
Mode
LED
For use on PS4TM systems please press the PS button at the beginning to
connect the wheel to the active user prole. The PlayStation®4 will display a
system notication on your screen.
Your setup is ready to use now. If you have difculties please check the follow-
ing chapters of this user manual, there are much more detailed descriptions for
each of the above steps.
*PC compatibility not tested nor endorsed by Sony Interactive Entertainment LLC.
10
PREPARATION
4.1 Package contents
5
CSL Elite Wheel Base (PS4TM version)
Table clamp screw with handle
Table clamp
Power supply
Power supply unit
USB connection cable with straight plug
Otros manuales para CSL Elite Racing Wheel
3
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Controladores de videojuegos de FANATEC
FANATEC
FANATEC ClubSport Wheel Base V2 Manual de usuario
FANATEC
FANATEC DD PRO Manual de usuario
FANATEC
FANATEC Porsche 911 Turbo S Wheel Manual de usuario
FANATEC
FANATEC McLaren GT3 Manual de usuario
FANATEC
FANATEC CSL Elite Pedals Manual de usuario
FANATEC
FANATEC SPEEDTER PURE Manual de usuario
FANATEC
FANATEC PODIUM Wheel Rim NASCAR Manual de usuario
FANATEC
FANATEC PODIUM F1 Manual de usuario
FANATEC
FANATEC CSL Elite F1 Set Manual de usuario
FANATEC
FANATEC CSL Elite Racing Wheel Manual de usuario
