Fabtech FTS22101 Manual de usuario
2008-2011 FORD SUPER DUTY 4WD
REAR LIFT FOR 6” F-250 With or Without FACTORY OVER LOAD LEAF
FTS22101
PARTS LIST:
Qua Part
# Description
2 FTBK5 5"
Block
4 FT742U U-Bolt
1 FT58H 5/8" Hardware
1 FTS419 Shim
Kit
1 FT30166 E-Brake Cable Sleeve
1 31182001081 5/16"-18 x 2" Bolt gr.8
1 31000005252 5/16" Split Washer
2 FT22101i Instruction
Sheet
Tool List: (Not Included)
Floor Jack
Jack Stands
Assorted Metric and S.A.E Sockets & Allen Wrenches
READ ALL INSTRUCTIONS THOROUGHLY FROM START TO FINISH BEFORE BEGINNING INSTALLATION!
IF TRUCK IS EQUIPPED WITH REAR SWAY BAR,FTS92010BK REAR SWAY BAR DROP
BRACKET CAN BE PURCHASED.
FOLLOW STEPS ONE – SIX FOR TRUCKS
WITHOUT THE FACTORY OVER LOAD
SPRING SET-UP
3. Locate and install the rear lift blocks, the factory block will
be positioned on top of the new Fabtech block, with the
short center pin of both blocks facing down, to the axle.
The short end of the blocks should face to the front of the
vehicle. Using the supplied u-bolts, nuts, and washers align
axle, lift blocks, and springs and torque to U-Bolts to 90lbs.
SEE PHOTO BELOW
INSTRUCTIONS:
1. Disconnect the negative terminal on the battery. Jack up
the rear end of the vehicle and support the frame rails with
jack stands. Supporting the rear differential remove and
discard the rear shocks and u bolts. Lower the axle down
slowly. Use care not to over extend the brake hose.
NEVER WORK UNDER AN UNSUPPORTED
VEHICLE!
2. Locate the factory emergency brake cable bracket on the
driver’s side rear frame section and remove. Use a die
grinder with a cut-off wheel and cut the bracket ONLY.
Remove the bracket from the cable and discard with the
hardware. SEE PHOTOS BELOW
2011 configuration shown above
4. Install Fabtech shock part number FTS7266 Performance
Shocks or FTS81005 Dirt Logic are not included with the
Factory hardware and torque bolts to 65lbs.
5. Locate the E-Brake Cable mount on the driver side spring
pack perch. Remove the bolt attaching it to the perch and
discard the hardware.
6. Locate FT30166 E-Brake Cable Sleeve and attach between
the spring perch and E-brake Cable bracket using the
supplied 5/16”-18 x 2” bolt and split washer. SEE PHOTO
BELOW
FOLLOW STEPS SEVEN – TEN FOR TRUCKS
WITH THE FACTORY OVER LOAD SPRING
SET-UP
7. Disconnect the negative terminal on the battery. Jack up
the rear end of the vehicle and support the frame rails with
jack stands. Supporting the rear differential, remove and
discard the rear shocks and u bolts. Lower the axle down
slowly. Use care not to over extend the brake hose.
NEVER WORK UNDER AN UNSUPPORTED
VEHICLE!
8. Locate and install the rear lift blocks, the factory block will
be positioned on top of the new Fabtech block, with the
short center pin of both blocks facing down, to the axle.
The short end of the blocks should face to the front of the
vehicle. Using the supplied u-bolts, nuts, and washers align
axle, lift blocks, and springs and torque to U-Bolts to 90ft-
lbs. SEE PHOTO BELOW
9. Install Fabtech shock part number FTS7266 Performance
Shocks or FTS81005 Dirt Logic (not included) with the
factory hardware and torque bolts to 65ftlbs.
10. Rotate the E-Brake cable bracket so that it positions the
cable below the spring plate and attach to the plate with the
factory hardware. Once tightened, bend the bracket forward
towards the front of the truck. Locate the upper E-brake
cable bracket on the frame and bend it outward / down to
give the cable some more slack. SEE PHOTOS IN NEXT
COLUMN
2011 configuration shown above
Bend bracket
forward to
give the cable
more slack
RESUME INSTALLATION ON ALL TRUCKS
11. Install FTS419 shim kit as per the instructions in the
FTS419 box.
12. Recheck all bolts for proper torque. Recheck brake hoses
and lines for proper clearances.
13. 2011 models only .Locate the factory brake line mount on
the driver side of the axle. Remove the vent line from the
bolt and remove bolt, save hardware. Locate the brake line
bracket FT30059 (Note: This part is included in the front
component box kit); attach the side with the sleeve to the
axle using the factory hardware. Using the supplied 3/8” x
2” bolt, nut, and washer attach the brake line to the other
end. Reattach vent line. SEE PHOTO BELOW.
14. Install tires and wheels and torque lug nuts to wheel
manufacturer’s specifications.
15. Readjust headlights.
16. Check the front-end alignment and set to the factory
specifications.
Bend bracket
downward to
give the cable
more slack
