EZee Life CH3010 Manual de usuario

Model: CH1044

EZee Life™ Products

34 Futurity Gate, Unit 15, Concord, Ontario L4K 1S6

Economy Rollators

Model: CH3010 – Standard Blue

CH3020 – Standard Red

CH3031 – Low Seat Red

…...................................................

Specifications:

Specification

CH3010

CH3020

CH3031

Frame Materia : A uminium A uminium A uminium

Weight: 17.9 b 17.9 b 18.3 b

Whee Size: 8” 8” 8”

Seat Width: 13 3/4” 13 3/4” 13 3/4”

Seat Depth: 13 1/4” 13 1/4” 13 1/4”

Seat Height: 22 1/4” 22 1/4” 18 1/2”

Width between

hand es:

17 1/2” 17 1/2” 20 1/2”

Hand e Height: 36” to 39 1/4” 36” to 39 1/4” 35 3/4” to 40”

Weight Capacity: 264 b 264 b 220 b

User Height

(approx.)

5' 8” to 6' 1” 5' 8” to 6' 1” 4' 6” to 5' 4”

Features:

Lightweight

Easi y Manoeuvrab e

Padded F ip Up Seat

Padded Backrest Bar

Mesh Basket

Hand Brakes

So id F at-Proof Tires

A uminum Frame

Economica y Priced

Limited Warranty:

Ezee Life™ products carry a one year warranty against

manufacturing defects, fau ty materia s and workmanship on y.

Any a terations, misuse, abuse, or accidenta damage voids this

warranty. Ezee Life™ reserves the right to rep ace or repair any part

that has become defective.

The warranty does not extend to consequentia costs resu ting from

the fau t or defect of the product: freight and trave costs, oss of

earnings, or other expenses that one may incur.

Warranty is va id for the origina purchaser on y and the origina

receipt must be presented before any warranty options are

considered. P ease a so be prepared to provide the date of purchase

and seria number.

Rollator Parts Guide

A – Brake Cab e F – Brake Lever

B – Backrest G – Hand e bar hand screw

C – Backrest Bracket H – Cane Ho der (top pc.)

D – Carry Pouch I – Seat

E – Hand Grip J – Cane Ho der ( ower pc.)

K - Whee

Assembly

1. Remove the wa ker from its box and unwrap the parts.

2. Insert the push hand es into the top of the front eg sections

3. Line up the ho es on the push hand es with the ho es in the egs

at the desired height and insert the bo ts supp ied.

4. Tighten the supp ied hand knobs onto the bo ts.

5. Insert the backrest into the backrest brackets on the front egs

unti they ock into p ace.

Handle Height Adjustment

For proper height adjustment, stand upright with

shou ders re axed and arms at your side. Adjust

hand e height to the height of the inside of your

wrist where your watch strap wou d be.

Folding

1) Lock the brakes on by pushing down both

brake evers unti they c ick into p ace.

2) Fo d seat up vertica y and ift strap attached

to fo ding mechanism.

3) Optiona : Backrest can be removed at any

time by re easing the ocking pins and ifting

the backrest out of backrest bracket.

Unfolding

To unfo d push down on the fo ding mechanism

unti the are fu y extended.

Operating the Bra es

A ways push down on both brake hand es to

ock the whee s before

sitting. CAUTION: The rear whee s wi ock

but it may sti s ide if the

f oor surface is s ippery.

Squeeze both brake hand es to re ease the

brake (2) CAUTION never

re ease the brakes unti you are standing

stab e and in the ready wa k

position. Do not re ease the brakes if you are

sitting down.

If you are wa king and wish to s ow down, squeeze the brake hand es

s ight y to put brake pressure on the whee s.

Bra e Adjustment

Over time the brake cab es wi stretch and require adjustment.

1) With the brakes off, grasp the ocking

nut with a sma wrench or pair of

p iers, and turn counter c ockwise to

oosen.

2) With fingers, unscrew the adjusting

screw to tighten brakes. A turn or two

shou d be enough.

3) Whi e ho ding adjustment screw in

p ace tighten the ocking nut.

4) Repeat on brake on other side.

Note: If the brakes are too oose the whee s wi turn when the brakes

are on. If the cab e is too tight the bakes wi not ock on.

IMPORTANT: before using the wa ker, ensure the brakes are working

proper y. If the whee s turn whi e the brakes are app ied have them

adjusted before using the wa ker.

Safety Information

Consu t a physician or other medica professiona to determine if this

equipment is suitab e for your needs.

Ensure a parts are secure, brakes are functiona and the frame is fu y

opened before using.

A ways ock the brakes on before siting and eave them ocked unti

you're standing and ready to wa k again.

Trave up and down s opes and inc ines. DO NOT trave across inc ines.

Use caution on s ippery surfaces.

Do Not over tighten hardware attaching to the frame. This cou d cause

damage to the frame tubing or strip the threads.

Do Not stand on seat.

Do Not over oad this ro ator. The weight capacity is 264 pounds (220 b

for Mode CH3031) inc uding the user and any things they may be

carrying.

Inspection Items

Ensure ro ator ro s straight (no excessive drag or pu to one side).

Inspect the seat for tears and/or excessive sagging.

Inspect hand grips for wear, ooseness or damage.

Inspect for any oose or broken hardware or parts.

Inspect for cracked, broken or oose whee s.

Imported / Distributed by:

Factory Direct Medical

34 Futurity Gate, Unit # 15

Concord Ontario L4K 1 6

Local: 416-739-8393

Toll Free: 855-235-2400
