EZ-ACCESS PATHWAY 3G Manual de usuario
Manufactured in the USA
LIFETIME WARRANTY. Please register at www.ezaccess.com/warranty-satisfaction.
© EZ-ACCESS®, a division of Homecare Products, Inc. All rights reserved.
All text and images contained in this document are proprietary and may not be shared, modified, distributed,
reproduced, or reused without the express written permission of EZ-ACCESS.
16397 REV 04-18-2022
Assembly Manual
PATHWAY
®3G Modular Access System
Image shown with multiple ramp and
platform handrail options.
PATHWAY®3G Modular Access System Assembly Manual
Page 2 of 75
1
ATTENTION INSTALLER and END USER
•For residential use only!
•1,000 lb. rated load; never exceed rated load.
•Read this manual in its entirety, ensuring you understand all instructions and warnings prior to ramp
assembly and use.
•Please read and become familiar with the ‘MAINTENANCE AND SAFETY’ section of this manual.
•Fill out online warranty registration.
•INSTALLER: Please leave this ASSEMBLY MANUAL with the end user.
IMPORTANT SHIPPING INFORMATION
•Immediately open shipping boxes and inspect for damage or missing parts. If damaged or missing parts are
noted, DO NOT INSTALL OR USE.
•Each system is shipped with a packing list. Confirm all items are present before starting installation. Also
check for shipping damage immediately upon receipt and note any freight damage on freight bill while driver
is still present. Contact shipper right away with any freight damage concerns. In most cases, freight damage
claims will not be allowed unless noted on the freight bill. Pictures of damage before the unit is unpacked
can be very helpful.
TOOLS TYPICALLY REQUIRED
1/2″ SOCKET OR 1/2″ WRENCH
BOX KNIFE
9/16″ SOCKET OR 9/16″ WRENCH HAMMER
5/16″ SOCKET OR 5/16″ WRENCH LEVEL
POWER DRILL FILE
#2 PHILLIPS SCREW DRIVE RUBBER MALLET
PLIERS 1/4″ MASONRY DRILL BIT (IF INSTALLING TO CONCRETE)
1/8” DRILL BIT DIGGING TOOLS (IF AN OBSTACLE NEEDS TO BE REMOVED)
5/16″ DRILL BIT
HACKSAW (FOR OPTIONAL HANDRAIL KITS
5/32″ ALLEN WRENCH 25’ TAPE MEASURE
3/16″ ALLEN WRENCH
CONSTRUCTION ADHESIVE
PATHWAY®3G Modular Access System Assembly Manual
Page 3 of 75
1
INTRODUCTION
Throughout this manual, the term “system” refers to the entire PATHWAY 3G Modular Access System, including
any gates, stairs, ramps, platforms, risers, handrails, supports, transition plates, landing pads, and any/all
hardware and components which are intended to be assembled on the PATHWAY® 3G Modular Access System.
SYMBOLS
The WARNING symbol indicates a potentially hazardous condition/situation. The safety warnings
throughout this manual, and on your equipment, if any, are for the protection of people and property.
Failure by any operator to abide by safety warnings will result in a waiver of all liabilities, loss of your
warranty, and could result in equipment damage and or failure, property damage, risk of serious bodily
injury, and or death. The symbol may appear in various colors and in conjunction with other symbols
and with or without the written word “WARNING”.
The NOTE symbol indicates important information. Failure to obey all notes could result in improper
operation, less-than-optimum equipment performance, and at the sole discretion of the equipment
manufacturer, may void your warranty. The symbol may appear in various colors and in conjunction
with other symbols and with or without the written word “NOTE”.
WARNINGS
Maximum weight capacity is 1,000 lbs.; never exceed weight capacity.
Prior to assembly and use, read and follow all instructions, warnings, and labels. Following all
instructions and obeying all warnings before and during use is necessary for safe operation. For
additional information or to obtain replacement copies of instructions or labels, call 1-800-451-1903.
For people and mobility equipment only; not for commercial use.
Consult local building codes regarding securing the system for wind loads.
Before use with mobility equipment, refer to your mobility equipment's owner guide for acceptable
ramp usage, including proper slope/incline, chair direction, etc.; never exceed its recommendations.
Only use the system with a qualified helper.
Always use a lap belt if using the system with mobility equipment.
If walking on the system, handrails are required and must be installed.
Before each use, check the system for worn, loose, or damaged parts. If you find any of these
conditions, do not use the system and contact your dealer for service or repairs; failure to do so may
result in serious injury.
Do not use the system if it is damaged or unstable.
Do not tamper with, attempt to repair, or modify any portion of the system.
Ensure that the landings the system will be placed on are substantial and of sound construction.
Use only if the secure, unobstructed, level landings can support, at minimum, the same weight capacity
as the system (1,000 lbs.).
Ensure that the system is securely anchored before each use.
Use only if sufficient maneuvering room is available at both ends of the system to assure safe travel
when entering and exiting the system.
Do not walk, sit, stand, etc. on the system until the installation is complete.
Consult local building codes regarding securing system for wind loads.
Keep the system clear of debris and clutter. Do not use if walking surface is unsafe.
Confirm the system is correctly leveled and positioned securely. Periodically check for ground shifts.
Never place anything on, under, or attach anything to system.
Only use components supplied or approved by manufacturer with system.
Do not sit, stand, or climb on guards, gates, or handrails.
Do not use any part of the system to support planters, lights, decorations, etc.
PATHWAY®3G Modular Access System Assembly Manual
Page 4 of 75
1
WARNINGS, CONT’D.
Do not run, jump, or play on or around the system, including climbing on or between the handrails.
Improper use of the system could result in serious injury.
Properly support and restrain system in transit or storage.
Do not use the system if its surface is covered with ice, snow, dirt, leaves, or other debris. Remove all
accumulations and sweep the surface clean before use.
The system may be slippery in wet conditions; use caution as traction may be reduced.
Before each use, check the system for worn, loose, or damaged parts. If you find any of these
conditions, do not use the system and contact your dealer for service or repairs; failure to do so may
result in serious injury.
Always exercise caution when handling, installing, and or using the system.
For additional care, usage, or general safety information, please call 1-800-451-1903.
Aluminum conducts electricity. Do not use or handle the system around live wiring or during electrical
storms.
PATHWAY®3G Modular Access System Assembly Manual
Page 5 of 75
1
TABLE OF CONTENTS
SECTION 1: BASIC SYSTEM COMPONENTS
IDENTIFYING COMPONENTS ......................................................................................................................... 6-12
SECTION 2: PLATFORMS
INSTALL PLATFORMS.........................................................................................................................................13
INSTALL SUPPORT TUBES AND FEET AND ADJUST PLATFORM HEIGHT...................................................... 14-15
CONNECT TWO PLATFORMS TOGETHER .................................................................................................... 15-16
45-DEGREE ANGLE PLATFORM..........................................................................................................................17
8’ X 5’ TURN BACK PLATFORM ..........................................................................................................................17
LOW PROFILE PLATFORM............................................................................................................................ 18-24
INSTALL UNIVERSAL ANGLE BRACE - PLATFORMS ............................................................................................24
INSTALL UNIVERSAL CROSS BRACE ...................................................................................................................25
SECTION 3: RAMPS
CONNECT RAMP SECTIONS ...............................................................................................................................26
INSTALL RAMPS ON PLATFORMS ......................................................................................................................27
ATTACH SUPPORT LEG BRACKETS AND LEGS TO RAMPS:........................................................................... 28-30
INSTALL UNIVERSAL ANGLE BRACE - RAMPS ....................................................................................................30
INSTALL GROUND TRANSITION RAMP ..............................................................................................................31
INSTALL A SINGLE RAMP RUN TO AN EXISTING STRUCTURE ............................................................................32
ANCHOR RAMP UPPER TRANSITION .................................................................................................................33
ANGLE RAMPS WITH RESPECT TO PLATFORMS, PORCHES, OR DECKS .............................................................34
SECTION 4: HANDRAILS
RAMP WITHOUT HANDRAILS ............................................................................................................................35
RAMP HANDRAILS ....................................................................................................................................... 35-36
ASSEMBLE STANDARD PLATFORM HANDRAILS ................................................................................................37
INSTALL STANDARD PLATFORM HANDRAILS .............................................................................................. 38-39
8’ X 5’ TURN BACK PLATFORM HANDRAILS (OPTIONAL EQUIPMENT) ....................................................... 39-40
45-DEGREE ANGLE PLATFORM HANDRAILS ................................................................................................ 40-47
SECTION 5: CLOSURES
TOP RAIL AND CURB.................................................................................................................................... 48-51
TWO-LINE CLOSURE LOWER RAIL .....................................................................................................................52
VERTICAL PICKET CLOSURE ......................................................................................................................... 53-54
TWO-LINE TURN BACK CLOSURE................................................................................................................. 55-57
SECTION 6: FINAL PLATFORM/RAMP STEPS AND CHECKS
SECURE RAMPS TO PLATFORM .........................................................................................................................58
INSTALL RAMP HANDRAIL END LOOPS .............................................................................................................59
INSTALL RAMP HANDRAIL END CAPS................................................................................................................60
INSTALL RAMP CORNER PROTECTORS ..............................................................................................................60
TOUCH-UP ARCHITECTURALLY FINISHED HANDRAILS ......................................................................................60
FINAL CHECKS....................................................................................................................................................60
SECTION 7: OPTIONAL EQUIPMENT
RAMP SUPPORT TOP .........................................................................................................................................61
RAMP LOWER TRANSITION ...............................................................................................................................62
SINGLE BRIDGE PLATE .......................................................................................................................................62
LANDING PAD.............................................................................................................................................. 63-64
PLATFORM TIE STRAPS......................................................................................................................................64
LIGHTNING GROUND ROD ................................................................................................................................65
TIE DOWN ................................................................................................................................................... 66-67
GATE............................................................................................................................................................ 68-69
CONNECT 45-DEGREE ANGLE PLATFORM WITH TWO-LINE RAILS TO STANDARD PLATFORM................... 70-73
SECTION 8:MAINTENANCE & SAFETY
PERIODIC MAINTENANCE & SAFETY .................................................................................................................74
SECTION 9: DEICING.................................................................................................................................................74
PATHWAY®3G Modular Access System Assembly Manual
Page 6 of 75
1
1. BASIC SYSTEM COMPONENTS
Because each ramp configuration will differ from one another, your system may or may not contain all these
basic system components. Identify your system components before you begin.
SURFACE OPTIONS
SOLID SURFACE EXPANDED METAL SURFACE
RAMP AND RAMP HANDRAIL OPTIONS
RAMP W/O HANDRAILS RAMP W/ TWO-LINE HANDRAIL
RAMP W/ VERTICAL PICKETS RAMP W/ HORIZONTAL PICKETS
PATHWAY®3G Modular Access System Assembly Manual
Page 7 of 75
1
KEY RAMP COMPONENTS
PSLXXPR – SUPPORT LEG PAIRS PRGT & PRGT48
RAMP GROUND TRANSITION 18” X 36”and 18” X 48”
PRHBPR – RAMP HANDRAIL END BRACKET (PAIR) PRRUC – UNIVERSAL CONNECTOR – RAMP TO RAMP
PRSUT – UNIVERSAL RAMP SUPPORT - TOP RAMP HANGER PAIR
XX DENOTES USABLE
LENGTH (LENGTHS
AVAILABLE 10”
THROUGH 100" IN 6”
INCREMENTS)
INCLUDES
COMPONENTS TO
CONNECT RAMPS
AND RAMP
HANDRAILS
SHOWN ASSEMBLED
USED WHEN LEGS
SUPPORT UPPER OR
LOWER END OF RAMP
ONLY
PATHWAY®3G Modular Access System Assembly Manual
Page 8 of 75
1
KEY RAMP COMPONENTS, CONT’D.
PRHRLU- UPPER HANDRAIL
END LOOP
PRHRLL - LOWER HANDRAIL
END LOOP PHREC - HANDRAIL END CAP
PRUT – RAMP UPPER TRANSITION PRLT – RAMP LOWER TRANSITION
INCLUDES RAMP CORNER
PROTECTORS
PATHWAY®3G Modular Access System Assembly Manual
Page 9 of 75
1
PLATFORMS AND PLATFORM HANDRAIL OPTIONS
PLATFORM (STRAIGHT CONFIGURATION)
W/TWO-LINE HANDRAILS
PLATFORM (TURN CONFIGURATION)
W/TWO-LINE HANDRAILS
PLATFORM W/ HORIZONTAL PICKET HANDRAILS PLATFORM W/ VERTICAL PICKET HANDRAILS
PLATFORM (8’ X 5’ TURN BACK)
W/TWO-LINE HANDRAILS
PATHWAY®3G Modular Access System Assembly Manual
Page 10 of 75
1
PLATFORM AND PLATFORM HANDRAIL OPTIONS, CONT’D.
PLATFORM 45-DEGREE ANGLE
W/ TWO-LINE HANDRAILS
NOT AVAILABLE WITH HORIZONTAL PICKET HANDRAILS
PLATFORM 45-DEGREE ANGLE
W/ VERTICAL PICKET HANDRAILS
NOT AVAILABLE WITH HORIZONTAL PICKET HANDRAILS
LOW PROFILE PLATFORM W/TWO-LINE HANDRAILS LOW PROFILE PLATFORM W/TWO-LINE HANDRAILS
USED AS A LANDING PAD
Otros manuales para PATHWAY 3G
2
Tabla de contenidos
Otros manuales de Ayuda a la movilidad de EZ-ACCESS
Manuales populares de Ayuda a la movilidad de otras marcas
Rhythm Healthcare
Rhythm Healthcare B3800F Manual de usuario
AMF-BRUNS
AMF-BRUNS PROTEKTOR Manual de usuario
Drive DeVilbiss Healthcare
Drive DeVilbiss Healthcare OTTER Manual de usuario
Rhythm Healthcare
Rhythm Healthcare C500U Manual de usuario
Lumex
Lumex RJ4200A Manual de usuario
Rebotec
Rebotec Jumbo Manual de usuario
