Extron electronics MSW 4SV rs Manual de usuario

Specifications — MSW 4 rs Series Switchers

Video — MSW 4V rs, MSW 4SV rs

Gain ............................................... Unity

Bandwidth

MSW 4V ............................ 300 MHz (-3 dB)

MSW 4SV .......................... 250 MHz (-3 dB)

Crosstalk ....................................... <-60 dB @ 3.58 MHz

Switching speed ........................... 20 ms (max.)

Video — MSW 4V SDI rs

Resolution ..................................... 8 or 10 bits, automatic

Operation standards ................... 143 Mb/s (4fsc NTSC)

177 Mb/s (4fsc PAL)

270 Mb/s (4:2:2) component video

360 Mb/s (4:2:2) widescreen, autoselect

Equalization and reclocking ...... Automatic for up to -30 dB of cable loss

Automatic data rate clock .......... Yes

Video input

Number/signal type

MSW 4V rs ........................ 4 composite video

MSW 4SV rs ...................... 4 S-video

MSW 4V SDI rs ................ 4 serial digital component video

Connectors

MSW 4V rs, MSW 4V SDI rs 4 female BNC

MSW 4SV rs ...................... 4 female 4-pin mini DIN

Nominal level ............................... 1 Vp-p for Y of S-video and for composite video

0.3 Vp-p for C of S-video

0.8 Vp-p for SDI

Minimum/maximum levels (MSW 4V rs, MSW 4SV rs)

0.4 V to 2.0 Vp-p with no offset

Impedance .................................... 75 ohms

Return loss

MSW 4SV rs ...................... <-25 dB, DC @ 10 MHz

Other models .................... <-40 dB, DC @ 10 MHz

DC offset (max. allowable) ......... 5.0 V

Input coupling

MSW 4V rs, MSW 4SV rs DC

MSW 4V SDI rs ................ AC

Video output

Number/signal type

MSW 4V rs ........................ 2 composite video

MSW 4SV rs ...................... 1 S-video, 1 composite video

MSW 4V SDI rs ................ 2 reclocked SMPTE-259 serial digital component video

Connectors

MSW 4V rs, MSW 4V SDI rs 2 BNC female

MSW 4SV rs ...................... 1 BNC female, (1) 4-pin mini DIN female

Nominal level ............................... 1 Vp-p for Y of S-video and for composite video

0.3 Vp-p for C of S-video

0.8 Vp-p for SDI

Minimum/maximum levels (MSW 4V rs, MSW 4SV rs)

0.4 V to 2.0 Vp-p

Impedance .................................... 75 ohms

1-2 MSW 4V rs, MSW 4SV rs, MSW 4V SDI rs • Specifications

Return loss

MSW 4V/4SV rs............... <-30 dB @ 5 MHz

MSW 4V SDI rs ................ <-25 dB @ 5 MHz

DC offset ....................................... ±5 mV maximum with input at 0 offset

Switching type (MSW 4V rs/4SV rs)

Vertical interval

Jitter (MSW 4V SDI rs) ............... <2 µs

Rise/fall time (20-80%, MSW 4V SDI rs)

700 ps ±100 ps

Re-clocking (MSW 4V SDI rs) ... Automatic, bypass mode for nonstandard rates

Sync

Standards

MSW 4V rs, MSW 4SV rs NTSC 3.58, NTSC 4.43, PAL, SECAM

MSW 4V SDI rs ............... SMPTE-259M

Control/remote — switcher

Serial control port ........................ 1 RS-232, 3.5 mm captive screw connector, 5 pole

Baud rate and protocol ............... 9600 baud, 8 data bits, 1 stop bit, no parity

Serial control pin configurations 1 = TX, 2 = RX, 3 = GND

Contact closure ............................ (1) 3.5 mm captive screw connector, 5 pole

Contact closure pin configurations 1 = input 1, 2 = input 2, 3 = input 3, 4 = input 4, 5 = GND

Program control ........................... Extron’s Universal Switcher program for Windows®

Extron’s Simple Instruction Set (SIS™)

General

External power supply ............... 100 VAC to 240 VAC, 50/60 Hz, external, autoswitchable; to 12 VDC, regulated

Power input requirements

MSW 4V rs, MSW 4SV rs 12 VDC, 0.2 A

MSW 4V SDI rs ................ 12 VDC, 0.4 A

Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Rack mount ................................... Yes, with optional 1U, 9.5" deep rack shelf, part #60-190-01 or 60-604-01; or 6" deep

rack shelf, part #60-190-10 or #60-604-10; or VersaTools®3" deep rack shelf, part

#60-190-20 or 60-604-20; also under-furniture mountable with optional brackets

#70-212-01

Enclosure type .............................. Metal

Enclosure dimensions ................. 1.7" H x 4.3" W x 3.0" D (1U high, quarter rack wide)

4.3 cm H x 10.9 cm W x 6.5 cm D

(Depth excludes connectors.)

Product weight ............................. 0.6 lbs (0.3 kg)

Shipping weight ........................... 3 lbs (2 kg)

Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)

Listings .......................................... UL, CUL

Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES

MTBF ............................................. 30,000 hours

Warranty ....................................... 3 years parts and labor

All nominal levels are at ±10%.

Specifications are subject to change without notice.

(7.52-121206-D3)

MSW 4V rs, MSW 4SV rs, MSW 4V SDI rs • Specifications 1-3
