Extron electronics Inline CIA116-1 Manual de usuario

CIA116 TABLE / RACK MOUNT

COMPUTER INTERFACE WITH MODULAR A / V FACEPLATE

CIA116

OPERAT ION MANUAL

CIA116

WITH OPTIONAL

RACK EARS

CIA116

WITH TABLE MOUNT BRACKETS

(INCLUDED)

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

Installation and Safety Instructions

For Models without a Power Switch:

The socket outlet shall be installed near the equipment and shall be accessible.

For all Models:

No serviceable parts inside the unit. Refer service to a qualified technician.

For Models with Internal or External Fuses:

For continued protection against fire hazard, replace only with same type and rating of fuse.

Instructions d’installation et de sécurité

Pour les modèles sans interrupteur de courant:

La prise de courant d’alimentation sera installé près de l’équipement et sera accessible.

Pour tout les modèles:

Pas de composants à entretenir à l’intérieur. Confiez toute réparation à un technicien qualifié.

Pour les modèles équipés de fusibles internes ou externes:

Afin d’éviter tout danger d’incendie, ne remplacer qu’avec le même type et la même valeur de fusible.

Installations- und Sicherheitshinweise

Für Geräte ohne Netzschalter:

Die Netzsteckdose soll in der Nähe des Gerätes installiert und frei zugänglich sein.

Für alle Geräte:

Keine Wartung innerhalb des Gerätes notwendig. Reparaturen nur durch einen Fachmann!

Für Geräte mit interner oder externer Sicherung:

Für dauernden Schutz gegen Feuergefahr darf die Sicherung nur gegen eine andere gleichen Typs und gleicher Nennleistung

ausgewechselt werden.

Instalacion E Instrucciones de Seguridad

Modelos Sin Interruptor:

La conexión debe ser instalada cerca del equipo y debe ser accesible.

Para Todos Los Modelos:

Dentro de la unidad , no hay partes para reparar. Llame un tecnico calificado.

Modelos con Fusibles Internos o Externos:

Para prevenir un incendio, reemplace solo con el mismo tipo de fusible.

CE COMPLIANCE

All products exported to Europe by Inline, Inc. after January 1, 1997 have been tested and found to

comply with EU Council Directive 89/336/EEC. These devices conform to the following

standards:

EN50081-1 (1991), EN55022 (1987)

EN50082-1 (1992 and 1994), EN60950-92

Shielded interconnect cables must be employed with this equipment to ensure compliance with

the pertinent Electromagnetic Interference (EMI) and Electromagnetic Compatibility (EMC)

standards governing this device.

FCC COMPLIANCE

This device has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC rules. These limits are designed to provide against harmful

interference when equipment is operated in a commercial environment. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. Operation of

equipment in a residential area is likely to cause harmful interference, in which case the user will be

required to correct the interference at their own expense.

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

Product Overview

DESCRIPTION

The CIA116 is a high-performance computer interface for analog video and stereo audio signals. The

unit is compatible with a variety of analog video signals including VGA, SVGA, XGA, SXGA, UXGA,

Macintosh®, SunTM, SGITM and other high-resolution workstations. The CIA116 combines high-

resolution computer interfacing and modular A/V connector plates into a versatile unit that fills several

different installation applications. This highly integrated approach gives audiovisual professionals the

ability to quickly design and install functional, customized computer interfacing and A/V connectivity

solutions for a broad spectrum of applications. Like other INLINE interfaces, the CIA116 performs the

following functions:

• Signal Splitting - allows the simultaneous connection and viewing of both the computer’s local

monitor and a second output device such as a data projector or a presentation monitor.

• Physical Interfacing - Because computers employ many different types of video output

connectors, it is sometimes difficult to directly connect them to data projection devices. The

CIA116 simplifies interfacing tasks by acting as a universal adapter. Through the use of

removable input cables, the CIA116 can be attached to different computers and will provide a

video output signal on five BNC connectors. The output signal may be set to RGBHV

(default), RGBS or RGsB formats.

The CIA116 is not a scan converter. The data projector, monitor or other

output device must be compatible with the horizontal scan rate output by

the computer video card.

PRODUCT FEATURES

• 15-Pin HD VGA Standard Connectors - The CIA116 connects directly to PC, Mac and SGI

graphics ports and local monitors using high-resolution coaxial VGA extension / adapter cables.

• Three unique installation applications:

1) The CIA116 mounts neatly under a conference or boardroom table, computer

workstation or podium.

2) The unit fits snugly into a 1U rack space.

3) The interface can be flush mounted in a table surface exposing only the faceplate.

• Ultra High-Resolution Amplification - The CIA116 provides superb performance with

analog video signals at any resolution.

• Modular A/V Connector Plates - The front panel accepts up to four (4) A/V connector

modules, available with a variety of popular connectors.

• Audio Buffering - The CIA116 accepts unbalanced stereo audio from a computer sound card

and can be set to output a balanced or unbalanced signal.

• Selectable Output Sync Format - The unit can be set for RGBHV (default), RGBS or RGsB

output sync as required by the data display device and signal distribution system.

• Buffered Local Monitor Output - ensures the highest quality display on a local monitor.

• One-Button Monitor Emulation - makes it easy to use the interface without a local monitor.

• New Soft-Touch Rocker Button for Horizontal Position Control - allows precise centering

of the image within the data display area.

• Sharpness Control - provides effective image enhancement for high-resolution video signals

by increasing clarity and image detail, and compensates for signal loss during long cable runs.

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

• Dual Front Panel A/C Power Outlets - provide a convenient place to plug in a laptop

computer, CD player or other portable A/V device.

• Available in Six Different Models to Match Decor and Regional Power Outlet Style:

CIA116-1 - Interface with (2) Edison A/C Convenience Outlets - Black Finish.

CIA116-2 - Interface with (2) Edison A/C Convenience Outlets - White Finish.

CIA116-3 - Interface with (2) Europlug A/C Convenience Outlets - Black Finish.

CIA116-4 - Interface with (2) Europlug A/C Convenience Outlets - White Finish.

CIA116-5 - Interface with (2) IEC A/C Convenience Outlets - Black Finish.

CIA116-6 - Interface with (2) IEC A/C Convenience Outlets - White Finish.

• 400 MHz Bandwidth

The CIA116 simplifies the design and installation process since a single unit fills the function of both video

interface and A/V connector plate. Available A/V modules are listed on pages 13-14.

Compatibility

INPUT

The CIA116 will accept high-resolution video signals from virtually any computer that outputs an

analog video signal. The unit will work with signals at virtually any resolution and refresh rate.

Compatible computer video signals include VGA, SVGA, XGA, MAC, SUN, SGI and other high-

resolution computers outputting an analog video signal. Input signal compatibility parameters are

listed below.

Video Signal: Analog RGB Video

Signal format: RGBHV, RGBS, RGsB*

Horizontal Frequency Range: 30 KHz to 130 KHz

Vertical Refresh Rates: 30 Hz to 120 Hz

* The CIA116 will operate with RGsB input signals. However, the unit will

not strip sync off of the green. RGsB input signals are always output as RGsB

(they cannot be output as RGBS or RGBHV). Also, the horizontal position

control will not operate when used with RGsB input signals.

OUTPUT

The output signal of the CIA116 is analog RGB video with TTL sync on 3, 4 or 5 female BNC

connectors. The output format can be set to RGBHV, RGBS or RGsB using dipswitches. This output

signal is compatible with high-resolution data grade monitors and data / graphics projectors.

VGA, MAC, SUN, SGI and other high-resolution workstations operate in

several video modes encompassing a wide range of resolutions and scan

rates. Many of the video signals from the newest models can run as high as

70 KHz or more, with the newest VGA cards offering an output resolution of

1600 x 1200 (some can even go as high as 1800 x 1440). The data projector

or monitor connected to the interface output must be compatible with the

horizontal scan rate and vertical refresh rate of the computer’s video signal.

Please check the documentation for both the computer graphics card and the

data display device to ensure compatibility.

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

Installation

CAUTION: Installation of the CIA116 must only be carried out by qualified

technicians.

This section offers step-by-step instructions for installing the CIA116. An Application Diagram is

provided on page 6, and Front and Rear Panel Connector and Control Diagrams are on page 7.

Note: Read the instructions carefully before initiating the installation procedure. Before you

begin, make sure that there is no power connected to the system, and that all the power buttons

are off.

1.) Set the dipswitches as appropriate for your installation (see page 9 for more details). The

CIA116 factory default output format is RGBHV. If your display device, routing system, or

cabling require a different format, use the dipswitches to change the output signal to RGBS or

RGsB as necessary. For best results with high-resolution data projectors / presentation

monitors, refer to Optimal Settings for LCD / DMD / D-ILA / Plasma Displays on page 9.

2.) For mounting the CIA116 under a conference or boardroom table, computer workshop,

or podium - use #6- ½” wood screws to mount the interface at the desired location (the

IN9252 integral mounting brackets and wood screws are included).

3.) For rack-mount installations - make sure that the CIA116 is securely installed in a standard

19” equipment rack using the IN9254 / IN9255 rack ears (optional).

Note: The IN9254 rack ears can accommodate four additional A/V connector modules.

4) For Flush-Mount Applications - install the interface into a table, podium or presentation

furniture using the optional IN9253 flush-mount brackets.

Note: A Dimensions Diagram is provided on page 15.

5) Terminate any audio, video and control cables to the backside of the A/V connector modules as

required by your installation (a complete list of available modules is provided on pages 13 and

14). The CIA116 can also be installed with one or two IN9367D double size blank plates

(included).

6) Using the IN9334 3/32” Allen Wrench (included), attach the modular connector plate(s) to the

front panel of the CIA116, making sure that none of the cables are pinched or damaged.

7) Connect the video coax cable to the (5) BNC female connectors using three, four, or five high-

resolution BNC cables, or a multi-conductor RGBHV, RGBS or RGB "snake.” The IN7000 /

IN7200 / IN7300 and IN7400P Series high-resolution cables are well suited for this purpose.

Take care while making connections to insure that the red output is connected to the red input,

green output to the green input, etc.

8) Connect the audio output cable to the appropriate pins on the CIA116 5-pin captive screw

connector. Make sure that the stereo audio output is connected appropriately for a balanced or

unbalanced signal as required by the installation (see the diagram on the following page).

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

Unbalanced Output - connect to the Left, Right and Ground connectors.

Balanced Output - connect to Left +, Left-, Right+, Right- and Ground connectors.

5LJKW*URXQG

/HIW*URXQG

/HIW

5LJKW

8QEDODQFHG

%DODQFHG

5LJKW*URXQG

/HIW*URXQG

/HIW

5LJKW

5LJKW

/HIW

9.) Apply power to the CIA116 using the IN9230 power cord (included). The power LED on the

front of the unit will illuminate.

10.) Turn the computer and computer monitor off. Disconnect the computer monitor from the

video output port on the computer.

11.) Connect the computer graphics card to the CIA116 15-pin video input port.

• PC / MAC / SGI Computers with 15-pin HD Video Ports - can be connected via

IN8000M-1 / IN8200M-1 Series high-resolution coaxial VGA cables.

• Older Macintosh (15-pin D) / SUN (13W3) / Workstations (4 or 5 BNC) - can be

connected using the appropriate input / output cables listed in the chart on the following page.

12).Connect the computer sound card output (if applicable) to the CIA116 3.5mm female stereo

audio input connector using an IN8200-1 Series cable [15-pin HD with 3.5mm (M-M) mini

DIN], or an IN9106 audio patch cable (3.5mm stereo mini male to 3.5mm stereo mini male).

For computers with RCA connectors, use the IN9107 audio adapter cable [(1) 3.5mm stereo mini

male to (2) RCA male].

13.)Connect the local computer monitor (if applicable) to the local monitor output port of the

CIA116. Monitors with 15-pin VGA connectors will attach directly to the interface. For

other types of monitors, refer to the table on the next page.

If a local monitor is required, disengage the monitor emulation feature by

pressing the Monitor Emulation Button. See page 9 for more details.

14.)Turn the computer and computer monitor on. If necessary, adjust the sharpness and

horizontal position controls (see page 8 for more details).

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

ADAPTER / EXTENSION CABLES FOR INPUT AND LOCAL MONITOR OUTPUT

The CIA116 has 15-pin HD VGA-type input and local monitor output connector ports. The

following cables / adapters are available:

Computer 3’ 6’ 12’ 25’ 35’ +

VGA: 15-Pin HD

Input Cable (M-M) IN8003M-1 IN8006M-1 IN8012M-1 IN8025M-1 IN80xxM-1

Output Cable (M-F) IN8006-1 IN8012-1 IN8025-1 IN80xx-1

VGA with Stereo Audio: 15-Pin HD with 3.5mm (M-M) mini DIN

Input Cable (M-M) IN8203M-1 IN8206M-1 IN8212M-1 IN8225M-1 IN82xxM-1

Output Cable (M-F) IN8203-1 IN8206-1 IN8212-1 IN8225-1 IN82xx-1

MAC with 15-Pin D:

Input Cable (M-M) IN9140M IN9144M

Output Cable (M-F) IN9141 IN9145

MAC G3, G4 and PowerBook with 15-Pin HD*:

Input Cable (M-M) IN8006M-1 IN8012M-1 IN8025M-1 IN80xxM-1

Output Cable (M-F) IN8006-1 IN8012-1 IN8025-1 IN80xx-1

SUN: 13W3 (may also be used with SGI with RGsB output)

Input Cable (M-M) IN9142M IN9146M

Output Cable (M-F) IN9143 IN9147

Workstation: 5 BNC / RGBHV

Input Cable (M-M) IN9045-L6 IN9045-L12 IN9045-L25 IN9045-Lxx

Output Cable (M-M) IN9045-L6 IN9045-L12 IN9045-L25 IN9045-Lxx

Workstation: 4 BNC / RGBS

Input Cable (M-F) IN9100

*Newer Mac G3 models (with translucent cases) have 15-Pin HD connectors (pins arranged in 3 rows).

Older G3 models (with solid white enclosures) incorporate 15-Pin D connectors (pins arranged in 2 rows).

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

CIA116 FRONT PANEL CONNECTORS AND CONTROLS

Horizontal

Position

Control

Monitor

Emulation with

LED Indicator

Video

Input Local

Monitor

Output

Power

Indicator

Stereo

Audio

Input

A / V

Connector

Modules

Convenience

Outlets

CIA116 REAR CONNECTORS AND CONTROLS

Power

Connector Sharpness

Control Dip

Switches

Audio

Output

Connector

(Balanced or Unbalanced)

Video

Output

Connectors

A / V Connector

Module Cable

Strain Relief

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

HORIZONTAL POSITION CONTROL

The location of the horizontal position control is shown in the Front Panel Connectors and

Controls Diagram on the previous page. Press and release the rocker button to shift the image by

one step to the left or right. Press and hold the button to shift the image continuously.

Note: The horizontal position control has no effect on the local computer monitor.

If the horizontal position adjustment is set to an extreme position on either the display device or

the CIA116, the output image may appear dark and / or the colors may be displayed improperly.

To position the video image and achieve optimum picture quality:

1. Set the display device’s horizontal position control to the center of its adjustment range.

2. Adjust the horizontal position control on the CIA116 until the picture is centered properly

on the display device.

Note: The horizontal position control does not work with RGsB input signals.

SHARPNESS CONTROL

The CIA116 sharpness / peaking circuitry provides variable high frequency equalization that can

compensate for signal losses due to long output cable runs. Careful optimization of the sharpness

control at the time of installation will result in a greatly enhanced image with increased clarity and

edge detail. The amount of high frequency boost required for each display system will vary

depending on the length and bandwidth performance of the video output cables, and, to a lesser

extent, the resolution and frequency of the input signal. When using short output cables, the

sharpness control should usually be placed at the minimum setting to avoid over-peaking.

The sharpness control is located on the back of the interface (see diagram on page 7). Using the

IN9339 Adjustment Tool (provided), turn the sharpness control clockwise to increase the

sharpness setting, and counterclockwise to decrease the sharpness setting. The factory default

setting is minimum (no sharpness / peaking enhancement). The following guidelines are useful in

selecting the optimal sharpness / peaking setting:

If the image is soft and / or fine details in the picture lack clarity:

The sharpness is probably set too low. Increase the sharpness control setting.

If a white, ghosted image appears to the right side of the lines / characters:

The sharpness is probably set too high (over-peaked). Decrease the sharpness control

setting.

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Equipo de grabación de Extron electronics

Extron electronics

Extron electronics RAC 104 Manual de usuario

Extron electronics

Extron electronics RGB 103 Manual de usuario

Extron electronics

Extron electronics VN-Matrix Manual de usuario

Extron electronics

Extron electronics RGB 158xi Manual de usuario

Extron electronics

Extron electronics RGB 124 Manual de usuario

Extron electronics

Extron electronics Architectural Series Universal Interfaces with Audio and ADSP RGB... Manual de usuario

Extron electronics

Extron electronics Quantum Ultra Series Manual de usuario

Extron electronics

Extron electronics RGB 109xi Manual de usuario

Extron electronics

Extron electronics IP LINK IPL T SFI244 Manual de usuario

Extron electronics

Extron electronics SSP 7.1 Manual de usuario

Extron electronics

Extron electronics RGB 109xi Manual de usuario

Extron electronics

Extron electronics RGB 326 Manual de usuario

Extron electronics

Extron electronics RGB 190F Manual de usuario

Extron electronics

Extron electronics Interfaces RGB 500 Series Manual de usuario

Extron electronics

Extron electronics MAV Series Manual de usuario

Extron electronics

Extron electronics AXI 02 AT Manual de usuario

Extron electronics

Extron electronics Wall and Floor Box Mountable Interfaces RGB... Manual de usuario

Extron electronics

Extron electronics RGB 190F Manual de usuario

Extron electronics

Extron electronics Extron IPL T S4 Manual de usuario

Extron electronics

Extron electronics RGB 170 Manual de usuario

Extron electronics

Extron electronics StudioStation 100 Manual de usuario

Extron electronics

Extron electronics IPL T S1 Manual de usuario

Extron electronics

Extron electronics RGB 160xi Manual de usuario

Extron electronics

Extron electronics SSP 200 Manual de usuario

Manuales populares de Equipo de grabación de otras marcas

KV2 Audio

KV2 Audio 500 Series Manual de usuario

Robotics Technologies

Robotics Technologies microBus-Cam II Manual de usuario

Seca

Seca 460 Manual de usuario

Cognex

Cognex MVS-8000 Series Manual de usuario

Mect

Mect MPNC006 Series Manual de usuario

Bad Caf

Bad Caf THE LEASH Manual de usuario

Strymon

Strymon NIGHTSKY Manual de usuario

Mitsubishi Electric

Mitsubishi Electric 16CH DIGITAL RECORDER DX-TL5000U Manual de usuario

Tews Technologies

Tews Technologies TPMC465 Manual de usuario

Honeywell

Honeywell Excel 50 Manual de usuario

SeaLevel

SeaLevel COMM+8.LPCI Manual de usuario

Arturia

Arturia AUDIOFUSE STUDIO Manual de usuario

Rukra

Rukra RK-1240 Manual de usuario

Samson

Samson SCOM Manual de usuario

Dynacord

Dynacord DPS260 Manual de usuario

Nice

Nice Core Manual de usuario

Pyle Pro

Pyle Pro PSS8 Manual de usuario

RF-System

RF-System TinyGate Manual de uso y cuidado
