Speciﬁcations — MAV Plus 64 Series

Extron MAV Plus 3248 through MAV Plus 6464 • Specications

Video— video BMEs

Routing ........................................... 64 x 64, 64 x 48, 64 x 32, 48 x 64, 48 x 48, 48 x 32, 32 x 48, or 32 x 64 matrix

Gain................................................. Unity

Bandwidth...................................... 150 MHz (-3 dB), fully loaded

0 - 10 MHz.......................... No more than +0.1 dB to -0.1 dB

0 - 130 MHz........................ No more than +0.1 dB to -0.1 dB

Crosstalk......................................... -80 dB @ 1 MHz, -62 dB @ 10 MHz, -52 dB @ 30 MHz

Switching speed ............................ 200 ns (max.)

Video input— video BMEs

Number/signal type..................... 32, 48, or 64 composite video

Connectors ..................................... 32, 48, or 64 BNC female

Nominal level ................................ 1 Vp-p for composite video

Minimum/maximum levels........ Analog: 0.5 V to 2.0 Vp-p with no offset

Impedance...................................... 75 ohms

Horizontal frequency.................... 15 kHz to 150 kHz

Vertical frequency.......................... 30 Hz to 150 Hz

Return loss...................................... <-30 dB @ 5 MHz

DC offset (max. allowable)........... 1.5 V

Video output— video BMEs

Number/signal type..................... 32, 48, or 64 composite video

Connectors ..................................... 32, 48, or 64 BNC female

Nominal level ................................ 1 Vp-p for composite video

Minimum/maximum levels........ 0 V to 2.0 Vp-p (follows input)

Impedance...................................... 75 ohms

Return loss...................................... <-30 dB @ 5 MHz

DC offset......................................... ±5 mV with input at 0 offset

Switching type............................... Vertical interval

Sync— video BMEs

Genlock connectors....................... 1 BNC female

Standards........................................ NTSC 3.58, NTSC 4.43, PAL, SECAM

Audio— audio BMEs

Routing ........................................... (32, 48, or 64) x (32, 48, or 64) stereo or mono matrix

N Both stereo (2 channel) and mono (1 channel) audio models are available.

Gain................................................. Unbalanced output: -6 dB; balanced output 0 dB

Frequency response ...................... 20 Hz to 20 kHz, ±0.05 dB

THD + Noise.................................. 0.03% @ 1 kHz at nominal level

S/N.................................................. >90 dB, balanced, at maximum output (21 dBu), unweighted

Crosstalk......................................... <-80 dB @ 1 kHz, fully loaded

Stereo channel separation............ >80 dB @ 1 kHz

CMRR.............................................. >75 dB @ 20 Hz to 20 kHz

Audio input— audio BMEs

Number/signal type..................... 32, 48, or 64 stereo balanced/unbalanced or

32, 48, or 64 mono balanced/unbalanced

Connectors

Stereo models..................... (32, 48, or 64) 3.5 mm captive screw connectors, 5 pole

Mono models..................... (32, 48, or 64) 3.5 mm captive screw connectors, 3 pole

Impedance...................................... >10k ohm, balanced/unbalanced, DC coupled

Speciﬁcations — MAV Plus 64 Series, cont’d

Extron MAV Plus 3248 through MAV Plus 6464 • Specications

Nominal level ................................ -10 dBV (316 mVrms)

Maximum level.............................. +19.5 dBu, (balanced or unbalanced) at 1% THD+N

Input gain adjustment .................. -18 dB to +24 dB, adjustable per input by RS-232/422, Ethernet, or front

panel

N 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈2 dBu

Audio output— audio BMEs

Number/signal type..................... 32, 48, or 64 stereo balanced/unbalanced or

32, 48, or 64 mono balanced/unbalanced

Connectors

Stereo models..................... (32, 48, or 64) 3.5 mm captive screw connectors, 5 pole

Mono models..................... (32, 48, or 64) 3.5 mm captive screw connectors, 3 pole

Impedance...................................... 50 ohms unbalanced, 100 ohms balanced

Gain error ....................................... ±0.1 dB channel to channel

Maximum level (Hi-Z) ................. >+21 dBu, balanced or unbalanced at 0.1% THD+N

Maximum level (600 ohm)........... >+15 dBm, balanced or unbalanced at 0.1% THD+N

Output volume range................... 0 to 64 (-98 dB to 0 dB) in 0.5 dB increments from steps 1 to 64, 35 dB

increment from step 0 to 1

Control/remote — switcher

Serial control port.......................... 1 RS-232 or RS-422, 9-pin female D connector

Baud rate and protocol................. 9600 (default), 19200, 38400, 115200 baud (adjustable); 8 data bits, 1 stop bit,

no parity

Serial control pin conﬁgurations. RS-232: 2 = TX, 3 = RX, 5 = GND

RS-422: 2 = TX-, 3 = RX-, 5 = GND, 7 = RX+, 8 = Tx+

Ethernet control port..................... 1 RJ-45 female connector

Ethernet data rate.......................... 10/100Base-T, half/full duplex with autodetect

Ethernet protocol........................... ARP, DHCP, ICMP (ping), TCP/IP, Telnet, HTTP

Program control............................. Extron's control/conﬁguration program for Windows®

Extron's Simple Instruction Set (SIS™)

Microsoft®Internet Explorer, Telnet

General

Power.............................................. 100 VAC to 240 VAC, 50/60 Hz, internal, primary and redundant

Video models ..................... 110 watts at 115 VAC, 60 Hz

All audio models............... 195 watts at 115 VAC, 60 Hz

N A redundant power supply is standard.

Temperature/humidity................ Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Cooling

Video models ..................... Fan, right to left (viewed from the front panel)

Audio models .................... Convection, vents on right and left sides

Rack mount.................................... Yes, with included parts

Enclosure type ............................... Metal

Enclosure dimensions

Video BMEs........................ 10.5" H x 17.0" W x 14.1" D (6U high, full rack wide)

(26.7 cm H x 43.2 cm W x 35.8 cm D)

Audio BMEs....................... 12.25" H x 17.0" W x 14.1" D (7U high, full rack wide)

(31.1 cm H x 43.2 cm W x 35.8 cm D)

Extron MAV Plus 3248 through MAV Plus 6464 • Specications

Product weight per BME

32 x 48 through 64 x 64 Series video BMEs ......................... 18.0 lbs (8.2 kg)

32 x 48 through 64 x 64 Series stereo audio BMEs.............. 19.0 lbs (8.6 kg)

32 x 48 through 64 x 64 Series mono audio BMEs.............. 18.5 lbs (8.4 kg)

Shipping weight per BME

32 x 48 through 64 x 64 Series video BMEs ......................... 29 lbs (13 kg)

32 x 48 through 64 x 64 Series stereo audio BMEs.............. 31 lbs (14 kg)

32 x 48 through 64 x 64 Series mono audio BMEs.............. 30 lbs (14 kg)

DIM weight, international, per BME ......44 lbs (20 kg)

Vibration......................................... ISTA 1A in carton (International Safe Transit Association)

Regulatory compliance

Safety................................... CE, CUL, UL

EMI/EMC .......................... CE, C-tick, FCC Class A, ICES, VCCI

MTBF............................................... 30,000 hours

Warranty......................................... 3 years parts and labor

N All nominal levels are at ±10%.

N Speciﬁcations are subject to change without notice.

7.6-103108-D6
