Specifications — IPL T PC1, IPL T PC1i

AC control interface

Connectors

IPL T PC1 .......................... 1 female USA/Edison power connector

IPL T PC1i ......................... 1 female IEC power connector

Voltage

IPL T PC1 .......................... 120 VAC, 50-60 Hz

IPL T PC1i ......................... 220 VAC, 50-60 Hz

Maximum AC load

IPL T PC1 .......................... 12 A, 1440 watts at 120 VAC

IPL T PC1i ......................... 10 A, 2200 watts at 220 VAC

Serial control interface

Serial control port ........................ (1) RS-232 only, 3.5 mm captive screw connectors, 4 pole

Baud rate and protocol ............... 115200 to 300 baud (9600 baud = default) ; 8 (default) or 7 data bits; 1 (default) or 2

stop bits; no parity (default), or even or odd parity

Serial control pin configurations 1 = TX, 2 = RX, 3 = GND, 4 = +5 VDC

Ethernet control interface

Connector...................................... 1 RJ-45 female connector

Data rate ........................................ 10/100Base-T, half/full duplex with autodetect

Protocols ....................................... ARP, DHCP, ICMP (ping), TCP/IP, UDP/IP, Telnet, HTTP, SMTP

Default settings ............................ Link speed and duplex level = autodetected

IP address = 192.168.254.254

Subnet mask = 255.255.0.0

Gateway = 0.0.0.0

DHCP = off

Web server .................................... Up to 200 simultaneous sessions

7.25 MB nonvolatile user memory

Program control ........................... Extron’s Simple Instruction Set (SIS™)

Global Viewer requirements...... Microsoft®Internet Explorer ver. 6 or higher

Contact closure interface (input only)

Quantity/type .............................. 1 contact closure input

Contact input control connector . (1) 3.5 mm captive screw connector, 4 pole (shared with IR output port)

Contact closure (input only)

Input voltage range ......... 0 to 5 VDC, clamped at +5.1 V

Input impedance .............. 10k ohms

Threshold .......................... 1.6 VDC

Pin configuration ......................... 1 = contact input, 2 = GND

IR control interface

IR control port .............................. (1) 3.5 mm captive screw connector, 4 pole (shared with contact closure input port)

Pin configurations ....................... 3 = S (IR signal output), 4 = GND

IR output carrier frequency........ 30 kHz to 1 MHz

General

Power input .................................. 100 VAC to 240 VAC, 50/60 Hz, 5 watts, internal, on 1 male IEC power connector

IPL T PC1 .......................... 12 A (max.)

IPL T PC1i ......................... 10 A (max.)

Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Cooling .......................................... Convection, unvented

1-2 IPL T PC1, IPL T PC1i Power Control • Specifications

Rack mount................................... Yes, with optional 1U rack shelf, part #60-190-01 or 60-604-01; or 1U, 6" deep rack

shelf, part #60-190-10 or 60-604-10.

Also furniture mountable with optional VersaTools under desk mounting kit, part

#70-077-01.

Enclosure type.............................. Metal

Enclosure dimensions ................. 1.7" H x 4.3" W x 6.0" D (1U high, quarter rack wide)

4.3 cm H x 10.9 cm W x 15.2 cm D

(Depth excludes connectors.)

Product weight............................. 1.0 lbs (0.5 kg)

Shipping weight ........................... 3 lbs (2 kg)

Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)

Listings .......................................... UL, CUL

Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES

MTBF ............................................. 30,000 hours

Warranty ....................................... 3 years parts and labor

All nominal levels are at ±10%.

Specifications are subject to change without notice.

(7.52-070207-D3)

IPL T PC1, IPL T PC1i Power Control • Specifications 1-3
