ExtremeWireless AP3917i/e Manual de usuario
ExtremeWireless™AP3917i/e
FCC/ROW Installation Guide
9035166
Published January 2018
Copyright © 2018 Extreme Networks, Inc. All rights reserved.
Legal Notice
Extreme Networks, Inc. reserves the right to make changes in specifications and other information
contained in this document and its website without prior notice. The reader should in all cases
consult representatives of Extreme Networks to determine whether any such changes have been
made.
The hardware, firmware, software or any specifications described or referred to in this document
are subject to change without notice.
Trademarks
Extreme Networks and the Extreme Networks logo are trademarks or registered trademarks of
Extreme Networks, Inc. in the United States and/or other countries.
All other names (including any product names) mentioned in this document are the property of
their respective owners and may be trademarks or registered trademarks of their respective
companies/owners.
For additional information on Extreme Networks trademarks, please see:
www.extremenetworks.com/company/legal/trademarks
Software Licensing
Some software files have been licensed under certain open source or third-party licenses. End-
user license agreements and open source declarations can be found at:
www.extremenetworks.com/support/policies/software-licensing
Support
For product support, phone the Global Technical Assistance Center (GTAC) at 1-800-998-2408
(toll-free in U.S. and Canada) or +1-408-579-2826. For the support phone number in other
countries, visit: http://www.extremenetworks.com/support/contact/
For product documentation online, visit: https://www.extremenetworks.com/documentation/
Table of Contents
Preface.........................................................................................................................................4
Text Conventions...................................................................................................................................................................4
Platform-Dependent Conventions................................................................................................................................4
Providing Feedback to Us.................................................................................................................................................5
Getting Help.............................................................................................................................................................................5
Extreme Networks Documentation............................................................................................................................. 6
Chapter 1: Overview...................................................................................................................7
Features..................................................................................................................................................................................... 7
LED Indicators........................................................................................................................................................................ 9
Chapter 2: Hardware Mounting and Installation..................................................................10
Verifying the Box Contents............................................................................................................................................ 10
Positioning the AP for Installation................................................................................................................................11
Mounting the AP3917i/e to a Wall or Solid Surface.............................................................................................11
Mounting the AP3917i/e to a Pole...............................................................................................................................14
Mounting the AP3917i/e Using Extension Arm.....................................................................................................16
Installing External Antennas...........................................................................................................................................17
Connecting the AP3917i/e to a Power Source......................................................................................................17
LAN/Console Connections............................................................................................................................................. 17
Professional Installation Instruction.......................................................................................................................... 20
Chapter 3: Specifications........................................................................................................22
Chapter 4: Regulatory Information.......................................................................................24
Safety Guidelines................................................................................................................................................................24
FCC Declaration of Conformity Statement........................................................................................................... 24
FCC Radiation Exposure Statement..........................................................................................................................25
Industry Canada Notice...................................................................................................................................................25
European Waste Electrical and Electronic Equipment (WEEE) Notice.................................................. 28
Hazardous Substances.................................................................................................................................................... 29
NCC Statements..................................................................................................................................................................29
Declaration of Conformity in Languages of the European Community................................................. 30
ExtremeWireless™ AP3917i/e FCC/ROW Installation Guide 3
Preface
Text Conventions
The following tables list text conventions that are used throughout this guide.
Table 1: Notice Icons
Icon Notice Type Alerts you to...
General Notice Helpful tips and notices for using the product.
Note Important features or instructions.
Caution Risk of personal injury, system damage, or loss of data.
Warning Risk of severe personal injury.
New This command or section is new for this release.
Table 2: Text Conventions
Convention Description
Screen displays This typeface indicates command syntax, or represents information as it appears on the
screen.
The words enter and
type
When you see the word “enter” in this guide, you must type something, and then press
the Return or Enter key. Do not press the Return or Enter key when an instruction
simply says “type.”
[Key] names Key names are written with brackets, such as [Return] or [Esc]. If you must press two
or more keys simultaneously, the key names are linked with a plus sign (+). Example:
Press [Ctrl]+[Alt]+[Del]
Words in italicized type Italics emphasize a point or denote new terms at the place where they are defined in
the text. Italics are also used when referring to publication titles.
Platform-Dependent Conventions
Unless otherwise noted, all information applies to all platforms supported by ExtremeXOS®software,
which are the following:
•ExtremeSwitching®switches
•Summit®switches
•SummitStack™
ExtremeWireless™ AP3917i/e FCC/ROW Installation Guide 4
When a feature or feature implementation applies to specific platforms, the specific platform is noted in
the heading for the section describing that implementation in the ExtremeXOS command
documentation (see the Extreme Documentation page at http://
documentation.extremenetworks.com). In many cases, although the command is available on all
platforms, each platform uses specific keywords. These keywords specific to each platform are shown in
the Syntax Description and discussed in the Usage Guidelines sections.
Providing Feedback to Us
We are always striving to improve our documentation and help you work better, so we want to hear
from you! We welcome all feedback but especially want to know about:
•Content errors or confusing or conflicting information.
•Ideas for improvements to our documentation so you can find the information you need faster.
•Broken links or usability issues.
If you would like to provide feedback to the Extreme Networks Information Development team about
this document, please contact us using our short online feedback form. You can also email us directly at
internalinfodev@extremenetworks.com.
Getting Help
If you require assistance, contact Extreme Networks using one of the following methods:
•GTAC (Global Technical Assistance Center) for Immediate Support
•Phone: 1-800-998-2408 (toll-free in U.S. and Canada) or +1 408-579-2826. For the support
phone number in your country, visit: www.extremenetworks.com/support/contact
•Email: support@extremenetworks.com. To expedite your message, enter the product name or
model number in the subject line.
•Extreme Portal — Search the GTAC knowledgebase, manage support cases and service contracts,
download software, and obtain product licensing, training, and certifications.
•The Hub — A forum for Extreme customers to connect with one another, answer questions, and
share ideas and feedback. This community is monitored by Extreme Networks employees, but is not
intended to replace specific guidance from GTAC.
Before contacting Extreme Networks for technical support, have the following information ready:
•Your Extreme Networks service contract number and/or serial numbers for all involved Extreme
Networks products
•A description of the failure
•A description of any action(s) already taken to resolve the problem
•A description of your network environment (such as layout, cable type, other relevant environmental
information)
•Network load at the time of trouble (if known)
•The device history (for example, if you have returned the device before, or if this is a recurring
problem)
•Any related RMA (Return Material Authorization) numbers
Preface
ExtremeWireless™ AP3917i/e FCC/ROW Installation Guide 5
Extreme Networks Documentation
To find Extreme Networks product guides, visit our documentation pages at:
Current Product Documentation www.extremenetworks.com/documentation/
Archived Documentation (for earlier
versions and legacy products)
www.extremenetworks.com/support/documentation-archives/
Release Notes www.extremenetworks.com/support/release-notes
Open Source Declarations
Some software files have been licensed under certain open source licenses. More information is
available at: www.extremenetworks.com/support/policies/software-licensing.
Preface
ExtremeWireless™ AP3917i/e FCC/ROW Installation Guide 6
1Overview
Features
LED Indicators
The AP3917 is an IP67 rated outdoor Access Point with 802.11ac dual band 2:2 radios. The AP3917 is easy
to install, lightweight, and is available in an internal (AP3917i) and external (AP3917e) antenna model.
Each model includes 802.11 radios, an IoT radio, and a GPS radio. The antennas are built into the AP3917i
while you need to install external antennas or terminators for the AP3917e model. In this document, the
functionality, features, and the procedures apply to both the models when AP3917i/e is used.
Note
The AP3917i/e requires a minimum base firmware of 10.41.
Features
The AP3917i/e model has the following features:
•Radios: 2 radios (2.4GHz and 5GHz); 1 IoT/BLE/802.15.4 Radio (2.4 GHz)
•Console Port: RJ45
•One RJ45, 10/100/1000 Mbps Ethernet Port (GE1) with PoE
•One RJ45 , 10/100/1000 Mbps Ethernet Port (GE2)
•IP67 Connectors on all ports
•LEDs: 4
•One Reset button
•Power: PoE 802.3af or 802.3at
•GPS Receiver (will be supported via a future firmware release)
•Antennas:
•AP3917i - Five internal antennas (one BLE antenna).
•AP3917e- Five external antennas (one BLE antenna)
•Temperature:
-40 to +65°C without solar radiation
-40 to +55°C with solar radiation
•Enclosure: Cast Aluminum base and outdoor rated PC cover
ExtremeWireless™ AP3917i/e FCC/ROW Installation Guide 7
Figure 1: Top and Side Views of AP3917i
1 IoT/BLE Radio
2 Radio - 5 GHz
3 Radio - 2.4 GHz
4 Status
5 GE1 (PoE IN)
6 GE2
7 Console/Reset
8 Vent
Figure 2: Top and Side Views of AP3917e
Overview
ExtremeWireless™ AP3917i/e FCC/ROW Installation Guide 8
1 IoT/BLE Radio
2 Radio - 5 GHz
3 Radio - 2.4 GHz
4 Status
5 GE1 (PoE IN)
6 GE2
7 Console/Reset
8 2.4 G - Antenna 1 and 2
9 Vent
10 5G - Antenna 1
11 BLE/802.15.4 Antenna
12 5 G - Antenna 2
LED Indicators
Both the Radio LEDs will be Green when they are ON and the LEDs will not have any lights when they
are OFF. Blue LED indicates the IoT status.
Table 3: AP3917ie LEDs
Item Status Description
IoT Radio LED
Blue Indicates IoT application is running
2.4GHz Radio LED
Green Indicates radio is enabled
5 GHz Radio LED
Green Indicates radio is enabled
Status LED
Green Indicates AP is working normally
Amber Indicates system failure
Overview
ExtremeWireless™ AP3917i/e FCC/ROW Installation Guide 9
2Hardware Mounting and
Installation
Verifying the Box Contents
Positioning the AP for Installation
Mounting the AP3917i/e to a Wall or Solid Surface
Mounting the AP3917i/e to a Pole
Mounting the AP3917i/e Using Extension Arm
Installing External Antennas
Connecting the AP3917i/e to a Power Source
LAN/Console Connections
Professional Installation Instruction
This section describes guidelines for mounting and connecting the AP3917i/e easily and safely. The
access point can be mounted to a wall, girder, ceiling, pole, or vehicle using the appropriate bracket. The
AP3917i/e mounting brackets are sold separately.
Warning
Only qualified personnel should perform installation procedures.
Verifying the Box Contents
Verify the contents of the box and ensure that the following items are available:
Table 4: Contents of the AP3917i/e Box
Quantity Item
1 AP3917i/e Quick Reference Guide
1 Cloud Quick Start Card
1 AP3917i/e Access Point
The following hardware is included:
1 M4 screw assembly with star washer
1 Ring terminal
ExtremeWireless™ AP3917i/e FCC/ROW Installation Guide 10
