The Future of

Networking is

Products at a Glance

Scalability. Agility. Simplicity.

Products from Extreme Networks

www.extremenetworks.com

Choose Extreme

More applications, more complexity—telephony, storage, mobility and applications—all required

at a frenzied pace. Higher stakes—downtime and security incidents that can cripple operations and

raise costs. Fewer resources—constrained electrical power and fewer people to manage an increased

workload. More devices—an end-user community that is highly mobile and with high expectations. All

of this with less budget to get it done. How do you solve these issues and still be ready for more?

Extreme Networks®solutions deliver the scalability, agility, and simplicity you need to address

your exciting and yet demanding challenges:

• Scalability to enter new markets, meet the demands of the ‘peaks’ of the business world,

and scale with your organization as it grows and evolves.

• Agility to implement new applications quickly and respond to your business and user

community, without making major investment and change.

• Simplicity that delivers on the vision of an environment that is simpler to install, operate

and maintain.

Prepare for the future—Be Extreme.

Our future-proof designs allow you to avoid forklift upgrades and give you backward and forward solution

compatibility, ultimately protecting your past and future network investments.

Get it Done.

Extreme.

Switching Portfolio

BlackDiamond

Family

The exacting demands of IP Telephony deployments, enterprise

aggregation, corporate data centers and network backbones, and

metro Ethernet provider Points of Presence require solutions that

combine consistent performance, carrier-class availability, enhanced

security and simpliﬁed management. BlackDiamond®products from

Extreme Networks are designed and purpose-built to meet these

mission-critical requirements.

BlackDiamond 20808

Ideal for the metro Ethernet core where price/performance ratio, high density and resources to support

new service offerings are required.

• Lowest cost per 10 Gigabit Ethernet port provides the most affordable per-bit transport

• Unparalleled per-slot and system capacity in its class

• Designed to support residential, business and wireless backhaul services on the same platform

• ExtremeXOS®modular high availability and extensible operating system

• Redundant, hot-swappable management and switching modules, power supplies and I/O modules

BlackDiamond 12800R Series

Ideal for metro aggregation where high service density with carrier-class scalability and availability

are required.

• ExtremeXOS modular high availability and extensible operating system

• Ingress and egress hierarchical Quality of Service (QoS) on gigabit and 10 Gigabit Ethernet ports

to handle thousands of subscribers

• High-performance multicast, MAC-in-MAC and MPLS for network scaling

• Advanced vMAN service multiplexing, cross-connect and network-peering features for Carrier

Ethernet deployments

• Redundant, hot-swappable management

BlackDiamond 12804C

Ideal for small to medium network cores where availability and security are crucial.

• ExtremeXOS modular high availability and extensible operating system

• Hardware support for IPv6 and NAT

• CLEAR-Flow Security Rules Engine

• Redundant, hot-swappable management and switching modules, power supplies and I/O modules

BlackDiamond 20808 BlackDiamond 12804CBlackDiamond 12800R Series

BlackDiamond 10808

Ideal for network core and data centers where high Gigabit Ethernet density, availability and security

are crucial.

•ExtremeXOS modular high availability and extensible operating system

•Hardware support for IPv6, MPLS, MAC-in-MAC and NAT

•CLEAR-Flow Security Rules Engine

•Redundant, hot-swappable management and switching modules, power supplies and I/O modules

BlackDiamond 8800 Series

Ideal for high density gigabit network edge, mid-sized network cores and data centers.

•ExtremeXOS modular high availability and extensible operating system

•Policy-based QoS and routing capability

•CLEAR-Flow Security Rules Engine (c series)

•High-performance gigabit and 10 Gigabit Ethernet connectivity with low power consumption

•Redundant, hot-swappable management and switching modules, power supplies and I/O modules

•High density 10/100/1000 Power over Ethernet (PoE)

Speeds.

Speed your feeds.

Feed your

BlackDiamond 10808 BlackDiamond 8800

BLACKDIAMOND

F E A T U R E S

20808 10808 12804R 12802R 12804C 8810 8806

Max Auto-Negotiating

10/100/1000BASE-T

Ports

— 480 80 40 80 432 240

Max 1 Gigabit

Ethernet Ports (SFP) 320 480 80 40 80 440 248

Max 10 Gigabit

Ethernet Ports 64 48 8 4 8 72 40

Form Factor/

Footprint

Chassis/

14.5RU

Chassis/

22RU

Chassis/

10RU

Chassis/

3RU

Chassis/

10RU

Chassis/

14RU

Chassis/

10RU

Total Switching Capacity 2 Tbps 1.28 Tbps 160 Gbps 80 Gbps 160 Gbps 1.45 Tbps 816 Gbps

Programmable ASICs Yes Yes Yes Yes Yes No No

Redundant Power Yes Yes Yes Yes Yes Yes Yes

Power over Ethernet

(802.3af) No No No No No Yes Yes

Wire-Speed Layer 2/

Layer 3 Switching Yes Yes Yes Yes Yes Yes Yes

Routing - IPv4

BGP4, IS-IS,

OSPF, RIP

v1/v2, PIM,

MSDP

BGP4, IS-IS,

OSPF, RIP

v1/v2, PIM,

MSDP

BGP4, IS-IS,

OSPF, RIP

v1/v2, PIM,

MSDP

BGP4, IS-IS,

OSPF, RIP

v1/v2, PIM,

MSDP

BGP4, IS-IS,

OSPF, RIP

v1/v2, PIM,

MSDP

BGP4, IS-IS,

OSPF, RIP

v1/v2, PIM,

MSDP

BGP4, IS-IS,

OSPF, RIP

v1/v2, PIM,

MSDP

Routing - IPv6

RIPng,

OSPFv3,

IS-IS

RIPng,

OSPFv3,

IS-IS

RIPng,

OSPFv3,

IS-IS

RIPng,

OSPFv3,

IS-IS

RIPng,

OSPFv3,

IS-IS

RIPng,

OSPFv3,

IS-IS

RIPng,

OSPFv3,

IS-IS

Policy-Based

Routing/Switching Yes Yes Yes Yes Yes Yes Yes

Policy-Based Quality of

Service (QoS)

Yes/ Three

Tier Yes Yes/Three

Tier

Yes/Three

Tier Yes Yes Yes

Network Login — Yes Yes Yes Yes Yes Yes

Access Control Lists Yes Yes Yes Yes Yes Yes Yes

Universal Port Yes Yes Yes Yes Yes Yes Yes

CLI Scripting Yes Yes Yes Yes Yes Yes Yes

Widgets Yes Yes Yes Yes Yes Yes Yes

Layer 3 Virtual Switching Yes Yes Yes Yes Yes No No

vMANs (802.1ad) Yes Yes Yes Yes Yes Yes Yes

MAC-in-MAC (802.1ah) — Yes Yes Yes Yes No No

CLEAR-Flow Yes Yes Yes Yes Yes Yes

(c series)

Yes

(c series)

sFlow® — Yes Yes Yes Yes Yes Yes

EAPS Yes Yes Yes Yes Yes Yes Yes

Advanced Spanning Tree

(802.1w, 802.1s, PVST+) Yes Yes Yes Yes Yes Yes Yes

Link Aggregation Yes Yes Yes Yes Yes Yes Yes

Switch Management

Capabilities

SNMP, XML,

Web, CLI,

4 RMON

groups

SNMP, XML,

Web, CLI,

4 RMON

groups

SNMP, XML,

Web, CLI,

4 RMON

groups

SNMP, XML,

Web, CLI,

4 RMON

groups

SNMP, XML,

Web, CLI,

4 RMON

groups

SNMP, XML,

Web, CLI,

4 RMON

groups

SNMP, XML,

Web, CLI,

4 RMON

groups

License - Upgrades MPLS,

H-QoS

MPLS

H-QoS

MPLS,

H-QoS — MPLS Core Core

License - Default Core Core Core Core Core Advanced

Edge

Advanced

Edge

Summit

Advanced Series

Summit®Advanced Series switches are designed to provide solutions for data

centers and enterprise aggregation/edge and Carrier Ethernet edge networks,

with their exceptional Quality of Service, low latency, resiliency, line-rate

performance and Power over Ethernet (PoE).

Summit Advanced Series switches offer various critical capabilities, such as

processing packets between core and edge switches, high availability and

control, and simpliﬁed management of your entire network with our ExtremeXOS

operating system. With one operating system from edge to core, these switches

provide high-density gigabit PoE to the desktop and in the data center, including

10/100 Layer 2/Layer 3 intelligent switching for advanced IP/Ethernet services.

Summit Advanced Series switches commonly support stacking with

SummitStack™ technology, Universal Port dynamic port conﬁguration and

Layer 3 IPv4/IPv6 routing to meet the demanding requirements of your network.

Summit X650 Summit X450a

Summit X450e

Summit Advanced Switch Common Features

•Universal Port dynamic port conﬁguration for IP Telephony and security

•40 gigabit full-duplex SummitStack stacking for mix-and-match stacking

•IPv4/IPv6 unicast and multicast routing

Summit X650

The ultimate Top of Rack switch for service virtualization and 10 gigabit aggregation.

• High-density 24-port 10 Gigabit Ethernet with 10GBASE-T or SFP+ support in 1 rack unit with

additional 8-port 10 Gigabit Ethernet option module

•AC or DC dual and hot-swappable power supply

Summit X450a Series

Ideal for Gigabit Ethernet Layer 2/Layer 3 aggregation and small network cores.

•Flexible ﬁber and copper Gigabit Ethernet with optional 10 Gigabit Ethernet

•AC or DC power supply with external redundancy options

Summit X450e Series

Ideal for Gigabit PoE Layer 2/Layer 3 intelligent switching for advanced IP services at the edge.

•Flexible 10/100/1000 PoE with optional 10 Gigabit Ethernet

•AC power supply with external redundancy options

Summit X250e Series

Ideal for 10/100 Layer 2/Layer 3 intelligent switching for advanced IP services at the edge.

•Flexible ﬁber and copper Fast Ethernet connectivity with PoE and gigabit uplinks

•AC or DC power supply with external redundancy options

Summit X250e

Summit X350 Series

Ideal for 10/100/1000 Layer 2 switching for simple enterprise edge solution.

•ExtremeXOS operating system

•ExtremeXOS scripting capability to automate switch conﬁguration

•External redundant AC power supply options

•Flexible 10/100/1000BASE-T standalone switches

Summit X150 Series

Ideal for 10/100 Layer 2 switching for simple enterprise edge solution.

•ExtremeXOS operating system

•ExtremeXOS scripting capability to automate switch conﬁguration

•External redundant AC power supply options

•10/100BASE-TX with and without PoE standalone switches

Summit X350 Summit X150

Summit X250e Summit X450e

Summit X450a Summit X650

Summit X150 Summit X350

10/100 Gigabit 10 Gigabit

Advanced Edge

Aggregation/Data Center

Value Edge

Summit

Value Series

Summit Value Series switches are designed to provide solutions for enterprise

edge applications with the industry-leading modular ExtremeXOS operating

system. Summit Value Series switches offer simplicity and intelligence at an

affordable price for the edge of the network by providing a uniﬁed switch

operating system environment—ExtremeXOS. They are designed for the

simple Gigabit Ethernet- or Fast Ethernet-to-the-desktop applications with

outstanding manageability, resiliency and performance.

With Summit Value Series switches, we can offer an end-to-end synchronized

and consistent operational experience from the core to edge through the

modularity of the ExtremeXOS operating system. The ExtremeXOS operating

system helps to increase network uptime and availability for mission-critical

applications in the enterprise environment to signiﬁcantly reduce the complexity

of managing the network.

To further simplify the operation, Summit Value Series switches commonly

support the CLI scripting capability which automates the deployment of the

network to help reduce the network operating expenditure.

SUMMIT

F E A T U R E S

SUMMIT

X650 X450a X450e X250e X350 X150

Max Auto-Negotiating

10/100BASE-TX

Ports

— — —

24 (SFP

available)

or 48

— 24 or 48

Max Auto-Negotiating

10/100/1000BASE-T

Ports

— 24 or 48 24 or 48 (both

with PoE) 2 24 or 48 2

Max 1 Gigabit

Ethernet Ports (SFP) 4 4 4 2 4 2

Max 10 Gigabit

Ethernet Ports (XFP,

XENPAK, SFP+)

24 (default),

32 (with VIM1-

10G8X)

2 2 — 2 —

Form Factor/

Footprint

Fixed/

1RU

Fixed/

1RU

Fixed/

1RU

Fixed/

1RU

Fixed/

1RU

Fixed/

1RU

Stacking Support Yes,

SummitStack

Yes,

SummitStack

Yes,

SummitStack

Yes,

SummitStack No No

Total Switching

Capacity

488-680

Gbps

128-256

Gbps

128-256

Gbps

48.8-97.6

Gbps

88-176

Gbps

8.8-13.6

Gbps

Redundant Power Yes/

Hot Swappable

Yes/

External

Yes/

External

Yes/

External

Yes/

External

Yes/

External

Power over Ethernet

(802.3af) No No Yes Yes No Summit

X150-24p

Wire-Speed Layer 2/

Layer 3 Switching Yes Yes Yes Yes Yes Yes

Routing - IPv4

BGP4, IS-IS,

OSPF, RIP

v1/v2, PIM,

MSDP

BGP4, IS-IS,

OSPF, RIP

v1/v2, PIM,

MSDP

OSPF, RIP v1/

v2, PIM

OSPF, RIP v1/

v2, PIM No No

Routing - IPv6 RIPng,

OSPFv3, IS-IS

RIPng,

OSPFv3, IS-IS RIPng RIPng No No

Policy-Based

Routing/Switching Yes Yes Yes Yes

Yes/

Policy-Based

Switching

Yes/

Policy-Based

Switching

Policy-Based Quality

of Service (QoS) Yes Yes Yes Yes Yes Yes

Network Login Yes Yes Yes Yes Yes Yes

Access Control Lists Yes Yes Yes Yes Yes Yes

Universal Port Yes Yes Yes Yes No No

CLI Scripting Yes Yes Yes Yes Yes Yes

Widgets Yes Yes Yes Yes Yes Yes

vMANs (802.1ad) Yes Yes Yes Yes Yes Yes

CLEAR-Flow Yes Yes No No No No

sFlow Yes Yes Yes Yes Yes Yes

EAPS Yes Yes Yes Yes Yes Yes

Advanced Spanning

Tree (802.1w,

802.1s, PVST+)

Yes Yes Yes Yes Yes Yes

Link Aggregation Yes Yes Yes Yes Yes Yes

Switch Management

Capabilities

SNMP, XML,

Web, CLI, 4

RMON groups

SNMP, XML,

Web, CLI, 4

RMON groups

SNMP, XML,

Web, CLI, 4

RMON groups

SNMP, XML,

Web, CLI, 4

RMON groups

SNMP, XML,

Web, CLI, 4

RMON groups

SNMP, XML,

Web, CLI, 4

RMON groups

License - Upgrades Core Core Advanced Edge Advanced Edge — —

License - Default Advanced Edge Advanced Edge Edge Edge Layer 2-Edge Layer 2-Edge

Wireless Products

Extreme Networks offers a complete suite of wireless LAN products pro-

viding a highly scalable, secure, and robust wireless solution for the enter-

prise mobile workforce. The solution is designed to be ﬂexible to meet the

needs of small- to medium-sized businesses, large corporate campuses,

and distributed enterprises with many branch ofﬁces. Extreme Networks

wireless solution seamlessly integrates with the wired infrastructure to

enable fast and easy deployment of uniﬁed voice and data services as well

as common security and QoS policies across the entire network.

Summit WM3000 Series

WLAN Controllers

Altitude™ 3500/4600 Series

Access Points

Summit WM3000 Series WLAN Controllers

•Small site to large multi-site deployment

•Comprehensive wired/wireless security features

•Seamless mobility

•Toll-quality voice service

•Scalability and high availability with clustering

Altitude 3500/4600 Series Access Points

•Dual radio/dual band access points

•Plug-n-play deployment

•Indoor and outdoor models for campus-wide mobility

•802.11n performance for high speed wireless access

•Remote site deployment with site survivability

•Mesh networking and bridging for extending wireless service

•Virtual AP services with 16 SSIDs/radio

Wireless Management Suite

•Life cycle management

•Import ﬂoor plans and LAN Planner designs

•Site survey and modeling

•Conﬁguration management

•Multi-site dashboard view

•RF Visualization with heat maps

•Wizard-based diagnostic tools

Wireless Management

Suite

Otros manuales para Summit Summit48si

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de Extreme Networks

Extreme Networks

Extreme Networks ExtremeSwitching ISW Series Manual de usuario

Extreme Networks

Extreme Networks Summit X450a-24tDC Manual

Extreme Networks

Extreme Networks X460-G2 Series Manual de usuario

Extreme Networks

Extreme Networks Summit X150-24t Manual

Extreme Networks

Extreme Networks EAS 100-24t Switch Manual de usuario

Extreme Networks

Extreme Networks Summit 200-24 Manual de usuario

Extreme Networks

Extreme Networks Summit X670-G2-72x Manual de usuario

Extreme Networks

Extreme Networks Summit 300-24 Manual

Extreme Networks

Extreme Networks ExtremeSwitching 3600 Series Manual de usuario

Extreme Networks

Extreme Networks Summit X150 Series Manual

Extreme Networks

Extreme Networks Summit X350-48t Guía de referencia

Extreme Networks

Extreme Networks Summit X250e-24p Manual de usuario

Extreme Networks

Extreme Networks ExtremeAccess Series Manual

Extreme Networks

Extreme Networks X460-G2 Series Manual de instalación y operación

Extreme Networks

Extreme Networks EAS 200-24p Switch Instrucciones de montaje

Extreme Networks

Extreme Networks ExtremeSwitching X435 Series Manual

Extreme Networks

Extreme Networks Summit WM100 Manual de usuario

Extreme Networks

Extreme Networks Alpine 3804 Instrucciones de instalación

Extreme Networks

Extreme Networks ExtremeSwitching Virtual Services Platform 4850GTS... Manual de usuario

Extreme Networks

Extreme Networks ExtremeSwitching VSP 7400 Series Manual

Extreme Networks

Extreme Networks Alpine 3808 Instrucciones de instalación

Extreme Networks

Extreme Networks BlackDiamond 6800 Manual

Extreme Networks

Extreme Networks BlackDiamond 10808 Manual

Extreme Networks

Extreme Networks BlackDiamond X8 Series Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
