Extreme Networks BlackDiamond 6800 Manual

Extreme Networks, Inc.

3585 Monroe Street

Santa Clara, California 95051

(888) 257-3000

http://www.extremenetworks.com

BlackDiamond Switch

Hardware Installation

Guide

Published: December 1999

Part number: 100039-00 Rev. A

Extreme Networks, Inc. in certain jurisdictions. ExtremeWare, ExtremeWare Vista, ExtremeWorks,

ExtremeAssist, ExtremeAssist1, ExtremeAssist2, PartnerAssist, Extreme Standby Router Protocol, ESRP,

BlackDiamond, SmartTraps, Summit, Summit1, Summit4, Summit4/FX, Summit7i, Summit24,

Summit48, Summit Virtual Chassis, SummitLink, SummitGbX, SummitRPS and the Extreme Networks

logo are trademarks of Extreme Networks, Inc., which may be registered or pending registration in

certain jurisdictions. The Extreme Turbodrive logo is a service mark of Extreme Networks, which may

be registered or pending registration in certain jurisdictions. All other registered trademarks,

trademarks and service marks are property of their respective owners. Specifications are subject to

change without notice.

iii

Contents

PREFACE

Introduction ix

Conventions x

Related Publications xi

LACKDIAMOND 6800 SWITCH OVERVIEW

Summary of Features 1-1

Port Connections 1-3

Media Types and Distances 1-4

Full-Duplex 1-5

BlackDiamond 6800 Switch Components 1-5

BlackDiamond 6800 Switch Power Supply 1-7

Power Supply LEDs 1-7

Management Switch Fabric Module 64 (MSM64i) 1-7

MSM64i Behavior 1-8

MSM64i Memory 1-9

MSM64i LEDs 1-11

I/O Module Cards 1-11

G4X, G6X, and G8Xi Modules 1-12

G8SXi and G12SXi Modules 1-14

F32T and F48Ti Modules 1-15

F32F Module 1-16

I/O Module LEDs 1-17

BlackDiamond 6800 Switch Rear View 1-17

BlackDiamond 6800 Switch Fan Tray 1-19

GBIC Types and Hardware/Software Support 1-19

NSTALLATION AND SETUP

Following Safety Information 2-1

Determining the System Location 2-2

Installing the BlackDiamond 6800 Switch 2-2

Powering On the System 2-7

Checking the Installation 2-8

Connecting Equipment to the Console Port 2-8

Logging In for the First Time 2-10

ERVICE AND MAINTENANCE

Following Safety Information 3-1

Removing and Replacing a Module Card 3-2

Removing and Replacing a Power Supply 3-3

Removing and Replacing the Fan Tray 3-4

Adding and Removing SODIMMs 3-5

Adding and Removing GBICs 3-7

AFETY INFORMATION

Important Safety Information A-1

Power A-1

Power Cord A-2

Connections A-3

Lithium Battery A-3

ECHNICAL SPECIFICATIONS

INDEX

Figures

1-1 BlackDiamond 6800 switch 1-6

1-2 Management Switch Fabric Module 64 (MSM64i) 1-8

1-3 MSM64i SODIMM sockets 1-10

1-4 G4X module, G6X module, and G8Xi module 1-13

1-5 G8SXi module and G12SXi module 1-14

1-6 F32T and F48Ti modules 1-15

1-7 F32F module 1-16

1-8 BlackDiamond 6800 switch rear view 1-18

2-1 Rack-mount helper bracket 2-3

2-2 BlackDiamond 6800 chassis mounted in rack 2-4

2-3 Power supply bays 2-5

2-4 MSM64i with extended ejector/injector handles 2-6

2-5 BlackDiamond Power Cable and Plug 2-8

2-6 Null-modem cable pinouts 2-9

2-7 PC-AT serial null-modem cable pinouts 2-10

3-1 BlackDiamond 6800 power supplies 3-3

3-2 Removing the fan tray 3-4

3-3 Adding a SODIMM 3-6

3-4 GBIC connectors 3-7

vii

Tables

1Notice Icons x

2Text Conventions x

1-1 Media Types and Distances 1-4

1-2 1000BASE-LX70 Specifications 1-5

1-3 Power Supply LEDs 1-7

1-4 MSM64i SODIMM Memory Combinations 1-10

1-5 MSM64i LEDs 1-11

1-6 I/O Module LEDs 1-17

2-1 Console Connector Pinouts 2-9

viii

BLACKDIAMOND SWITCH HARDWARE INSTALLATION GUIDE IX

Preface

This Preface provides an overview of this guide, describes guide conventions, and lists

other publications that may be useful.

INTRODUCTION

This guide provides the required information to install the BlackDiamond™6800 switch.

This guide is intended for use by network administrators who are responsible for

installing and setting up network equipment. It assumes a basic working knowledge of

•Local Area Networks (LANs)

•Ethernet concepts

•Ethernet switching and bridging concepts

•Routing concepts

•Simple Network Management Protocol (SNMP)

For information on configuring the BlackDiamond 6800 switch, refer to the ExtremeWare

Software User Guide.

If the information in the “Release Notes” shipped with your switch differs from the

information in this guide, follow the “Release Notes.”

XBLACKDIAMOND SWITCH HARDWARE INSTALLATION GUIDE

PREFACE

CONVENTIONS

Table 1 and Table 2 list conventions used throughout this guide.

Table 1: Notice Icons

Icon Notice Type Alerts you to...

Note Important features or instructions.

Caution Risk of personal injury, system damage,

or loss of data.

Warning Risk of severe personal injury.

Table 2: Text Conventions

Convention Description

Screen displays This typeface represents information as it appears on the screen,

or command syntax.

Screen displays bold This typeface represents commands that you type.

The words “enter”

and “type” When you see the word “enter” in this guide, you must type

something, and then press the Return or Enter key. Do not press

the Return or Enter key when an instruction simply says “type.”

[Key] names Key names appear in text in one of two ways:

■Referred to by their labels, such as “the Return key” or “the

Escape key”

■Written with brackets, such as [Return] or [Esc]

If you must press two or more keys simultaneously, the key

names are linked with a plus sign (+). Example:

Press [Ctrl]+[Alt]+[Del].

Words in

italicized

type Italics emphasize a point or denote new terms at the place where

they are defined in the text.
