Extech Instruments MN10 Manual de usuario

User's Guide

Pocket MultiMeter

Model MN10

www. .com information@itm.com1.800.561.8187

MN10-en-GB_V1.3 09/16

Introduction

Congratulations on your purchase of the Extech MN10 Pocket Multimeter. This meter measures

AC/DC Voltage, DC Current, Resistance, Diode Test, and Battery test. It features a rugged design for

heavy duty use This meter is shipped fully tested and calibrated and, with proper use, will provide

years of reliable service.

Safety

This symbol adjacent to another symbol, terminal or operating device indicates

that the operator must refer to an explanation in the Operating Instructions to

avoid personal injury or damage to the meter.

This WARNING symbol indicates a potentially hazardous situation, which if not

avoided, could result in death or serious injury.

This CAUTION symbol indicates a potentially hazardous situation, which if not

avoided, may result damage to the product.

This symbol advises the user that the terminal(s) so marked must not be

connected to a circuit point at which the voltage with respect to earth ground

exceeds 500 VAC or VDC.

This symbol adjacent to one or more terminals identifies them as being associated

with ranges that may, in normal use, be subjected to particularly hazardous

voltages. For maximum safety, the meter and its test leads should not be handled

when these terminals are energized.

This symbol indicates that a device is protected throughout by double insulation or

reinforced insulation.

WARNING

CAUTION

MAX

500V

www. .com information@itm.com1.800.561.8187

MN10-en-GB_V1.3 09/16

SAFETY INSTRUCTIONS

This meter has been designed for safe use, but must be operated with caution. The rules listed below

must be carefully followed for safe operation.

1. NEVER apply voltage or current to the meter that exceeds the specified maximum:

Input Protection Limits

Function Maximum Input

V DC or V AC 500VDC/AC

mA AC/DC 200mA AC/DC

Resistance, Diode Test 500VDC/AC

2. USE EXTREME CAUTION when working with high voltages.

3. DO NOT measure voltage if the voltage on the "COM" input jack exceeds 500V above earth

ground.

4. NEVER connect the meter leads across a voltage source while the function switch is in the

current, resistance, or diode mode. Doing so can damage the meter.

5. ALWAYS discharge filter capacitors in power supplies and disconnect the power when making

resistance or diode tests.

6. ALWAYS turn off the power and disconnect the test leads before opening the covers to replace

the fuse or batteries.

7. NEVER operate the meter unless the back cover and the battery and fuse covers are in place

and fastened securely.

8. If the equipment is used in a manner not specified by the manufacturer, the protection provided

by the equipment may be impaired.

Controls and Jacks

1. NCV indicator lamp

2. LCD Display

3. Power button

4. Function switch

5. COM jack

6. Data Hold button

7. Battery compartment (rear)

8. Positive jack

Symbols and Annunciators

Diode test ΩOhms

Low Battery V Volts

µ micro A Amps

m milli AC Alternating current

A Amps DC Direct current

k kilo

www. .com information@itm.com1.800.561.8187

MN10-en-GB_V1.3 09/16

Operating Instructions

WARNING: Risk of electrocution. High-voltage circuits, both AC and DC, are very dangerous and

should be measured with great care.

1. ALWAYS switch the meter OFF when the meter is not in use using the power on/off button.

2. If “1” appears in the display during a measurement, the value exceeds the range you have

selected. Change to a higher range.

NOTE: On some low AC and DC voltage ranges, with the test leads not connected to a device, the

display may show a random, changing reading. This is normal and is caused by the high-input

sensitivity. The reading will stabilize and give a proper measurement when connected to a circuit.

NON-CONTACT VOLTAGE (NCV)

The meter can detect the presence of AC voltage (from 100 to 600VAC) simply by being held very

near to a voltage source.

WARNING: Test the AC voltage detector on a known live circuit before each use.

WARNING: Before using the meter in the AC Voltage Detector mode, verify that the battery is fresh

by confirming characters appear on the LCD when the function dial is turned to any position. Do

not attempt to use the meter as an AC Voltage Detector if the battery is weak or bad.

The NCV function works on any rotary switch position.

1. Turn the meter on.

2. The NCV function works with the meter’s function switch set to any position.

3. Be sure to test the NCV function on a known live circuit before use.

4. Hold the top of the meter very close to the voltage source.

5. If voltage is present, the red LED indicator directly above the meter’s LCD display

will solidly illuminate.

DC VOLTAGE MEASUREMENTS

CAUTION: Do not measure DC voltages if a motor on the circuit is being switched ON/OFF.

Large voltage surges may occur that can damage meter.

1. Set the function switch to the highest V DC position.

2. Insert the black test lead banana plug into the negative (COM) jack.

Insert the red test lead banana plug into the positive (V) jack.

3. Touch the black test probe tip to the negative side of the circuit.

Touch the red test probe tip to the positive side of the circuit.

4. Read the voltage in the display. Reset the function switch to successively lower V

DC positions to obtain a higher resolution reading. The display will indicate the

proper decimal point and value. If the polarity is reversed, the display will show (-)

minus before the value.

www. .com information@itm.com1.800.561.8187

MN10-en-GB_V1.3 09/16

AC VOLTAGE MEASUREMENTS

WARNING: Risk of Electrocution. The probe tips may not be long enough to contact the live parts

inside some 240V outlets for appliances because the contacts are recessed deep in the outlets. As

a result, the reading may show 0 volts when the outlet actually has voltage on it. Make sure the

probe tips are touching the metal contacts inside the outlet before assuming that no voltage is

present.

CAUTION: Do not measure AC voltages if a motor on the circuit is being switched ON or OFF.

Large voltage surges may occur that can damage the meter.

1. Set the function switch to the highest V AC position.

2. Insert the black test lead banana plug into the negative (COM) jack.

Insert red test lead banana plug into the positive (V) jack.

3. Touch the black test probe tip to the negative side of the circuit.

Touch the red test probe tip to the positive side of the circuit.

4. Read the voltage in the display. Reset the function switch to successively lower V

AC positions to obtain a higher resolution reading. The display will indicate the

proper decimal point and value.

DC CURRENT MEASUREMENTS

1. Insert the black test lead banana plug into the negative (COM) jack.

2. Set the function switch to the 200mA or 2000A DC range position.

3. Insert the red test lead banana plug into the mA jack.

4. Remove power from the circuit under test, then open up the circuit at the point

where you wish to measure current.

5. Touch the black test probe tip to the negative side of the circuit.

Touch the red test probe tip to the positive side of the circuit.

6. Apply power to the circuit.

7. Read the current in the display. The display will indicate the proper decimal point

and value.

RESISTANCE MEASUREMENTS

WARNING: To avoid electric shock, disconnect power to the unit under test and discharge all

capacitors before taking any resistance measurements. Remove the batteries and unplug the line

cords.

1. Set the function switch to the highest Ωposition.

2. Insert the black test lead banana plug into the negative (COM) jack

Insert the red test lead banana plug into the positive  jack.

3. Touch the test probe tips across the circuit or part under test. It is best to

disconnect one side of the part under test so the rest of the circuit will not

interfere with the resistance reading.

4. Read the resistance in the display and then set the function switch to the lowest

Ωposition that is greater than the actual or any anticipated resistance. The

display will indicate the proper decimal point and value.

www. .com information@itm.com1.800.561.8187

MN10-en-GB_V1.3 09/16

DIODE CHECK

1. Set the function switch to the position

2. Insert the black lead banana plug into the negative (COM) jack

Insert the red test lead banana plug into the positive () jack.

3. Connect the red test lead to the anode of the diode and the black lead to the

cathode.

4. The forward voltage drop in mV will be displayed. If the leads are reversed, the

display will indicate “I”.

BATTERY TEST

1. Insert the black test lead banana plug into the negative COM jack and the red test lead banana

plug into the positive V jack.

2. Select the 9V BAT position using the function switch.

3. Connect the red test lead to the positive side of the 9V battery and the black test lead to the

negative side of the 9V battery.

4. Read the voltage in the display (> 8.2V indicates good; < 7.2 indicates a bad; 7.2V to 8.2V

indicates a weak)

www. .com information@itm.com1.800.561.8187

MN10-en-GB_V1.3 09/16

Maintenance

This MultiMeter is designed to provide years of dependable service, if the following care instructions

are performed:

1. KEEP THE METER DRY. If it gets wet, wipe it off.

1. USE AND STORE THE METER IN NORMAL TEMPERATURES. Temperature extremes can

shorten the life of the electronic parts and distort or melt plastic parts.

2. HANDLE THE METER GENTLY AND CAREFULLY. Dropping it can damage the electronic parts

or the case.

3. KEEP THE METER CLEAN. Wipe the case occasionally with a damp cloth. DO NOT use

chemicals, cleaning solvents, or detergents.

4. USE ONLY FRESH BATTERIES OF THE RECOMMENDED SIZE AND TYPE. Remove old or

weak batteries so they do not leak and damage the unit.

5. IF THE METER IS TO BE STORED FOR A LONG PERIOD OF TIME, the batteries should be

removed to prevent damage to the unit.

BATTERY REPLACEMENT

WARNING: To avoid electric shock, disconnect the test leads from any source of voltage before

removing the back cover or the battery cover.

1. Disconnect the test leads from the meter.

2. Remove the Phillips head screw located on the back of the instrument and remove the battery

cover.

3. Replace the 12V battery.

4. Secure the fuse/battery compartment cover.

5. Dispose of the old battery as required by local regulations.

The end user is legally bound (EU Battery ordinance) to return all used batteries, disposal

in the household garbage is prohibited! Bring used batteries / accumulators to collection

points in your community or wherever batteries / accumulators are sold!

Disposal: Follow the valid legal stipulations in respect of the disposal of the device at the

end of its lifecycle

WARNING: To avoid electric shock, do not operate your meter until the battery cover is in place and

fastened securely.

FUSE REPLACEMENT

1. Disconnect the test leads from the meter.

2. Remove the 3 Phillips head screws securing the meter’s rear cover and lift the cover off.

3. Gently remove the fuse and install the new fuse into the holder.

4. Always use fuses of the proper size and value 0.2A/250V fast blow

5. Secure the rear cover.

WARNING: To avoid electric shock, do not operate your meter until the rear cover is in place and

fastened securely.

www. .com information@itm.com1.800.561.8187

MN10-en-GB_V1.3 09/16

Specifications

Function Range Resolution Accuracy (reading)

DC Voltage

(V DC)

200mV 0.1mV

(0.5% rdg + 2d)

2000mV 1mV

20V 0.01V

200V 0.1V

500V 1V

AC Voltage

(V AC) (50/60Hz)

200V 0.1V



(1.2% rdg + 10d

500V 1V

DC Current

(A DC)

2000



A 1





(1.2% rdg + 2d)

200mA 100





(1.5% rdg + 2d)

Resistance 200



0.1



(0.8% rdg + 4d)

2000



20k



0.01k



200k



0.1k



2000k





(1.5% rdg + 2d)

Battery Test 9V 10mV



(1.2% rdg + 2d)

www. .com information@itm.com1.800.561.8187

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Multímetro de Extech Instruments

Extech Instruments

Extech Instruments MP510A Manual de usuario

Extech Instruments

Extech Instruments 411 Manual de usuario

Extech Instruments

Extech Instruments 382860 Manual de usuario

Extech Instruments

Extech Instruments EX710 Manual de usuario

Extech Instruments

Extech Instruments DM220 Manual de usuario

Extech Instruments

Extech Instruments MG300 Manual de usuario

Extech Instruments

Extech Instruments 38390 Manual de usuario

Extech Instruments

Extech Instruments AUT500 Manual de usuario

Extech Instruments

Extech Instruments MiniTec Series Manual de usuario

Extech Instruments

Extech Instruments MiniAmp Series Manual de usuario

Extech Instruments

Extech Instruments EX623 Manual de usuario

Extech Instruments

Extech Instruments Extech 470 Manual de usuario

Extech Instruments

Extech Instruments SDL900 Manual de usuario

Extech Instruments

Extech Instruments EX210 Manual de usuario

Extech Instruments

Extech Instruments EX810 Manual de usuario

Extech Instruments

Extech Instruments MN15A Manual de usuario

Extech Instruments

Extech Instruments EX420A Manual de usuario

Extech Instruments

Extech Instruments 38387 Manual de usuario

Extech Instruments

Extech Instruments SD750 Manual de usuario

Extech Instruments

Extech Instruments MM750W Manual de usuario

Extech Instruments

Extech Instruments EX411A Manual de usuario

Extech Instruments

Extech Instruments 401025 Manual de usuario

Extech Instruments

Extech Instruments CMM-17 Manual de usuario

Extech Instruments

Extech Instruments MiniTec Series Manual de usuario

Manuales populares de Multímetro de otras marcas

Agilent Technologies

Agilent Technologies 34420A Manual de usuario

Fluke

Fluke 83 Manual de usuario

Hameg

Hameg HM 8012 Manual de usuario

Mastech

Mastech MY70 Manual de usuario

Steren

Steren MUL-300 Manual de usuario

Somogyi Elektronic

Somogyi Elektronic home SMA 92 Manual de usuario

Gossen MetraWatt

Gossen MetraWatt METRAmax 6 Manual de usuario

PeakTech

PeakTech 4000 Manual de uso y cuidado

YOKOGAWA

YOKOGAWA 90050B Manual de usuario

Gossen MetraWatt

Gossen MetraWatt METRALINE DMM16 Manual de usuario

Fluke

Fluke 8846A Manual de operación y mantenimiento

Tempo Communications

Tempo Communications MM200 Manual de usuario

Elenco Electronics

Elenco Electronics CM-1555 Manual de usuario

Mastech

Mastech MS8238C Manual de usuario

SDAR

SDAR 830A, 830B, 830D, 830C Manual de usuario

RS PRO

RS PRO RS-9519BT Manual de usuario

BGS technic

BGS technic 8890 Manual de usuario

Amprobe

Amprobe Hexagon 60 Manual de usuario
