User's Guide

Heavy Duty Hot Wire CFM Thermo-Anemometer

Model 407119A

407119A-EN v5.3 3/14

Introduction

Congratulations on your purchase of the Extech 407119A Thermo-Anemometer. The 407119A

measures air velocity, air volume, and air temperature. It uses a telescoping probe antenna to

allow convenient access to grills and diffusers. Careful use of this meter will provide years of

reliable service. The Model 407119A features are listed below.

Features

Combination hot wire probe (for air velocity) and thermistor sensor (for temperature) deliver

rapid and precise measurements even at low air velocity values.

Slim probe design with telescoping antenna for easy grill and diffuser access

Air Velocity, Air Volume, and Air Temperature measurements

20 Reading Average feature

Zero adjustment

Data Hold and Record/Recall Max/Min features

Auto Power OFF

PC Interface (RS-232) with optional software and cable for data acquisition

Applications

Environmental testing, air conveyors, flow hoods, clean rooms, air balancing,

fans/motors/blowers, furnace velocity, paint spray booths, and others.

407119A-EN v5.3 3/14

Specifications

General Specifications

Display Dual function 5-digit LCD

Measurement units Air Velocity: m/s, km/h, ft/min, knots, mph;

Air Flow: CMM (m3/min) and CFM (ft3/min);Temperature: °C and °F

Data hold Freezes displayed reading

Sampling rate Display update rate:1 second (approx.)

Sensors Air velocity and temperature sensors: Thermistor type

MAX/MIN Memory Record and view Maximum and Minimum readings

Average feature Averages up to 20 readings

Automatic Power off Auto shut off after 15 minutes

Data Output RS-232 PC serial interface with 16-bit data stream output

Operating Temp. 32 to 122°F (0 to 50°C)

Operating Humidity Max. 80% Relative Humidity

Power Supply Four (4) ‘AA’ 1.5V batteries or optional AC adaptor

Power Current 70mA DC (approx.)

Weight (meter only) 1.15 lbs. (521g) with batteries installed

Dimensions Main instrument: 7.9 x 3.0 x 1.5" (200.0 x 76.2 x 36.8mm)

Telescoping Sensor: 0.5" (12.7mm) diameter head

Min length of sensor: 8” (260mm); Max. length: 37” (0.94m) with 5.5’

(1.7m) cable

Range Specifications

Air Velocity Range Resolution Accuracy (of rdg)

m/s (meters per second) 0.2 – 17.0 m/s 0.1 ±(5% + 5 digits)

km/h (kilometers per hour) 0.7 – 61.2 km/h 0.1 ±(5% + 20 digits)

ft/min (feet per minute) 40 – 3346 ft/min 1 ±(5% + 100 digits)

mph (miles per hour) 0.5 – 38.0 mph 0.1 ±(5% + 10 digits)

knots (nautical miles per hour) 0.4 to 33.0 knots 0.1 ±(5% + 10 digits)

Air Flow Measurements Range Resolution Area Range

CMM (cubic meters per min.) 0 – 36,000 m3/min 0.001 to 1 0.001 to 30.0 m2

CFM (cubic feet per minute) 0 – 1,271,200 ft3/min 0.01 to 100 0.01 to 322.91ft2

Air Temperature Range Resolution Accuracy

32 to 122oF

(0 to 50oC) 0.1oF/C ±1.5oF (0.8oC)

407119A-EN v5.3 3/14

Meter Description

1. Display

2. POWER button

3. HOLD and ESC button

4. REC and ENTER button

5. UNIT, ZERO, and ▲up arrow button

6. Function and ▼down arrow button

7. AVG. and ►right arrow button

8. AREA SETUP button

9. Tilt stand

10. Battery compartment / Cover

11. Tripod mount

12. LCD contrast adjustment pot

13. System reset switch

14. RS-232 Output terminal

15. DC9V power adaptor

15 14 13 12

407119A-EN v5.3 3/14

Operation

Initialization and Zero procedures (please follow these steps before use)

Important Note: The meter’s probe locking switch must be in the

locked position (with the probe inserted) for the meter to turn on

and operate correctly. Refer to the accompanying diagram or the

diagram at the top of the meter for switch orientation.

For the best accuracy and for proper operation, the following

steps must be performed.

1. Connect the sensor to the input jack on top of the meter by

first unlocking the sensor jack and then inserting the sensor

plug. Lock the sensor jack after the probe is inserted.

2. Press the POWER button to turn on the meter. The meter will

perform a self-test during which the display will count down

from 9999 to 0000.

3. Select the air velocity function using the FUNCTION button. The LCD will display the most

recently selected unit of measure for air velocity.

4. To change the temperature units of measure (C/F), use the advanced programming mode

discussed later in this manual.

5. Momentary presses of the UNIT button changes the air velocity units. The LCD will reflect the

selection.

6. Place the sensor cover in the up (ZERO) position (see diagram below).

7. Open the telescoping sensing antenna to a convenient length.

8. Place the sensor in the area to be measured and allow a short time for it to stabilize to the

ambient temperature.

9. To Zero the meter display, press and hold the ZERO button until the second beep.

Warning! Do not touch the air velocity or temperature thermistors inside the sensor head while

moving the sensor cover.

TOP VIEW OF METER

LOCKED Position

UNLOCKED Position

407119A-EN v5.3 3/14

Air Velocity Measurements

1. Follow the Initialization and Zeroing procedures above before continuing.

2. Open the antenna to the desired length.

3. Slide the air velocity sensor cover down.

4. Press the POWER button to turn the meter on.

5. Place the sensor in the air

current to be measured.

Have the air flow meet the

sensor head in the

direction of the white dot

(as shown in diagram).

6. View the air velocity and temperature readings on the LCD Display. The large main LCD display

shows the Air Velocity reading. The lower LCD sub-display shows the temperature reading (left)

and the unit of measure (right).

7. To turn the meter off, press and hold the POWER button until the meter switches off.

Air Flow (Volume) Measurements (CMM / CFM)

NOTE: Temperature is not displayed while the meter is in the Air Flow mode.

1. Follow the steps in the Initialization and Zeroing section before continuing.

2. Select the air flow mode using the Function button. The LCD will display CMM (cubic meters per

minute) or CFM (cubic feet per minute) when Air Flow is selected.

3. Press the UNIT button momentarily to select the desired air flow units: CMM or CFM. The LCD

display will reflect the selection.

4. Calculate the area of the duct or vent under test (refer to the Useful Conversions and Equations

section in the back of this manual for assistance). Be sure to compute the area of the vent or

duct in square feet or meters. If you have the area in inches, convert inches to feet before

programming the meter with the area value.

5. Press the AREA SET button to begin entering the area in m2or ft2. The left digit will begin

flashing. Follow the steps below to enter the area of the duct or vent in question:

Use the ►button to select a digit to change (digit will flash)

Use the ▲button increase the value of the flashing digit

Use the ▼button to decrease the value of the flashing digit

6. Press the REC/Enter button and then the AREA SET button to save the new area value

7. After the area has been entered, the new area value will be shown on the lower left of the LCD

display in ft2or m2. If the unit of measure is CFM, the area will be shown in square feet. If the

unit of measure is CMM, the area will be shown in meters squared.

8. Press the ESC button to abort the programming at any time.

9. Place the probe in the area under test. The main LCD digits will indicate the air flow in CFM or

CMM. If the CFM or CMM reading exceeds 99999, use the displayed X10 multiplier to calculate

the reading.

10. To turn the meter off, press and hold the POWER button until the meter switches off.

407119A-EN v5.3 3/14

AVERAGE Feature for the Air Flow Mode

In the Average mode, up to 20 readings can be stored and averaged.

1. In the Air Flow Mode (discussed earlier), press the FUNCTION button momentarily until the

AVG icon and a ‘zero’ appears on the lower LCD display line.

2. Press the AVG START button to record the current reading. A ‘1’ will appear on the lower LCD

line indicating that one reading has been stored.

3. Press the AVG START for up to a total of 20 measurements. The number on the lower LCD line

will increment with each press of the AVG START button letting the user know how many

readings are currently being averaged. Note that only the averaged reading is shown while in

this mode, not the actual reading.

4. To clear (erase) all of the currently stored readings and start again, press and hold the AVG

button until the meter beeps twice. Note that the counter resets to ‘0’ and that the meter is ready

to start another averaging session.

5. Use the FUNCTION button to exit this mode of operation.

Data Hold Feature

1. While taking measurements, press the HOLD button to freeze a reading.

2. The HOLD indicator will appear on the LCD when the display is in Data Hold mode.

3. Press HOLD again to return to normal operation.

Maximum (MAX) and Minimum (MIN) Recording

The MAX / MIN Record-Recall feature allows the user to record and view the highest and lowest

readings during a measurement session.

1. Press the REC button once. The REC indicator will appear on the display and the meter will

begin keeping track of the MAX and MIN values.

2. To view the MAX reading, press REC again. The MAX indicator along with the maximum

reading will appear on the LCD display.

3. Press REC again to view the minimum value, the MIN indicator along with the minimum reading

will appear on the LCD display.

4. To return to normal operation, press and hold the REC button for approx. 3 seconds (until the

meter beeps). The display indicators REC, MAX, and MIN will disappear.

Note: Auto Power Off is disabled in the RECORD mode.

Auto Power Off

To save battery life, the meter will automatically shut off after approximately 15 minutes of

operation. To temporarily disable this feature (until the meter’s power is cycled), press the REC

button and enter the RECORD mode. Alternatively, go to the advanced programming section (later

in this manual) for instructions on how to disable it long term.

407119A-EN v5.3 3/14

Advance Programming Mode

From the Air Velocity mode of operation, press and hold the SET button until the meter beeps and a

‘1’ is displayed. The advanced programming mode is now accessed. The Auto Power OFF

Enable/Disable and the Temperature Units selections are available in the advanced programming

mode. Use the ESC button to exit this mode at any time.

Auto Power Enable/Disable

The first parameter in the advanced mode is the Auto Power OFF enable/disable. Use the up and

down arrow keys to select the desired value. ‘0’ defeats the Auto Power OFF feature; ‘1’ enables the

Auto Power OFF feature. Momentarily press the SET button to move to the next parameter

temperature units (see below).

Temperature Units selection (C/F)

The second parameter in the advanced mode is the Temperature Units selection. Use the up and

down arrow keys to select the desired value. ‘0’ selects degrees ‘C’; ‘1’ selects degrees ‘F’. Press

the Rec/Enter button to confirm temperature selection. Press the ESC button to exit the advanced

programming mode.

System Reset

If the meter’s display ‘locks up’ and/or the button presses do not cause the display to change, try a

system reset. To reset the meter, use one of the following methods.

1. Move the probe lock switch from the ON to the OFF to the ON position again. Turn the meter on.

2. While powering the meter, press the RESET switch (side compartment) using the point of a

paper clip.

PC Interface

The 407119A is equipped with a 3.5mm jack (side compartment) for connection to a PC for data

acquisition purposes. The meter’s data output is a 16 bit data stream. For streaming of data to a PC

via the RS232 Output jack, the optional 407001-USB kit (RS232 to USB cable and driver CD) along

with the 407001 software (available free at www.extech.com) are required.

Battery Replacement

When the battery icon appears on the lower left corner of the LCD display, the four (4) ‘AA’ batteries

must be replaced.

1. Remove the rear Phillips head screw

2. Slide off the rear battery compartment

3. Replace the batteries

4. Secure the battery compartment

407119A-EN v5.3 3/14

Useful Equations and Conversions

Area equation for rectangular or square ducts

Area equation for circular ducts

Cubic equations

NOTE: Measurements made in inches

must be converted to feet or meters before using the above formulae.

Unit of Measure Conversion Table

m/s ft/min knots km/h MPH

1 m/s 1196.87 1.944 3.6 2.24

1 ft/min 0.00508 10.00987 0.01829 0.01138

1 knot 0.5144 101.27 11.8519 1.1523

1 km/h 0.2778 54.69 0.54 10.6222

1 MPH 0.4464 87.89 0.8679 1.6071 1

Width (W)

Height (H)

Area (A) = Width (W) x Height (H)

CFM (ft3/min) = Air Velocity (ft/min) x Area (ft2)

CMM (m3/min) = Air Velocity (m/sec) x Area (m2) x 60

Radius Area (A) = pi x r2

Where pi= 3.14 and r2= radius x radius

407119A-EN v5.3 3/14

Warranty

FLIRSystems,Inc.warrantsthisExtechInstrumentsbranddevicetobefreeofdefectsinpartsandworkmanshipforoneyear

fromdateofshipment(asixmonthlimitedwarrantyappliestosensorsandcables).Ifitshouldbecomenecessarytoreturnthe

instrumentforserviceduringorbeyondthewarrantyperiod,contacttheCustomerServiceDepartmentforauthorization.Visit

thewebsitewww.extech.comforcontactinformation.AReturnAuthorization(RA)numbermustbeissuedbeforeanyproductis

returned.Thesenderisresponsibleforshippingcharges,freight,insuranceandproperpackagingtopreventdamageintransit.

Thiswarrantydoesnotapplytodefectsresultingfromactionoftheusersuchasmisuse,improperwiring,operationoutsideof

specification,impropermaintenanceorrepair,orunauthorizedmodification.FLIRSystems,Inc.specificallydisclaimsanyimplied

warrantiesormerchantabilityorfitnessforaspecificpurposeandwillnotbeliableforanydirect,indirect,incidentalor

consequentialdamages.FLIR’stotalliabilityislimitedtorepairorreplacementoftheproduct.Thewarrantysetforthaboveis

inclusiveandnootherwarranty,whetherwrittenororal,isexpressedorimplied.

Calibration,Repair,andCustomerCareServices

FLIRSystems,Inc.offersrepairandcalibrationservicesfortheExtechInstrumentsproductswe

sell.NISTcertificationformostproductsisalsoprovided.CalltheCustomerServiceDepartmentfor

informationoncalibrationservicesavailableforthisproduct.Annualcalibrationsshouldbe

performedtoverifymeterperformanceandaccuracy.Technicalsupportandgeneralcustomer

serviceisalsoprovided,refertothecontactinformationprovidedbelow.

Allrightsreservedincludingtherightofreproductioninwholeorinpartinanyform

www.extech.com

SupportLines:U.S.(877)439‐8324;International:+1(603)324‐7800

TechnicalSupport:Option3;E‐mail:[email protected]

Repair&Returns:Option4;E‐mail:[email protected]

Productspecificationsaresubjecttochangewithoutnotice

Pleasevisitourwebsiteforthemostup‐to‐dateinformation

www.extech.com

FLIRCommercialSystems,Inc.,9TownsendWest,Nashua,NH03063USA

Otros manuales para 407119A

Tabla de contenidos

Otros manuales de Multímetro de Extech Instruments

Extech Instruments

Extech Instruments MA400 Manual de usuario

Extech Instruments

Extech Instruments EX205T Manual de usuario

Extech Instruments

Extech Instruments 38390 Manual de usuario

Extech Instruments

Extech Instruments 380224 Manual de usuario

Extech Instruments

Extech Instruments 380947 Manual de usuario

Extech Instruments

Extech Instruments Extech 470 Manual de usuario

Extech Instruments

Extech Instruments EX410A Manual de usuario

Extech Instruments

Extech Instruments MiniTec Series Manual de usuario

Extech Instruments

Extech Instruments PQ3470 Manual de usuario

Extech Instruments

Extech Instruments LT40 Manual de usuario

Extech Instruments

Extech Instruments DM220 Manual de usuario

Extech Instruments

Extech Instruments Extech 470 Manual de usuario

Extech Instruments

Extech Instruments 407303 Manual de usuario

Extech Instruments

Extech Instruments SDL350 Manual de usuario

Extech Instruments

Extech Instruments EX310 Manual de usuario

Extech Instruments

Extech Instruments 382860 Manual de usuario

Extech Instruments

Extech Instruments EX411A Manual de usuario

Extech Instruments

Extech Instruments MultiLog ML720 Manual de usuario

Extech Instruments

Extech Instruments EX542 Manual de usuario

Extech Instruments

Extech Instruments MultiMaster MM560A Manual de usuario

Extech Instruments

Extech Instruments MN62-K Manual de usuario

Extech Instruments

Extech Instruments 381676 Manual de usuario

Extech Instruments

Extech Instruments EX320 Manual de usuario

Extech Instruments

Extech Instruments Extech 470 Manual de usuario

Manuales populares de Multímetro de otras marcas

Agilent Technologies

Agilent Technologies 34420A Manual de usuario

Fluke

Fluke 83 Manual de usuario

Hameg

Hameg HM 8012 Manual de usuario

Mastech

Mastech MY70 Manual de usuario

Steren

Steren MUL-300 Manual de usuario

Somogyi Elektronic

Somogyi Elektronic home SMA 92 Manual de usuario

Gossen MetraWatt

Gossen MetraWatt METRAmax 6 Manual de usuario

PeakTech

PeakTech 4000 Manual de uso y cuidado

YOKOGAWA

YOKOGAWA 90050B Manual de usuario

Gossen MetraWatt

Gossen MetraWatt METRALINE DMM16 Manual de usuario

Fluke

Fluke 8846A Manual de operación y mantenimiento

Tempo Communications

Tempo Communications MM200 Manual de usuario

Elenco Electronics

Elenco Electronics CM-1555 Manual de usuario

Mastech

Mastech MS8238C Manual de usuario

SDAR

SDAR 830A, 830B, 830D, 830C Manual de usuario

RS PRO

RS PRO RS-9519BT Manual de usuario

BGS technic

BGS technic 8890 Manual de usuario

Amprobe

Amprobe Hexagon 60 Manual de usuario
