EXP8039 User’s Manual
CHAPTER 1
INTRODUCTION
1.1 OVERVIEW
The
EXP8039
is complemented by a 256KB second level Write-
Back cache providing workstation level computing performance
and SIMM sockets support up to 32MB of DRAM.
The
EXP8039
motherboard offers outstanding I/O capabilities.
Three PCI Local Bus slots provide a high bandwidth data path for
data-movement intensive function such as Graphics. Four ISA
slots complete the I/O mix.
The
EXP8039
motherboard provides the foundation for cost
effective high performance highly expandable platforms which
deliver the latest in CPU and I/O technologies.
1.2 SYSTEM FEATURES
qTi Processor only
qSupports 4 System States for Power Saving :
ON/DOZE/STANDBY/SUPEND
qSupports L2 Write Back/Write Through Cache Feature
qSupports 3 MASTER PCI Bus
qSupports 128KB/256KB Cache Size
qSupports 72pin SIM MODULES
qEnhanced PCI IDE on Board
qSupports 2S1P Floppy on Board
qBIOS has been Hardware Integrated with Enhanced IDE
Driver for Best Hard Disk Performance
