EXP Computer CD421 Manual de usuario

PCMCIA

Portable CD-ROM

Installation Manual

CD-421

EXP COMPUTER, INC.

EXP MEMORY PRODUCTS.

NON-TRANSFERABLE LIMITED WARRANTY

EXP COMPUTER INC., AND EXP MEMORY PRODUCTS("EXP")

warrants that the Quadruple Speed Portable CD-ROM(“products”)

manufactured or distributed by EXP to be free from failures due to

defects in materials or workmanship for full one year from the date of

purchase of the products.

This warranty is void if the product is damaged by abnormal or improper

use or by accident, abuse or if any attempt to repair or modify the

product without authorization from EXP. Your sales receipt or invoice,

showing the date of purchase and the name of the authorized reseller, is

your proof of the date of purchase. During the warranty period, EXP will

at its option, replace or repair, at no charge, the product which in its

opinion is defective.

Before you return the failed products, contact EXP. You must obtain a

Return Merchandise Authorization (RMA) number by calling EXP

Computer Inc. At (516) 496-7629. The RMA number should be displayed

on the outside of the returned package and on the accompanying

packing list. EXP cannot be held responsible for any package returned

without the RMA number. You are responsible for packaging, providing

proof of the date of purchase and the shipping cost of the failed product

to EXP Computer, Inc. You are responsible for mailing the warranty

registration card. The warranty claims may not be honored if there is no

corresponding registration card on file at EXP.

IN NO EVENT WILL EXP BE LIABLE FOR ANY DIRECT, INDIRECT,

SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGE, INCLUDING

LOSS OF PROFIT, LOSS OF SAVINGS; OR ANY OTHER DAMAGES

CAUSED BY PRODUCT OR FAILURE OF THE PRODUCT TO

PERFORM.

THIS LIMITATION OF LIABILITY APPLIES EVEN IF EXP HAS BEEN

ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. SOME

SATES DO NOT ALLOW THE EXCLUSION OR LIMITATION IN

INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE

EXCLUSION OR LIMITATION MAY NOT APPLY TO YOU.

FCC COMPLIANCE STATEMENTS

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the Distance between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

CHANGE OR MODIFICATIONS NOT EXPRESSLY APPROVED BY

PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE

USER’S AUTHORITY TO OPERATE THE EQUIPMENT.

CAUTION

TRADEMARKS

SystemSoft is a registered trademark of SystemSoft Corporation.

CardSoft is a trademark of SystemSoft Corporation.

Phoenix is a registered trademark of Phoenix Technologies, Ltd.

Databook is a registered trademark of Databook Inc.

Cardtalk is a trademark of Databook Inc.

PCMCIA is a trademark of Personal Computer Memory Card

International Association.

MS-DOS, Windows, Windows 95, and MSCDEX are trademarks of

Microsoft Corporation.

OS/2 WARP is a trademark of International Business Machines

Corporation.

Photo CD is a trademark of Kodak.

CONTENTS

INTRODUCTION............................................................................... 1

SYSTEM REQUIREMENTS........................................................ 1

FEATURES ............................................................................... 1

PART NAMES AND FUNCTIONS ..................................................... 2

FRONT PANEL OF THE CD-ROM DRIVE.................................. 2

REAR PANEL OF THE CD-ROM DRIVE..................................... 3

POWER SOURCE ............................................................................ 4

CONNECT THE AC ADAPTER................................................... 4

INSTALLING THE BATTERIES................................................... 5

REMOVING THE BATTERIES.................................................... 6

NOTICE ............................................................................... 6

HARDWARE INSTALLATION ........................................................... 7

SOFTWARE INSTALLATION ........................................................... 8

SOFTWARE INSTALLATION FOR DOS/WINDOWS ................. 8

AUTOMATIC INSTALLATION............................................ 8

MANUAL INSTALLATION.................................................. 9

SOFTWARE INSTALLATION FOR WINDOWS 95..................... 11

USING CD-421 UNDER WINDOWS 95............................. 11

USING CD-421 TO INSTALL WINDOWS 95..................... 12

ENABLING 32-BIT CARD SUPPORT OF WINDOWS 95 .. 13

SOFTWARE INSTALLATION FOR OS/2 WARP ........................ 15

AUTOMATIC INSTALLATION ........................................... 15

MANUAL INSTALLATION.................................................. 16

ADDING PCMCIA SUPPORT............................................ 17

USING CD-421 TO INSTALL OS/2 WARP ........................ 19

TROUBLE SHOOTING...................................................................... 20

BASIC OPERATING PROCEDURES................................................ 22

PCMCIA(PC Card) SOFTWARE INFORMATION.............................. 23

POWER SAVING.............................................................................. 27

- -

INTRODUCTION

The CD-421 brings the latest in mobile computing technology to

notebook computer users with portability and convenience. The CD-421

is a 4X(quad-speed) CD-ROM drive compliant with the PCMCIA 2.1(PC

Card) standard. Featuring flexible power options, the CD-421 may

operate on either AC power or batteries. The CD-421 is designed for

both business and entertainment solutions.

SYSTEM REQUIREMENTS

1. Notebook or desktop computer with a PCMCIA 2.1 Type I, II or III

slot.

2. MS-DOS Version 6.0 or higher with MSCDEX.EXE (for

DOS/Windows users only) or Windows 95 or OS/2.

FEATURES

§ Complies with PCMCIA 2.1

Standard

§ MSCDEX compatible

§ Easy-to-install device driver

software

§ Ultra slim PCMCIA Card

85.6 x 54.0 x 3.3 mm (Type I)

§ CD-ROM Drive

Size: 164 x 250 x 50mm

Weight ≤1.35 Kg

§ PCMCIA power consumption:

+5V/300 mA (Standby),

+5V/500 mA (max.)

§ Power source: AC adapter or

batteries (1.5V AA size x 8)

§ Battery life ≥3 hours. (CD-ROM

continuous video play)

§ Windows 95 Ready

§ OS/2 Warp Ready

§ Quad-speed data transfer rate:

600 Kbytes/sec

§ Average access time: 235 ms

(1/3 stroke)

§ 128 Kbytes Memory Buffer

§ Data capacity: 553MB (Mode 1)

635 MB (Mode 2)

§ Motorized front tray loading

§ Supports CD-Audio, CD-XA,

CD-ROM mode 1 and 2,

Multi-session Photo CD

§ Audio function: Headphone

output jack with volume control,

Audio line-in jack

- -

PART NAMES AND FUNCTIONS

FRONT PANEL OF THE CD-ROM DRIVE

•• Disc Tray:

This disc tray is used to insert the compact disc.

‚‚ Load/Stop button:

• Press this button to load the disc tray.

• When playing an Audio CD, pressing this button will put it into the

stop state.

ƒƒ Power Indicator:

• This indicator will light with a green LED when the power is on.

• This LED will blink when battery power is low.

„„ Play/Skip: (for CD Audio operation only)

• If the drive is in the stop state, pressing this button will activate the

drive to start playing.

• If the drive is in play state, pressing this button will skip to the next

track.

…… Headphone Volume Control Knob:

This rotary knob is used to adjust the volume of the headphone jack.

†† Power On/Busy LED:

This LED will light with a green LED when power is on.

This LED will blink when the drive is accessing the disc.

‡‡ Headphone Jack:

3.5mm audio headphone jack.

- -

REAR PANEL OF THE CD-ROM DRIVE

•• Interface Connector:

This interface connector connects to the PCMCIA interface card.

‚‚ DC in Jack:

This jack connects to the AC adapter.

ƒƒ Line out Jack:

This jack outputs audio signal to an amplifier.

„„ DC Source Switch

This switch select DC power source for the CD-ROM drive.

There are two sources to choose from battery or AC adapter.

- -

POWER SOURCE

The CD-421 can be either powered by the AC adapter or by the batteries

as a flexible option. However, the AC adapter has a priority over the

battery in powering the CD-ROM. That means if you connect the AC

adapter, the CD-421 will operate on it regardless if the batteries are

installed.

The CD-421 will be turned on automatically when your computer is

powered on and the PCMCIA interface card is connected to the

computer and initialized. On the other hand, when you turn off your

computer or disconnect the PCMCIA interface card from your computer,

the CD-421 will be powered off automatically. Such convenient design

ensures that users will not waste the battery power if the CD-ROM is not

in use.

The POWER LED indicates the power state, it will always light up when

the power supply is in the normal condition. The LED will flash if the

power is insufficient caused by a malfunctioning AC adapter or if the

batteries are reaching the end their service life. In this case, remove

the old batteries and replace with new batteries, or check your AC

adapter to see if it is defective or improperly connected.

CONNECT THE AC ADAPTER

1. Connect the AC adapter plug to the DC IN jack at the rear panel of

the CD-ROM.

2. Attach the AC adapter to the AC power outlet.

CAUTION

Use only the AC adapter provided with this unit. Using the

incorrect AC adapter will result in permanent and unpredictable

damage to the CD-421.

- -

INSTALLING THE BATTERIES

The CD-421 requires eight AA size batteries (not included) for operation.

When using alkaline batteries, the battery life may last for more than 3

hours if the CD-421 is used in CD-ROM mode, it can be even longer

when the CD-421 is used in CD-Audio mode. You can also use NiCad

rechargeable battery’s which have a shorter service life. Both the

rechargeable battery and the re-charger are NOT provided with this unit.

To install the batteries, follow the instruction below:

1. Remove the disc from the CD-ROM.

2. Power off the CD-ROM by disconnecting the PCMCIA interface card

from your computer.

3. Turn over the CD-ROM drive and place horizontally.

4. Press and slide the battery lid in the direction of the arrow to remove

it. (As shown in Figure 3)

Figure 3

5. Install eight fresh AA batteries in the order as illustrated in Figure 4,

and make sure polarities are aligned properly. It is recommended that

you follow the order in the illustration to install the batteries with ease.

6. Please note that the battery ribbon must be arranged as shown in

Figure 4. Otherwise, it will be difficult to remove the batteries.

7. Replace the battery lid.

Tabla de contenidos

Otros manuales de Unidad de CD/CDR de EXP Computer

EXP Computer

EXP Computer Portable CD-ROM Manual de usuario

EXP Computer

EXP Computer CD Traveler Manual de usuario

EXP Computer

EXP Computer CD ReWriter CRW-726 Manual de usuario

EXP Computer

EXP Computer CRW-740 Manual de usuario

EXP Computer

EXP Computer CD-940E Manual de usuario

EXP Computer

EXP Computer CDS-940 Manual de usuario

EXP Computer

EXP Computer CD Station Manual de usuario

EXP Computer

EXP Computer PD TRAVELER Manual de usuario

EXP Computer

EXP Computer CDG-821 Manual de usuario

Manuales populares de Unidad de CD/CDR de otras marcas

Philips

Philips CDD3610 Manual de usuario

QPS

QPS Que!Fire Manual de usuario

LG GCC-4241N Manual de usuario

Plextor

Plextor 12X-3 Guía

Samsung

Samsung SN-324B Manual de usuario

Teac

Teac CD-211E Manual de usuario

SmartDisk

SmartDisk Firewire CD-R/W Manual de usuario

Axis

Axis CD-ROM SERVER Manual de usuario

LG CRD-8322B Manual de usuario

Memorex

Memorex 32023234 - 52x32x52x External USB2.0 CD... Instrucciones de instalación

Yamaha

Yamaha CD Recordable/Rewritable Drive CRW3200 Manual de usuario

Sony

Sony CRX230AE Manual de usuario

Sony

Sony CRX - 160E Manual de usuario

Panasonic

Panasonic KX-LD742 Manual de usuario

Pioneer

Pioneer BDR-S13U-X Manual de usuario

Panasonic

Panasonic LK-MC606BP Manual de usuario

Panasonic

Panasonic CF-VCW Series Manual de usuario

LG CRD-8320B Manual de usuario
