Ewent EW7015 Manual de usuario

EW7015

Dual Docking Station USB

3.0

for harddisk SATA 2.5” and 3.5”

ENGLISH

EW7015 R1 Dual Docking Station USB 3.0 for

harddisk SATA 2.5” and 3.5”

Table of contents

1.0 Introduction ...........................................................................................................2

1.1 Functions and features......................................................................................2

1.2 Packing contents...............................................................................................3

2.0 Connecting a hard disk..........................................................................................3

3.0 Connecting the EW7015 to your computer ............................................................3

4.0 Using the EW7015.................................................................................................4

4.1 Preparing the hard disk using Windows XP/Vista...............................................4

4.2 Preparing the hard disk using Windows 7/8.......................................................5

5.0 OTB software ........................................................................................................5

5.1 Installing the OTB software................................................................................5

5.2 Using the OTB software.....................................................................................5

5.2.1 Using the backup button of the EW7015.........................................................6

5.2.2 Making a backup with the PC Clone EX software ...........................................6

5.2.3 Restore a backup ...........................................................................................6

6.0 Clone Function......................................................................................................7

7.0 Frequently Asked Questions and other related information....................................8

8.0 Service and support...............................................................................................8

9.0 Warning and points of attention .............................................................................9

10.0 Warranty conditions...........................................................................................10

1.0 Introduction

Congratulations with the purchase of this high-quality Ewent product! This product

has undergone extensive testing by Ewent’s technical experts. Should you

experience any problems with this product, you are covered by a five-year Ewent

warranty. Please keep this manual and the receipt in a safe place.

1.1 Functions and features

The EW7015 Docking Station offers you a quick and easy way to connect a 2.5’’

and/or 3.5’’ SATA hard disk without having to open the cover of your computer. The

EW7015 is equipped with a USB 3.0 port. Thanks to this connection, it is very easy to

save and exchange your data. The EW7015 features a smart one-touch backup

button which allows you to make a backup of your data.

ENGLISH

1.2 Packing contents

The following parts need to be present in the packing:

•EW7015 R1 Dual Docking Station USB 3.0 for harddisk SATA 2.5” and 3.5”

•Power supply

•USB 3.0 cable

•CD-ROM with PC Clone EX software

•Manual

2.0 Connecting a hard disk

Use the following steps to mount a hard disk in the EW7015.

1. Make sure the EW7015 is completely turned off.

2. Take your SATA hard disk with the label on top and the SATA connector at the

bottom. Make sure the SATA connection is pointed towards the hard disk slot of

the EW7015. If correct, the connectors of the EW7015 and hard disk are perfectly

aligned.

3. Carefully slide the hard disk into the EW7015. The hard disk will align into it’s

position.

Hint: Do not disconnect the hard disk from the EW7015 while in use. The EW7015

needs to be turned off. This way, damage to both the hard disk and EW7015 can be

prevented.

3.0 Connecting the EW7015 to your computer

1. Make sure the hard disk has been mounted as described in chapter 2.

2. Connect the supplied USB cable to the USB connection of the EW7015.

3. Connect the other side of the USB cable to a free USB port on your computer.

4. Connect the cable of the power supply to the ‘DC IN’ connection of the EW7015.

5. Connect the power supply to a wall outlet.

6. Please make sure the switch ( on the backside ) is switched to “PM”.

7. Press the ‘Power’ button of the EW7015 to turn the EW7015 on.

8. Your computer will automatically detect the hardware of both the EW7015 and

the SATA hard disk. If correct, Windows will detect a ‘USB Mass storage device’.

Note: USB is ‘hot swappable’, which means there is no need to turn off your computer

while connecting the EW7015 using USB.

ENGLISH

4.0 Using the EW7015

The moment Windows has found the hardware and has finished installing this

hardware, the EW7015 is ready to be used. If a hard disk has been mounted which

has been pre-used, then you are able to use the hard disk to transfer data. However, if

the hard disk you have mounted is brand new, and has not been formatted before, you

have to prepare the hard disk for usage with Windows. Use the following steps to do

so.

Note: Make sure you must safely remove the EW7015 from your computer.

Click ‘Safely remove hardware’ icon on the taskbar and you will see al list of

devices. Click the device you want to remove.

4.1 Preparing the hard disk using Windows XP/Vista

1. Right click the ‘My Computer’ icon.

2. Click ‘Manage’.

3. Select the option ‘Disk Management’ from the left side of the screen.

4. Right click the new hard disk and choose ‘Initialize’.

5. Click ‘OK’.

6. Right click the new hard disk.

7. Click ‘New Partition’.

8. Click ‘Next’.

9. Click ‘Next’.

10. Click ‘Next’.

11. Choose the desired partition format (Note: when using FAT32 the partition size is

limited to 32GB).

12. Click ‘Next’.

13. Select the drive letter you wish to assign to this partition.

14. Click ‘Next’.

15. Select the desired file system: FAT32 or NTFS.

Note! If you only use the hard disk on Windows XP or Vista systems we recommend

the usage of the NTFS file system. However, If you are also using older Windows

systems, we recommend the usage of FAT32.

16. Enter a name for the new partition in the field 'Volume label'.

17. Enable the checkbox near ‘Quick format’.

18. Click ‘Next’.

19. Click ‘Finish’.

20. The hard disk is now ready to be used.

ENGLISH

4.2 Preparing the hard disk using Windows 7/8

1. Go to ‘Start’.

2. Select ‘Control Panel’.

3. Select ‘Administrative Tools’.

4. Select ‘Computer Management’.

5. Select ‘Disk Management’ at ‘Storage’.

6. Right-click the new hard disk and click ‘New Simple Volume’.

7. Choose the amount of free space needed for the new disk/partition. We

recommend to use all of the free disk space.

8. Select the drive letter you wish to assign.

9. Enter a name for the new partition.

10. Format the hard disk.

11. After formatting, the hard disk is ready to be used.

Note: Formatting the hard disk can take a few minutes, depending on the hard disk

size. Do not interrupt this process.

5.0 OTB software

5.1 Installing the OTB software

1. Start your computer.

2. Place the installation disk in your CD-rom or DVD-player.

3. The installation disk will start automatically .

4. Choose your language.

5. Choose Install EW7015.

6. Follow the instructions on screen to continue.

Note! When installing this software on Windows Vista or 7/8, you will be prompted to

give permission to continue the installation.

5.2 Using the OTB software

There are two methods to make a backup with the EW7015. You can use the PC

Clone EX software to make a backup, or you can use the ‘Clone button’ of the

EW7015 itself. In the following examples we will explain how you can use these two

methods.

ENGLISH

5.2.1 Using the backup button of the EW7015.

1. Press the ‘Clone’ button of the EW7015 once.

2. The PC Clone EX software will be started.

3. The first time you make a backup, you’ve to make a selection of the disk(s) and

folders you want to backup. At he left side of the screen you can make the

desired selection.

4. Press the ‘Clone’ button once more.

5. The backup will now start.

6. Click ‘OK’ to confirm that the backup has finished.

5.2.2 Making a backup with the PC Clone EX software

1. Click ‘Start’.

2. Click ‘Programs’

3. Select ‘PC Clone EX’.

4. Click ‘PC Clone EX’.

5. Click the second icon in the menu tray (Files Backup).

6. Select at the left column the hard disk and folders you want to backup.

7. Click at the right side of the screen on the first icon called ‘Backup’.

8. Click ‘Start’. The backup will now start.

9. Click ‘OK’ to confirm that the backup has finished.

5.2.3 Restore a backup

You can also restore a backup. This is a very convenient function which only alter

changed data. There is no need to make a complete backup again.

1. Press the backup button of the EW7015 or click the second icon in the system

tray (Files backup).

2. Now, select the desired files and folders you want to backup at the right side of

the screen. When selecting the first folder, all the subfolders and directories will

be saved in a backup.

3. Click at the right side of the screen on the ‘Restore’ icon.

4. Click ‘OK’ to confirm that restoring the backup has finished.

ENGLISH

6.0 Clone Function

Note! The cloning function works without PC connections.

1. Install 2 Hard disk on the EW7015. In the slot B the target disk and in slot A the

source disk

2. Please make sure the switch ( on the backside ) is switched to “Clone”.

3. Turn on the Docking Station

4. Click “clone button two times, and listen to beep sound, then 2 hard disks will

begin cloning

5. The LED of 25% on the EW7015 will be blinking when it starts to clone. LED light

will indicate the cloning rate from 25%, 50%, 75% to 100%.

6. When the 4 LEDs stop blinking and listen a beep sound, the cloning is finished..

Note! Don’t turn off the power or take out the hard disk before the cloning is finished

The cloning will takes a long time to finish clone.

For Example:

HDD volume TIME

80GB 35min

500GB over 3H

1TB over 6H

2TB 13H

3TB 18~19H

ENGLISH

7.0 Frequently Asked Questions and other

related information

The latest Frequently asked questions for your product can be found on the support

page of your product. Ewent will update these pages frequently to assure you have

the most recent information. Visit www.ewent-online.com for more information about

your product.

8.0 Service and support

This user’s manual has been carefully written by Ewent’s technical experts. If you

have problems installing or using the product, please fill out the support form at the

website www.ewent-online.com/

You can also contact us by phone. Please check www.ewent-online.com/ for the

helpdesk phone number and opening hours.

ENGLISH

9.0 Warning and points of attention

Due to laws, directives and regulations set out by the European parliament, some

(wireless) devices could be subject to limitations concerning its use in certain

European member states. In certain European member states the use of such devices

could be prohibited. Contact your (local) government for more information about this

limitations.

Always follow up the instructions in the manual*, especially where it concerns devices

which need to be assembled.

Warning: In most cases this concerns an electronic device. Wrong/improper use may

lead to (severe) injuries!

Repairing of the device should be done by qualified Ewent staff. The warranty

immediately voids when products have undergone self repair and/or by misuse. For

extended warranty conditions, please visit our website at www.ewent-online.com.

*Tip: Ewent manuals are written with great care. However, due to new technological

developments it can happen that a printed manual does not longer contain the most

recent information.

If you are experiencing any problems with the printed manual or you cannot find what

you are looking for, please always check our website www.ewent-online.com first for

the newest updated manual.

Also, you will find frequently asked questions in the FAQ section. It is highly

recommended to consult the FAQ section. Very often the answer to your questions will

be found here.

ENGLISH

10.0 Warranty conditions

The five-year Ewent warranty applies to all Ewent products, unless mentioned

otherwise before or during the moment of purchase. After buying a second-hand

Ewent product the remaining period of warranty is measured from the moment of

purchase by the product’s initial owner. Ewent warranty applies to all Ewent products

and parts, indissolubly connected or mounted to the product it concerns. Power supply

adapters, batteries, antennas and all other products not directly integrated in or

connected to the main product or products of which, without reasonable doubt, can be

assumed that wear and tear during use will show a different pattern than the main

product, are not covered by the Ewent warranty. Products are not covered by the

Ewent warranty when exposed to incorrect/improper use, external influences or when

opening the service parts of the product by parties other than Ewent. Ewent may use

refurbished materials for repair or replacement of your defective product. Ewent

cannot be held responsible for changes in network settings by internet providers. We

cannot guarantee that the Ewent networking product will keep working when settings

are changed by the internet providers. Ewent cannot guarantee the working of web

services, apps and other third party content that is available through Ewent products.

Ewent products with an internal hard disk have a limited warranty period of two years

on the hard disk. Ewent could not be held responsible for any data lost. Please make

sure that if the product stores data on a hard drive or other memory source, you will

make a copy before you return the product for repair.

When my product gets defective

Should you encounter a product rendered defective for reasons other than described

above: Please contact your point of purchase for taking care of your defective product.

EW7015_R1-UK | 01-2015

Tabla de contenidos

Otros manuales de Estación de acoplamiento de Ewent

Ewent

Ewent EW7011 R2 Manual de usuario

Ewent

Ewent EW7011 Manual de usuario

Manuales populares de Estación de acoplamiento de otras marcas

Sony

Sony Dream Machine XDR-DS12iP Manual de usuario

Acer

Acer USB Type-C Dock II Manual de usuario

ATEN

ATEN UC-2000 Manual de usuario

Xcellon

Xcellon HDD-202 Manual de usuario

Dok

Dok CR09 Manual de usuario

Philips

Philips BTM630/12 Manual de usuario

IOGear

IOGear Travel Pro GUD3C09 Manual de usuario

RKI

RKI SDM-E2 Manual de usuario

iHome

iHome iP15 Manual de usuario

VITURE ONE

VITURE ONE MOBILE DOCK Manual de usuario

Lindy

Lindy 42984 Manual de usuario

CipherLab

CipherLab 8001 Manual de usuario

Pyle

Pyle PIPDSP2 Manual de usuario

Avol

Avol AS2350 Manual de usuario

Datalogic

Datalogic JoyaTouch Manual de usuario

Philips

Philips DC190/79 Manual de usuario

Targus

Targus DOCK315EUZ Manual de usuario

Akasa

Akasa DuoDockX3 AK-DK08U3-BK Manual de usuario
