Evertz X-9504 Manual de usuario

Model X-9504

4 x 1 SDI Router

Model X-HD9504

4 x 1 High Definition Router

Instruction Manual

EVERTZ MICROSYSTEMS LTD.

5288 John Lucas Drive,

Burlington, Ontario, Canada,

L7L 5Z9

Phone: 905-335-3700

Sales Fax: 905-335-3573

Support Fax: 905-335-0909

Internet: Sales: [email protected]

Tech Support: [email protected]

Web Page: http://www.evertz.com

Version 1.3.1 Feb 2002

The material contained in this manual consists of information that is the property of Evertz Microsystems and is

intended solely for the use of purchasers of the X-9504 and X-HD9504 Routers. Evertz Microsystems expressly

prohibits the use of this manual for any purpose other than the operation of the Router.

Microsystems Ltd. Copies of this guide can be ordered from your Evertz products dealer or from Evertz

Microsystems.

INFORMATION TO USERS IN EUROPE

NOTE

CISPR 22 CLASS A DIGITAL DEVICE OR PERIPHERAL

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to the European Union EMC directive. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. Operation

of this equipment in a residential area is likely to cause harmful interference in which

case the user will be required to correct the interference at his own expense.

INFORMATION TO USERS IN THE U.S.A.

NOTE

FCC CLASS A DIGITAL DEVICE OR PERIPHERAL

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instruction

manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own expense.

WARNING

Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could

void the user’s authority to operate the equipment.

Use of unshielded plugs or cables may cause radiation interference. Properly shielded

interface cables with the shield connected to the chassis ground of the device must be

used.

X-9504 and X-HD9504 Series Router Manual

REVISION HISTORY

REVISION DESCRIPTION DATE

1.0 Original Version June 99

1.1 Updated Menu structure to support GVG Ten XL protocol and GPI Mode Aug 00

1.2 Updated Table 2-4 to correct Pinout labels May 01

1.3 Added support for RS-232 and RS-422 external control July 01

Added Support for GVG Ten XL SMPTE serial control protocol

1.3.1 Added DIP Switch 5 functionality to Table 4-1 Feb 02

X-9504 and X-HD9504 Series Router Manual

This page left intentionally blank

X-9504 and X-HD9504 Series Router Manual

Manual Change Sheet 1.1-0 August 9, 2000 Page 1 of 4

The following document describes the operational changes to the 9504 Series Routers related to

firmware version 1.21. References to the 9504 manual are to version 1.2 printed May 2001.

1. Added Features

• GVG Ten XL SMPTE serial control protocol

• RS-232 and RS-422 external control supported

2. Installation

Table 2-1 in section 2.1.4 has been changed to show the pinout when COM 1 is operated in the RS-422

(485) mode. The new table is shown below.

COM 1 An RS-232 or RS-485 serial interface used for updating the firmware or external serial remote

control. The Setup menu is used to configure the COM 1 port for external control or firmware

updating and to configure the port for RS-485 or RS-232 operation. (See section 3.3.)

This COM1 port has a female 9 pin D with the following pinout

Name Description

1 GND Chassis ground

2 TxD/Tx- RS-232 Transmit Output / RS-422 Tx-(A)

3 RxD/Rx- RS-232 Receive Input / RS-422 Rx-(A)

5 Sig Gnd RS-232 Signal Ground

7 RTS/Rx+ RS-232 RTS Input / RS-422 Rx+(B)

8 CTS/Tx+ RS-232 CTS Output / RS-422 Tx+(B)

Table 2-1: COM 1 Pin Definitions

Note that when the control port is configured for RS-485 (RS-4222) operation an adapter cable with the

pinout shown in Table 2-5 will be required for connection to an edit controller with a SMPTE 207M

standard control port. Consult the technical information for your controller device to make sure you have

wired the cable correctly.

X-9504 and X-HD9504 Series Router Manual

Page 2 of 4 August 9, 2000 Manual Change Sheet 1.1-0

Router End Controller End

9 pin D

Male

Pin Belden

9729

9 pin D

Male

1 1

Tx- 2 -------1a------ Rx- 2

Rx+ 7 -------2b------ Tx+ 3

---drain 2---- RxGnd 4

Gnd 5

---drain 1---- TxGnd 6

Tx+ 8 -------1b----- Rx+ 7

Rx- 3 -------2a------ Tx- 8

9 9

Frame Gnd Shield ---drain 1---- Frame Gnd Shield

Table 2-5: RS422 Remote Control Adapter Cable

3. Menu Structure Changed to add new features.

Figure 3-2 in the menu system overview in section 3.3 has been changed to support the new features.

The new menu structure is shown below.

Video Reference Ntsc Pal 1080i/59.94 1080i/50 1080p/23.98(sF) 720p/59.94

Ref Align Line 1 align

Switchover line 10

External Control Gvg ten xl ASCII Gvg ten xl SMPTE

Baud Rate 38400 19200 9600

Serial Format 8.n.1 8.o.1 8.e.1 7.n.1 7.o.1 7.e.1

Serial Address 00

Serial Control Master Slave

Serial Standard RS-232 RS-485

GPO1 Assignment Switch trig Gen missing Psu alarm

GPO2 Assignment Switch trig Gen missing Psu alarm

GPI Mode Default Input #1 Hold Selection

Display level 0

Factory reset SEL+STATUS=RESET

Update Software? Erase alert

Figure 3-1: Overview of the Setup Menu

The relevant sections of 3.3 have been updated or inserted.

X-9504 and X-HD9504 Series Router Manual

Manual Change Sheet 1.1-0 August 9, 2000 Page 3 of 4

3.1.1. Selecting the External Remote Control Protocol

External Control Gvg ten xl ASCII Gvg ten XL SMPTE

This menu item is used to select the protocol used for control by routing switcher control devices. The

External Control, Baud Rate, Serial Format, and Serial Address settings must be set to match the desired

control protocol. The Serial Standard settings must be set to the correct serial communications standard

in use by the controller. The 9504 series routers can also serve as controllers by setting the Serial Control

menu item to master.

3.1.2. Selecting the Serial Data Standard

Serial Standard RS-232 RS-485

This menu item is used to select whether the electrical connection of the External control port follows the

RS-232 or RS-485 standard. The External Control, Baud Rate, Serial Control and Serial Format settings

must be set to match the desired control protocol.

X-9504 and X-HD9504 Series Router Manual

Page 4 of 4 August 9, 2000 Manual Change Sheet 1.1-0

This page left intentionally blank

X-9504 and X-HD9504 Series Router Manual

Revision 1.3

TABLE OF CONTENTS

1. OVERVIEW...................................................................................................................................1-1

1.1. HOW TO USE THIS MANUAL..................................................................................................1-1

1.2. GLOSSARY..............................................................................................................................1-2

X-9504 and X-HD9504 Series Router Manual

Revision 1.3

This page left intentionally blank
