Superior Water Disinfection in

Hazardous Areas Offshore

MD-HN

Cartridge

P/N 255349

(6 pack)

Replaces P/N

EV961004

MD-HE

Cartridge

P/N 255351

(6 pack)

Replaces P/N

EV962304

MD Single Head

P/N 169110 (1 Pack)

Replaces P/N EV927401

Designed for use

with MD-HN & MD-HE

lter cartridges.

MD Dual Head Assembly*

P/N 169111 (1 Pack)

Replaces P/N EV927402

Designed for use with

MD-HN & MD-HE lter cartridges.

MD Triple Head Assembly*

P/N 169112 (1 Pack)

Replaces P/N EV927403

Designed for use with

MD-HN & MD-HE lter cartridges.

Recirculating Brominator BENEFITS

•RecognizedbytheU.S.Navyandoffshoreindustryasthe

safest,mostreliable,andeasy-to-usemethodofwater

disinfectionaboardshiporrig/platform

•Iscompletelymechanical,andrequiresnoelectricity

•Constructedofdurablematerialstowithstandseverema-

rineenvironments

•Mountedona24"X28"steelplateforeasyinstallation

•Recirculatestank-storedwater

•Requiresnoadditionalpumptooperate–existingpressure

setpumpissufcient

•Requiresnoadditionalchemicals–brominecartridgesare

readytouseandrequirejust30secondstochange

•Automaticallydeliversbrominetowaterinaconstantratio

•SSFM-100M-15recirculatesat15gpm

•SSFM-100M-25recirculatesat25gpm

MD Water Filter BENEFITS

•Reduceschlorine,bromineandotherofftastesandodors

•Reducesdirtlargerthanone-halfmicroninsize

•Exclusive1/2micronprecoatltrationremoves99%of

asbestosbers,and99.95%cystssuchasCryptospo-

ridium,Toxoplasma,Giardia,andEntamoeba

•Keepsdrinkscarbonatedlonger

•MD-HNandMD-HEalsoinhibitlimescalebuild-upwhich

increaseslifeofwater-usingequipment

RECOMMENDATION FOR GREAT-TASTING WATER

TheinstallationofEverpureMDSeriesQuick-ChangeHeads

andWaterFilterCartridgesatalllocationswherepremium

qualitywaterisneededwillprovideyougreat-tastingingredi-

entwaterforcookinganddrinking.

SSFM-100M-15 & SSFM-100M-25

Recirculating Brominators

MD-CE

Cartridge

P/N 255350

(6 pack)

Replaces P/N

EV961210

SSFM-100M-15

P/N 169084

Replaces P/N EV906115

SSFM100M-25

P/N 169083

Replaces P/N EV906114

MD-CN

Cartridge

P/N 255348

(6 pack)

Replaces P/N

EV960123

SPECIFICATIONS

Dimensions

24"Wx28"HX8"D

Weight

75lbs.(34.0kg)

DryWeight:45lbs.(20.4kg)

Recirculation Rate

15gpmSSFM-100M-15

25gpmSSFM-100M-25

Mechanicaltimevalvecontrolstreatmentcycle.

Recirculatinglooppipingshouldnotbesmallerthan1"ID.

NO ELECTRICAL COMPONENTS

TheEverpureModelsSSFM-100M-15&SSFM-100M-25Recir-

culatingBrominatorsfeedasetquantityofbromineintoapotable

watertankensuringthatthewaterisbacteriologicallysafetodrink.

Thesebrominatorsaredesignedwithnoelectricalcomponents,

makingitidealforexplosion-proofenvironments.

MOUNTING

Selectalocationsuitableforsupportingtheweightanddimensions

ofthebrominatorbeforemounting.Themountingplateis24”X28”

withfour(4)mountingholesforbuyersuppliedscrews,nutsand

lockwashers.Allinstallationpipingisbuyersupplied.

PLUMBING TERMINATIONS

Therecirculatingbrominefeederbypassheaderisdesignedfor

mountingbetweentwo(2)1"IPScommercialanges.

NOTES

Apotablewaterstoragetankshouldbetreatedwheneveritislled

fromashoresource,orwheneverthereisnomeasurablebromine

residualinthetank.Ameasurablebromineresidualwillinsurethe

waterissafetodrink.Noadditionalpumpisrequired.Thepump

onthepressuresetwillbesufcient.

Watermetermonitorsowthroughthebrominecartridgeand

servesasthecartridgechangeindicator.

Treatedwaterleavingthebrominecartridgewillbeslightlycorro-

sive.Itisrecommendedthatthepipereturningtothestoragetank

beeitherbrass,bronzeorplastic.



'-08



 



&7&3163&

#30.*/"503

(BMMPOT

'FFEFS

"TTFNCMZ

FEEDER

ASSEMBLY

13" CLEARANCE REQUIRED FROM

FEEDER TOP TO ANY OVERHEAD

OBJECT FOR REMOVAL OF BROMINE

CARTRIDGE FROM FEEDER SHELL

17/32" DIAMETER

(4 HOLES) FOR

1/2" DIAMETER

MOUNTING BOLTS

BYPASS

HEADER

ASSEMBLY

STORAGE

TANK

GALLONS

POTABLE

WATER

STORAGE

TANK

FILL LINE

SSFM-100M-15

or SSFM-100M-25 15 GPM

or 25 GPM

QUARTERS

PRESSURE SET

(EXISTING)

SIMPLIFIED FLOW SCHEMATIC EVERPURE

RECIRCULATING BROMINATOR

MODELS SSFM-100M-15 & SSFM-100M-25

22"

28"

FLOW

26"

Pentair Filtration, Inc.

502IndianaAvenue-P.O.Box1047

Sheboygan,Wisconsin53082-1047

Phone866.873.7506Fax888.203.7361

InternationalPhone920.457.9435InternationalFax920.457.2417

www.everpure.com

24"

CAUTION
