Everpure Feeder/Deliming System EV9797-20 Manual de usuario

BENEFITS

APPLICATION/SIZING

INSTALLATION TIPS OPERATION TIPS

SR-X Feeder/Deliming System

Superior scale prevention and corrosion control for steam

equipment

SR-X Feeder and Deliming System: EV9797-20

SS-10 Cartridge: EV9799-02

2.2 lb package Scalekleen and Dip Tube

SR-X Feeder and Deliming System: EV9797-20

SS-10 Cartridge: EV9799-02

2.2 lb package Scalekleen and Dip Tube

A complete system that effectively targets scale

Provides protection against equipment corrosion

A sophisticated blend of polyphosphate

compound represents an advancement in scale

inhibition

Patented design (patent no. 5,580,448) dispenses

a controlled amount of Hydroblend™ for long-

term protection and provides greater effectiveness

than standard phosphate treatments

SS-10 cartridge is more effective in higher

alkalinty/ hardness/ TDS/ temperature

installations.

Clear bowl and cartridge make it easy to

determine when Hydroblend compound is

exhausted

System includes clear SR-X housing, SS-10

cartridge, dip tube assembly, (1) 2.2 lb. ScaleKleen

package

The SS-10 is NSF Certified under NSF/ANSI

Standard 42 for material requirements only

Choose a mounting location suitable to support

the full weight of the system when operating

Make sure to properly lubricate O-ring prior to

use

Use 3/4” water line (Optional reducer bushings

included)

Install vertically with bowl hanging down

Allow 2-1/2” clearance below the cartridge for

easy cartridge replacement

For steam applications, connect the system to the

boiler water only! Do not connect to the

condenser!

Deliming of equipment prior to application is

recommended, but not required

Inspect SS-10 cartridge at least every 6 months

Replace SS-10 cartridge before Hydroblend™

compound is completely dissolved

Pre-existing equipment scale may come loose and

clog equipment. Remove any loose scale to assure

satisfactory operation

For scale reduction applications

Provides scale reduction for steam applications

Provides deliming capabilities

EV9797-20

SR-X Feeder/Deliming System

Overall Dimensions:

12.44”H x 5.16”W x 5.5”D

Inlet connection: 3/4”

Outlet connection: 3/4”

Service Flow Rate:

Maximum 6.0 gpm (22.7 Lpm)

Pressure Requirements:

10 - 125 psi (0.7 – 8.6 bar), non-shock

Temperature: 35 - 100°F (2 - 38°C)

No electrical connection required

Shipping Weight: 6 lbs.

Operating Weight: 6 lbs.

**The ScaleStick® trademark is used

pursuant to an agreement between PWC

Enterprises and Everpure, Inc.

The contaminants or other substances

removed or reduced by this drinking water

system are not necessarily in your water. Do

not use with water that is microbiologically

unsafe or of unknown quality without

adequate disinfection before or after the

system. Systems certified for cyst reduction

may be used with disinfected water that may

contain filterable cysts.

SR-X Feeder and Deliming System

Everpure water treatment systems (excluding replaceable elements)

are covered by a limited warranty against defects in material and

workmanship for a period of five years after date of purchase.

Everpure replaceable elements (filter cartridges and water treatment

cartridges) are covered by a limited warranty against defects in

material and workmanship for a period of one year after date of

purchase. See printed warranty for details. Everpure will provide a

copy of the warranty upon request.
