EverFocus EI350 Manual de usuario

EVERFOCUS

1/3” 560 TVL Pure Vision Lens

Integrated Color Camera

Operation Instructions

Model No. EI350

Please read this manual first for correct installation and operation. This manual should be retained

for future reference. The information in this manual was current when published. The

manufacturer reserves the right to revise and improve its products. All specifications are therefore

subject to change without notice.

PRECAUTIONS

1. Do not install the camera near electric or magnetic fields.

Install the camera away from TV, radio transmitter, magnet, electric motor, transformer,

audio speakers since the magnetic fields generate from above devices will distort the video

images.

2. Never disassemble the camera nor put impurities in it.

Disassembly or impurities may result in trouble or fire.

3. Never face the camera toward the sun.

Direct sunlight or severe ray may cause fatal damage to sensor and internal circuit.

4. Keep the power cord away from water and liquid.

Touching the wet power cord may result in electric shock.

5. Never install the camera in areas exposed to water, oil or gas.

Water, oil or gas may result in failure, electric shock or fire.

6. Cleaning

Do not touch the surface of sensor by hand directly. Use a soft cloth to remove the dirt from

the camera body. Use lens tissue or a cotton swab and ethanol to clean the sensor and the

camera lens.

7. Do not operate the camera beyond the specified temperature, humidity or

power source ratings.

Use the camera at temperatures within 0℃~50℃(32℉ ~ 122℉) and humidity between

20%~ 80%. The input power source is 12VDC/24VAC.

PREFACE

The camera features a high performance, high-resolution 1/3" color CCD processor and

built-in vari-focal lens, which provides excellent picture quality, flexibility and cost savings.

A mounting bracket is included with every camera making it one of the most complete and

easy to install camera packages on the market.

FEATURES

z1/3” SONY Super HAD with low light sensitivity of 0.5 lux/F=1.2

zIndustry leading super high-res. with 560 TVL

zRevolutionary integrated 10-bit Digital Signal Processor (DSP) delivers excellent

picture quality an sharp color images

zIntelligent backlight compensation

zUtilizes Pure Vision Technology

PACKAGE CONTENTS

zCamera Unit x 1

zMounting Bracket x 1

zManual x 1

SPECIFICATIONS

Pickup Device 1/3'' SONY Super HAD CCD

Video Format NTSC or PAL

Scanning System NTSC: 525 TV lines, 60 fields/sec

PAL: 625 TV lines, 50 fields/sec

Picture Elements 768 x 494(NTSC) ; 752 x 582(PAL)

Horizontal Resolution 560TVL

Sensitivity 0.5Lux/F=1.2

S/N Ratio Over 48dB(AGC off)

Electronic Shutter 1/50(1/60)~1/100,000

Lens Type Vari-focal lens, Auto Iris

f=3.8~9.5mm, F=1.2

Back Light Comp. ON/OFF Switch

Auto Gain Control ON/OFF Switch

Flickerless ON/OFF Switch

Auto White Balance Yes

Gamma Correction 0.45

Video Output BNC 1.0Vp-p , 75ohm

Sync. Mode Line Lock/Internal Sync

Power Source 12VDC/24VAC

Power Consumption 24VAC: 7.5VA max.

12VDC: 4.5W max.

Dimensions 66mm(W) x 59mm(H) x 146mm(D);

2.56" (W) x 2.3"(H) x 5.7"(D)

Weight 0.4kg ; 0.9lbs

Mounting Bracket: Aluminum, Dimension 145 (H) x 56.5 (O.D.) mm / 5.7"(H) x

2.2(O.D); Max Load 3 kgs

Operating Temperature 0°C~50°C ; 32°F~122°F(20%~80% Humidity)

Service Kit: Mounting bracket x 1 pcs

Certifications FCC/CE

DIMENSIONS

USING SPECIAL FEATURES

Lens adjustment

You may adjust the focus and zoom of the lens to bring the object in focus.

This lens has two focal distances. The change of Tele/Wide can be done with

zooming. You could switch focus between Tele/Wide, by re-adjusting focusing once again.

Back Light Compensation

When BLC is turned on, the AGC, ES or IRIS operating point is determined by averaging

over the center area instead of entire field-of-view, so that a dimly-lit foreground object at

center area can be clearly distinguished from brightly-lit backgrounds.

BLC should not be used unless it is needed to compensate for back-lit.

Back Panel

1. Auto IRIS adjustment

2. Function switcher

Flickerless On/Off

When picture flicker fiercely, turn FL on, then the camera will stabilize the speed of

electronic shutter at 1/100(NTSC) or 1/120(PAL) automatically, and reduce the flicker

immediately.

BLC (Back Light Compensation) Normal/On

When BLC is turned on, the AGC, ES and IRIS operating points are determined by

averaging over the center area instead of entire field-of-view, so that a dimly-lit foreground

object at center area can be clearly distinguished from brightly-lit backgrounds.

BLC should not be used unless it is needed to compensate for back-lit. The default setting is

Normal.

AGC (Automatic Gain Control) Off/On

AGC ON: The sensitivity increases automatically when light is low.

AGC OFF: A-low-noise picture is obtained under a low light condition.

The default setting is ON.

LL (Line-Lock) Off/On

To select the sync mode between Internal Sync.(LL off) and Line-Lock (LL on).

Set the line-lock off, the camera will synchronize to the internal time base. Set the line-lock

on, the camera’s vertical synchronization can be driven by the AC signal in the power lines.

The default setting is Off.

Note: Line-Lock sync mode operation is possible only when used with an AC power

source; it is not possible with a DC power source.

3. Video output connector

4. 12VDC/24VAC input terminal

5. V Phase adjustment

INSTALLATION

1. Connect the video output of the camera to a color monitor or other video device through a 75

ohm type coaxial cable with BNC female connector at camera end.

2. Plug the power cord to the outlet. Power indicator LED should light if the power source is

properly connected.

3. Remove the lens cover cap from the top of the camera for adjusting the vari-focal lens.

4. Once the image appears on the monitor, adjust the focus and diaphragm of the lens to

obtain the best picture.

5. Mount the camera on the mounting bracket by using the mounting hole on the top and bottom

of camera casing.

EverFocus Electronics Corp.

Head Office:

12F, No.79 Sec. 1 Shin-Tai Wu Road,

Hsi-Chih, Taipei, Taiwan

TEL: +886-2-26982334

FAX: +886-2-26982380

www.everfocus.com.tw

USA L.A. Office:

1801 Highland Ave. Unit A

Duarte, CA 91010, U.S.A.

TEL: +1-626-844-8888

FAX: +1-626-844-8838

www.everfocus.com

USA N.Y. Office:

415 Oser Avenue Unit S

Hauppauge, NY 11788

TEL: 631-436-5070

FAX: 631-436-5027

www.everfocus.com

Europe Office:

Albert-Einstein-Strasse 1

D-46446 Emmerich, Germany

TEL: 49-2822-9394-0

www.everfocus.de

China Office:

Room B-05D-1, KESHI PLAZA , Shangdi

Information Industry Base,

Haidian District, Beijing China

100085

TEL: +86-10-62973336/37/38/39

FAX: +86-10-62971423

www.everfocus.com.cn

Japan Office:

1809 WBG MARIBU East 18F,

2-6 Nakase.Mihama-ku.

Chiba city 261-7118, Japan

TEL: +81-43-212-8188

FAX: +81-43-297-0081

www.everfocus.com

our EverFocus product is desi

ned and

manufactured with high quality materials and

components which can be recycled and

reused.

This symbol means that electrical and

electronic equipment, at their end-of-life,

should be disposed of separately from your

household waste.

Please, dispose of this equipment at your

local community waste collection/recycling

centre.

In the European Union there are separate

collection systems for used electrical and

electronic product.

Please, help us to conserve the environment

we live in!

Ihr EverFocus Produkt wurde entwickelt und

hergestellt mit qualitativ hochwertigen

Materialien und Komponenten, die recycelt

und wieder verwendet werden können.

Dieses Symbol bedeutet, dass elektrische und

elektronische Geräte am Ende ihrer

Nutzungsdauer vom Hausmüll getrennt

entsorgt werden sollen.

Bitte entsorgen Sie dieses Gerät bei Ihrer

örtlichen kommunalen Sammelstelle oder im

Recycling Centre.

Helfen Sie uns bitte, die Umwelt zu erhalten, in

der wir leben!

P/N: MI35G00800_Ver.B
