EverFocus ED560 Manual técnico

Operation Instruction

3”

”

Volume

EverFocus

Operation Instruction

Please read this manual first for correct installation and operation. This manual should be retained for future

reference. The information in this manual was current when published. The manufacturer reserves the right to

revise and improve its products. All specifications are therefore subject to change without notice.

means without written permission of the EverFocus Electronics Corporation.

Precautions

1. Do not place any object on top of the cover.

2. Be careful when handling the camera, do not drop it or subject it to strong shock or vibration to prevent

any damages to it. Do not disassemble it or place it on an unstable base.

3. Install the camera away from TV, radio transmitter, magnet, electric motor, transformer, audio speakers

because the magnetic fields generate from above devices will distort the video image.

4. Install the camera away from stoves, or other heat generating devices as the high temperature could cause

deformation, discoloration or other damages of the camera. Install the camera at where the temperature

range will stay between -10°C to 50°C (14°F to 122°F).

5. Never aim the camera at the sun or other extremely bright objects whether it is in use or not.

6. Do not touch the surface of CCD sensor by hand directly. Use a soft cloth to remove the dirt from the

camera body. Use lens tissue or a cotton tipped applicator and ethanol to clean the CCD sensor and the

camera lens. When the camera is not in use, put the cover cap on the lens mount.

7. All warnings on the products and in the operating instructions should be adhered to.

8. Do not use attachments not recommended by the appliance manufacturer as they may cause hazards.

9. Do not allow anything to rest on the power cord. Do not locate this appliance where the cord will be

abused by persons walking on it.

10. Do not overload wall outlets and extension cords as this can result in fire or electric shock.

11. Never push objects of any kind into his appliance through cabinet slots as they may touch dangerous

voltage points or short out parts that could result in fire or electric shock.

12. Refer all work related to the installation of this product to qualified service personnel or system installers.

Federal Communication Commission Interference

Statement

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by

one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance

could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Table of Contents

1. Product Overview……………………………………………6

1.1 Features............................................................................7

1.2 Accessory Parts List ........................................................ 8

1.3 Specifications................................................................. 10

1.4 Dimensions...................................................................... 11

1.5 Camera Component Description .................................... 12

1.6 Front and Back Panel Layout.......................................... 13

1.7 Related Products ............................................................15

2. INSTALLATION………………………………………………16

2.1 Mounting Camera............................................................17

2.1 .1 Drill the Holes ........................................................ 17

2.1.2 Mounting .................................................................19

2.2 Adjusting Camera ...........................................................21

2.2.1 Adjusting Camera Position .....................................21

2.2.2 Adjusting Zoom and Focus ..................................... 22

2.2.3 Camera Setting............................................................24

2.2.3.1 OSD User Setup Menu..................................... 24

2.2.4 Close the Camera Cover......................................... 25

3. OSD Menu & Configuration………………………………28

3.1 OSD Menu Setup ............................................................. 28

3.1.1 LENS........................................................................ 29

3.1.2 Shutter ................................................................... 29

3.1.3 White Balance Control............................................31

3.1.4 BACKLIHGT............................................................. 32

3.1.5 AGC (Auto Gain Control)......................................... 33

3.1.6 DNR (Dynamic Noise Reduction) ............................ 34

3.1.7 SENS-UP.................................................................. 35

3.1.8 SPECIAL .................................................................. 36

3.1.8.1 CAMERA ID...................................................... 37

3.1.8.2 COLOR ADJ ..................................................... 38

3.1.8.3 SYNC ............................................................... 38

3.1.8.4 MOTION DETECTION....................................... 39

3.1.8.5 PRIVACY..........................................................42

3.1.8.6 MIRROR...........................................................44

3.1.8.7 SHARPNESS....................................................45

3.1.8.8 RESET.............................................................. 45

3.1.8.9 RETURN...........................................................46

3.1.9 EXIT......................................................................... 46

Product Overview

The new ED560 is designed with the advanced 16-bit Digital Signal Processor (DSP) for powerful

processing capability to show 560TVL horizontal resolution. Designed with SENS-UP 128X slow

shutter technology, ED560 captures images in almost darkness with super high sensitivity of

0.002lux. With 3-Axis rotation, ED560 offers quick and flexible wall or ceiling installation. In

addition, ED560 is weatherproof IP66 rated, vandal resistant to avoid any intentional destruction.

ED560 is ideal for 24/7 surveillance in all outdoor application. It is available in model with or

without True Day/Night function.

Chapter

CHAPTER 1 PRODUCT OVERVIEW

1.1 Features

z1/3” SONY Super HAD CCD for excellent picture quality

z560TVL of horizontal resolution with the advanced 16-bit Digital Signal Processor (DSP)

zED560 captures clear images in almost darkness with 0.002 Lux

zSENS-UP Slow Shutter 128X max.

zTrue Day/Night function with removable IR cut filter (ED560T)

zBuilt-in DNR (Dynamic Noise Reduction) for noise reduction and a 70% saving of disk

storage

z3-Axis rotation

zEasy wall or ceiling installation

zOSD setting menu

zSupport Motion Detection function

zSupport Privacy function

zVandal resistant

zWeatherproof IP66 rated

CHAPTER 1 PRODUCT OVERVIEW

1.2 Accessory Parts List

Please be careful when you unpack the box due to the electronics devices inside. Check and make sure

that you have all the items listed below inside the original box:

•Camera Unit x 1

•Operation Manual x 1

•Mounting kit includes:

-Long Screws x 3 (for mounting base)

-Expanding Screws x 3

-Washer x 3

•Circle Installation Sticker x 1

•Video Cable x 1

•Extension Power Cable x 1

•Desiccant Pack x 1

CHAPTER 1 PRODUCT OVERVIEW

•Focus Aiding Lens Cap(for 9~22mm models only) x 1

Please Note: If an item appears to have been damaged in shipment, replace it properly in its carton and

notify the shipper. If any items are missing, notify your EverFocus Electronics Corp. Sales Representative or

Customer Service. The shipping carton is the safest container in which the unit may be transported. Save it

for possible future use.

CHAPTER 1 PRODUCT OVERVIEW

1.3 Specifications

Items Parameter

Picku

Device 1/3” SONY Su

er HAD CCD

Video Forma

NTSC or PA

Scanning System NTSC:525 TVL, 60 fields/sec

PAL:625 T

L, 50 fields/sec

Picture Elements 768 x 494

(

NTSC

)

; 752 x 582

(

PAL

)

Horizontal Resolution 560 T

Sensitivit

0.002Lux

(

SENS-UP 128x

)

; 0.25Lux/ F=1.2

S/N Ratio Over 50 dB

(

AGC off

)

Electronic Shut

er 1/50

(

1/60

)

~1/100,000

Lens Type Vari-focal lens, Auto Iris

f=2.9~10mm/F=1.2 ;f=9~22mm/F=1.6

*Lens models and availabilit

var

in different re

ions

Bac

ht Com

. Off/Low/Middle/Hi

h Ad

ustable

uto Gain Control Off/Low/Middle/Hi

h Ad

ustable

uto White Balance

(

2500 °

~8300 °

)

/AWC/Manual

Gamma Correction 0.45

True Day & Night Yes

Flickerless Yes

Video Output 2 video outputs

BNC 1.0Vp-p, 75ohm

dditional testin

video out

ut 1.0V

, 75ohm

nc. Mode Line Lock/Internal s

nc.

H-Mirror Yes

OSD Menu Yes

Vandal Resistan

Yes

Power Source 12VDC/24VAC

Power Consumption 24VAC 5VA max

12VDC 3.5W max

Dimensions 123mm

(

O.D.

)

x 107.8mm

(

)

; 4.8”

(

O.D.

)

x 4.2”

(

)

Wei

ht 0.74 k

/ 1.6 lbs

eratin

erature -10°C~50°C ; 14°F~122°F

(

20%~80% Humidit

Weather

roof IP66

CHAPTER 1 PRODUCT OVERVIEW
