EverFocus EDR410H Manual de usuario

Volume

Instruction Manual

EVERFOCUS ELECTRONICS CORPORATION

EDR 810H / EDR810M

EDR 410H / EDR410M

Instruction Guide

1801 Highland Ave

Phone 626.844.8888 • Fax 626.844.8838

form or by any means without written permission of the Everfocus Electronics Corporation.

QuickTime is a registered trademark of the Apple Computer, Inc. Windows is a registered trademark

of the Microsoft Corporation in the United States and other countries. Linksys is a registered

trademark of the Linksys Corporation. D-Link is a registered trademark of the D-Link Corporation.

DynDNS is a registered trademark of the DynDNS.org Corporation. Other product and company

names mentioned herein may be the trademarks of their respective owners.

Release Date: January 2006

Table of Contents

CHAPTER 1

Product Overview 1

Features 1

Specifications 2

Front Panel Keypads 3

Back Panel Connections 6

Monitor Display 9

CHAPTER 2

Installation 11

Basic Wiring Instructions 12

Hard Disk Drive Installation 13

Final Install Process 13

CHAPTER 3

DVR Menu Setup 14

Time/Date Setup Menu 15

Camera Setup Menu 19

Record Setup Menu 23

Alarm Setup Menu 25

Motion Setup Menu 28

VLoss Setup Menu 32

Network Setup Menu 34

Config 34

Alarm Network 36

Email 38

Password 39

Wireless Network (EDR410-810M Only) 40

Schedule Setup Menu 43

Disk Setup Menu 45

Control Setup Menu 46

Warning Setup Menu 48

Fan Fault 48

HDD Temp 49

No HDD 51

HDD Full 52

System Setup Menu 54

CHAPTER 4

Recording Overview 58

Instant (N) Recording Setup 58

Schedule Recording Setup 59

Event Recording Setup 60

CHAPTER 5

Playback Overview 63

Basic Playback 63

Search Playback 65

CHAPTER 6

Copying Video 68

Viewing Copied File 70

CHAPTER 7

Call Overview 72

CHAPTER 8

Screen Display Setting & Mode 74

Mode Button 75

CHAPTER 9

How to Upgrade Firmware? 76

CHAPTER 10

Networking Overview 77

Introduction to TCP/IP 77

Subnet Masks 77

Gateway Addresses 78

Virtual Ports 78

Pre-Installation 79

What Type of Network Connection 80

Simple One to One Connection 81

Direct High Speed Modem Connection 87

Router or LAN Connection 89

CHAPTER 11

Linksys Port Forwarding 92

Dynamic DNS 95

CHAPTER 12

D-Link Port Forwarding 97

Dynamic DNS 100

CHAPTER 13

DDNS 102

Creating DDNS Account 102

CHAPTER 14

Viewing through Internet Explorer 105

CHAPTER 15

Interface Specifications 115

Transmission Settings 116

Remote Control Protocol 116

Appendix A

Remote Control 120

Appendix B

Alarm Board Configuration 121

Appendix C

RJ45 (RS485) Pin Assignment 122

Troubleshooting 123

Safety Warning

WARNING

TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Note:

This equipment has been tested and found to comply with the limits for a Class A digital device,

The changes or modifications not expressly approved by the party responsible for compliance could

void the user's authority to operate the equipment.

Note:

This is a class A product. In a domestic environment this product may cause radio interference

In which case the user may be required to take adequate measures.

Notice:

The information in this manual was current when published.

The manufacturer reserves the right to revise and improve its products.

All specifications are therefore subject to change without notice.

Safety Precautions

Refer all work related to the installation of this product to qualified service personnel or

system installers.

Do not block the ventilation opening or slots on the cover.

Do not drop metallic parts through slots. This could permanently damage the appliance?

Turn the power off immediately and contact qualified service personnel for service.

Do not attempt to disassemble the appliance. To prevent electric shock, do not remove

screws or covers. There are no user-serviceable parts inside. Contact qualified service

personnel for maintenance. Handle the appliance with care. Do not strike or shake, as this

may damage the appliance.

Do not expose the appliance to water or moisture, nor try to operate it in wet areas. Do take

immediate action if the appliance becomes wet. Turn the power off and refer servicing to

qualified service personnel. Moisture may damage the appliance and also cause electric

shock.

Do not use strong or abrasive detergents when cleaning the appliance body. Use a dry cloth

to clean the appliance when it is dirty. When the dirt is hard to remove, use a mild detergent

and wipe gently.

Do not overload outlets and extension cords as this may result in a risk of fire or electric

shock.

Do not operate the appliance beyond its specified temperature, humidity or power source

ratings. Do not use the appliance in an extreme environment where high temperature or

high humidity exists. Use the appliance at temperature within indoor type DVR for 0oC ~

+40oC and a humidity below 90%. The input power source for this appliance is

AC100~240V.

Safety Precautions

Read Instruction — All the safety and operating instructions should be read before the unit is

operated.

Retain Instructions — The safety and operating instructions should be retained for future

reference.

Heed Warnings— All warnings on the unit and in the operating instructions should be adhered to.

Follow Instructions— All operating and use instructions should be followed.

Cleaning— Unplug the unit from the outlet before cleaning. Do not use liquid cleaners or aerosol

cleaners. Use a damp cloth for cleaning

Attachments—Do not use attachment not recommended by the product manufacturer as they may

cause hazards.

Water and Moisture—Do not use this unit near water-for example, near a bath tub, wash bowl,

kitchen sink, or laundry tub, in a wet basement, near a swimming pool, in

an unprotected outdoor installation, or any area which is classified as a wet

location.

Servicing—Do not attempt to service this unit by yourself as opening or removing covers may

expose you to dangerous voltage or other hazards. Refer all servicing to qualified

service personnel.

Power Cord Protection—Power supply cords should be routed so that they are not likely to be

Chapter

Product Overview

DVRs are the industry’s first full-featured digital video recorder designed specifically

for use within the security industry. The Digital Video Recorder incorporates all the

benefits of digital video recording, is simple to install, and operates just like a VCR.

Highly efficient compression technology and superior resolution of recorded images

make the Digital Video Recorder stand out from the competition as the best choice for

security surveillance.

1.1 Features

¾Duplex Operation for Recording & Playback

¾Built-in MPEG4 Codec with Configurable Quality

¾Variable Recording Speeds up to 120/100 Images per second for NTSC/PAL

¾Audio Recording Capabilities

¾Motion Detection Capabilities

¾One 3.5” Hard Disk with Hot-Swap Tray for Internal Storage

¾Ethernet Interface for Remote Network Viewing

¾Optional Wireless LAN Interface for Data Transmission (Reserved)

¾RS232 and RS485 for Remote Control

¾Shuttle/Jog Dial for Picture-by-Picture or Fast/Slow Viewing

¾Easy-to-use Control Panel with Common VCR and Multiplexer Functions

¾On-Screen Menus Operations with Multi-Language Support

¾Real-Time Live Display for all Cameras

¾Easy archiving of video and Remote Viewer through USB port

1.2 Specifications

Video Format NTSC/EIA or PAL/CCIR

Video Input 4/8 camera inputs (BNC), 1Vp-p/75ohm

1 BNC video out (1Vp-p/75ohm) for Main Monitor

1 BNC video out (1Vp-p/75ohm) for CALL Monitor

Video Output 4 video out (1Vp-p/75ohm) for Looping (4 Channels only)

Video Compression MPEG4

Recording Resolution 720x240, 720x480 or 360x240 for NTSC (selectable)

720x288, 720x576 or 360x288 for PAL

Video Display Full, PIP, 4, 7, 8/9 and 2x2 Zoom for Live Viewing and Playback

Display Resolution 720x240, 720x480 or 360x240 for NTSC (selectable)

720x288, 720x576 or 360x288 for PAL

Video Pause Yes

4/8 Alarm Inputs 4/8 Alarm Inputs

Alarm Outputs 1 Alarm Output

Hard Disk Storage One Hot-Swappable 3.5” IDE Hard Disk

Recording Rate Up to 30(N)/25(P) Images per second for 720 x 480(N)/720 x 576 (P)

Up to 60(N)/50(P) Images per second for 720 x 240(N)/720 x 288 (P)

Up to 120(N)/100(P) Images per second for 360 x 240(N)/360 x 288(P)

Recording Mode Continue, Time-lapse, Schedule,

Event recording (Motion and Alarm)

Playback Rate Up to 30/25 Images per second for 720 x 480/720 x 576

Up to 60/50 Images per second for 720 x 240/720 x 288

Up to 120/100 Images per second for 360 x 240/360 x 288

Playback Search By Date/Time or Event (Motion, Video Loss, Alarm)

Motion Detection Yes, with MULTIPLE configurable detection areas & sensitivity

Video Loss Detection Yes

Event Log Yes

User Interface User-friendly Menu Driven

Setup On screen display setup

User Input Device Front panel keypad with Shuttle/Jog

Timer Built-in real time clock and Auto Time Synchronization with global NTP

server through Internet

Watch Dog Timer Yes

Title 12-characters title for each camera

Ethernet RJ45 connectors for network communication

Archive USB for archiving

RS-232 9-pin female connector for local communication

RS-485 for Keyboard connection

Audio 2 mono inputs, 2 mono (SPEAKER) outputs

Power Rate DC 12V/DC 24V

Dimension Half size: 320 mm (L) x 215mm (W) x 100mm (H)

Mobile : 320.8mm (L) x 215mm (W) x 109.9mm(H)

Weight 4.85 KG

Operating Temperature 0oC ~ +50oC

Remote Controller IR Remote Controller

IR Remote Controller with Extension Wire(optional)
